Mytrix Technology -

http://www.mytrixtech.com

Dreamweaver

Desktop 3D Printer

User Manual

2014 Mytrix Technology

Table of Contents

Need help?

Do you have a question about the Dreamweaver and is the answer not in the manual?

Questions and answers

Summary of Contents for MYTRIX Dreamweaver

Page 3: Table Of Contents
Mytrix Technology - http://www.mytrixtech.com Catalogue Chapter 1 Assembling the printer ..................4 1.1 Installing the extruder ...................... 4 1.2 Feeding the filament ...................... 11 1.3 Installing glass platform ....................15 Chapter 2 Loading and changing filament ..............17 Chapter 3 Off-line print and LCD control Panel ............
Page 4 Mytrix Technology - http://www.mytrixtech.com 4.1 Coarse adjustment ......................28 4.2 Fine adjustment......................28 Chapter 5 Installing software ....................29 Chapter 6 Solution when unable to install Arduino driver ........30 Chapter 7 Software introduction ..................32 7.1 Quickprint ........................32 7.2 Full settings ........................
Page 5 Mytrix Technology - http://www.mytrixtech.com 9.3 Assembleing matching graphic tolerance ..............49 9.4 Big size graphic print ..................... 49 Chapter 10 FAQ ........................50 Chapter 11 Notice ......................... 51 Chapter 12 Maintanence ....................52 2014 Mytrix Technology All rights reserved Third Version...
Page 6: Chapter 1 Assembling The Printer
Mytrix Technology - http://www.mytrixtech.com Chapter 1 assembling the printer 1.1 Installing the extruder Find the white PTFE round base at the cross-shaped sliding table, as shown below. 2014 Mytrix Technology All rights reserved Third Version...
Page 7 Mytrix Technology - http://www.mytrixtech.com cross-shaped sliding table white PTFE round base Align the aluminum tube with the PTFE round-shaped hole, press it in slowly, and make sure it is the right direction, the end with the chamfer should be facing up, as shown below.
Page 8 Mytrix Technology - http://www.mytrixtech.com Align the screw hole, then install the screws, as shown below. use the hex tool to tighten the screws 2014 Mytrix Technology All rights reserved Third Version...
Page 9 Mytrix Technology - http://www.mytrixtech.com After it is successfully installed, the length of the aluminum tube exposed in the extruder surface should be the same as shown below. Align the two screw holes from the extruder motor with the screws in the motor settle socket, and then tighten the screws, as shown below.
Page 11 Mytrix Technology - http://www.mytrixtech.com Connect extruder motor cooling fan filament (while plug), as shown below. Connect the cooling nozzle fan filament (red plug), as shown below. 2014 Mytrix Technology All rights reserved Third Version...
Page 12 Mytrix Technology - http://www.mytrixtech.com Use the cable tie to tie all the filaments of the extruder, fasten them on the motor cooling tower. 2014 Mytrix Technology All rights reserved Third Version...
Page 13: Feeding The Filament
Mytrix Technology - http://www.mytrixtech.com 1.2 Feeding the filament Install the feeding frame, as shown below. 2014 Mytrix Technology All rights reserved Third Version...
Page 16 Mytrix Technology - http://www.mytrixtech.com Use the winding pipe (in the accessory box) to fix the electric wires and filament feeding tube, as shown below. Load the filament from the bottom offilamentfeeding pipe, as shown below. 2014 Mytrix Technology All rights reserved Third Version...
Page 17: Installing Glass Platform
Mytrix Technology - http://www.mytrixtech.com Load the filament into the filament feeding box of the extruder, as shown below. 1.3 Installing glass platform Use the clamp ( or torsion spring) to fix the glass plate on the print platform, the side...
Page 18 Mytrix Technology - http://www.mytrixtech.com with the tape should be facing up as it improves the printing adhesive, as shown below. 2014 Mytrix Technology All rights reserved Third Version...
Page 19: Chapter 2 Loading And Changing Filament
Mytrix Technology - http://www.mytrixtech.com Chapter 2 Loading and changing filament Introduction about LCD screen basic operation Basic function Operation Remarks Menu selection Rotate button of LCD screen Clockwiserotation top-down selection selected menu press LCD screen rotate button press and enter selected screen...
Page 20 Mytrix Technology - http://www.mytrixtech.com Back to previous choose ' ' and select this menu menu Load the filament into the filament feeding machine，and then can start to load and change the filament according to the following instruction. Press the LCD rotate button, enter the screen as below.
Page 21: Chapter 3 Off-Line Print And Lcd Control Panel
Mytrix Technology - http://www.mytrixtech.com Chapter 3 Off-line print and LCD control Panel 3.1 Testing print Insert SD card, as shown below. Choose ' Print from SD’ and press the rotate button. Choose test pattern according to the filament. 2014 Mytrix Technology...
Page 22 Mytrix Technology - http://www.mytrixtech.com The machine will preheat the platform first, when the temperature gets to the target point, the nozzle will start to warm up. When it reaches to its temperature, the print will start automatically. When it starts to print, check whether the platform height is appropriate or not. It can be adjusted with the four height adjustment screws at the bottom.
Page 23: Lcd Screen Control Introduction
Mytrix Technology - http://www.mytrixtech.com The standard height difference between the nozzle and platform is as thick as a card. Hot bed adjustment method, please refer to Chapter4 3.2 LCD screen control introduction 3.2.1 Pause, resume and stop print During print, it can be paused, resumed and stopped.
Page 25: Print Speed And Temperature Adjustment
Mytrix Technology - http://www.mytrixtech.com 3.2.2 Print speed and Temperature adjustment During printing, if the temperature does not match with the speed, it can be adjusted by the rotate button. Speed: Print speed. The percentage of compilation speed, for example 121%, means the compiling speed multiplied by 121%.
Page 27: Automatic Preheat
Mytrix Technology - http://www.mytrixtech.com 3.2.4 Automatic preheat Automatically preheat according to the filament, press the rotate button and choose ' prepare’. Choose preheat PLA or Preheat ABS according to the filament. 2014 Mytrix Technology All rights reserved Third Version...
Page 28: Control The Machine To Move
Mytrix Technology - http://www.mytrixtech.com 3.2.5 Control the machine to move Roll down and control XYZ axis separately, choose ' move Axis’. Choose the Axis that you want to control, for example, to control Z Axis. 2014 Mytrix Technology All rights reserved Third Version...
Page 29: Unlock
Mytrix Technology - http://www.mytrixtech.com Rotate the button to set the control schedule, press the button, Z axis will get to the setting height. 3.2.6 Unlock If unable to move the cross-shaped sliding table manually, that is because the motor is locked down after it is connected to the electricity, to unlock:rotate ' prepare' ...
Page 30: Coarse Adjustment
Mytrix Technology - http://www.mytrixtech.com 4.1 Coarse adjustment First, set the four springs at the bottom to the shortest, then press the LCD rotate button, choose ‘prepare-Auto home’. Hold the platform, and then shut down the power, eyes look straight forward to the...
Page 31: Chapter 5 Installing Software
Mytrix Technology - http://www.mytrixtech.com Adjust the platform regulation nuts, test a few more times until the distance is perfect. When print for the first round, it is better to pay close attention to it so as to make sure the nozzle will not hit the platform.
Page 32: Chapter6 Solution When Unable To Install Arduino Driver
Mytrix Technology - http://www.mytrixtech.com Chapter6 Solution when unable to install Arduino driver If you are using starter edition windows system, a system error might prompt up as ' the system can not locate the specified file' when installing Arduino driver, as shown below.
Page 33 Mytrix Technology - http://www.mytrixtech.com To solve this problem: 1.First, open C:\windows\inf\setupapi.dev.log This file contains relevant plug-and-play device and driver program installation info, and of course it tells you the reasons why it fails to install the Arduino driver. Open this file, slide to the end of the file name, you can see the info as shown below: This missing file is the reason why the Arduino cannot be installed.
Page 34: Chapter 7 Software Introduction
Mytrix Technology - http://www.mytrixtech.com 4. Re-install the driver, and now it will be successfully installed. Chapter 7 Software introduction 7.1 Quick print Press Expert and choose switch to quick print, as shown below. 2014 Mytrix Technology All rights reserved Third Version...
Page 35: Full Settings
Mytrix Technology - http://www.mytrixtech.com 7.2 Full settings Point the mouse to the parameter, you can see the details of every parameter. 7.3 Parameter introduction 7.3.1 General setting 1. Layer height: the thickness of every layer of the filament, support 0.05-0.3, value between 0.1-0.2 is recommended.
Page 36 Mytrix Technology - http://www.mytrixtech.com 3. Enable retraction: retract the filament when print. Effect: Without retraction, it will over pull the filament which will impact the overall printing. 4. Bottom/top thickness: the thickness of the bottom and the top. Effect: If the printed model has damaged holes on the top, please adjust the thickness figure accordingly.
Page 37: Advanced Setting
Mytrix Technology - http://www.mytrixtech.com for gravity reason. Therefore, a support is needed. But not for all. None: no support is needed. Touching build plate: support from outside, only add support for the overhang part outside of the model. Everywhere: add to every part of the model as long as it is overhang, including inside of the model.
Page 38 Mytrix Technology - http://www.mytrixtech.com 3. Retraction distance: the length of filament. These two parameter will only valid when choose retraction allow in the general setting. Effect: If the length of the retraction filament is too short, it will possibly lead to over- pulled, if it is too long, the filament might be able to be loaded.
Page 39: Print Screen
Mytrix Technology - http://www.mytrixtech.com 10. Outer shell speed: the speed of print wall, slow print can make the wall print better. Effect: Slow down the print speed of wall, the surface will be smoother. 11. Inner shell speed: the speed of the print in wall. Higher speed can shorten the print time.
Page 40 Mytrix Technology - http://www.mytrixtech.com Scale Scale the model Reset the model maximize the model Input the proportion in scale XYZ, or input the exact figure. Above is for scale the model proportionally. If only for a specific direction, you can click uniform scale item and scale it accordingly.
Page 41 Mytrix Technology - http://www.mytrixtech.com Mirror Mirror X Mirror Y Mirror Z View mode ：Normal view ：Overhang view, red mark will show up if a support is needed :Transparent view ：X-ray view ：Layers view, simulating the whole print procedure How to view model...
Page 42: Usb Network Print
Mytrix Technology - http://www.mytrixtech.com View the model from different angles: right click and do not release, move the mouse Move the model: left click and move the mouse Zoom in and out to view the model: roll the mouse wheel 7.4 USB network print...
Page 44: Chapter 8 Picture Printing
Mytrix Technology - http://www.mytrixtech.com Chapter 8 Picture printing Choose the picture, better use PS to change the background into transparent and save it as PNG format, if no need for transparent background, then can save as BMP/JPG/JPEG/PNG etc. image format.
Page 47: Chapter 9 Print Technique
Mytrix Technology - http://www.mytrixtech.com Chapter 9 Print technique FDM format 3D printer has its own print features, mastering those features can print out perfect graphic. Summarized as follows: 9.1 Flat bottom When start to print, choose the flat bottom side, because it starts to print from the bottom and then all the layers up, so the bottom decide the whole print quality.
Page 48: Avoiding Overhang
Mytrix Technology - http://www.mytrixtech.com 9.2 Avoiding overhang Because the filament that come out from the nozzle is fluid during printing, it will drop down for gravity reason, if there is any overhang in the printed image, the filament will drop down. Therefore, we need to use software to form a support when print, and remove it after print is done.
Page 49 Mytrix Technology - http://www.mytrixtech.com Overhang should be avoided starting from designing the graphic, 90°overhang can be replaced by upward sloping, or separate the overhang part of the graphic and then stick them all together with glue at a later stage...
Page 51: Assembleing Matching Graphic Tolerance
Mytrix Technology - http://www.mytrixtech.com 9.3 Assembling matching graphic tolerance If the printed object is a graphic needed to be assembled, for example, graphic like screw matching screw cap/toothed gear, because plastic will expand with heat and contract with cold and also the inflated edge of the bottom during printing, the tolerance should be bigger, normally set as 0.4m, it can be set according to the actual graphic.
Page 52: Chapter 10 Faq
Mytrix Technology - http://www.mytrixtech.com Chapter 10 FAQ 1、Q: Got electrical shock when using the machine The machine has a metal cabinet which comes with static electricity, it will not cause harm to human body. The reason why it has static electricity is that the ground filament has not been connected yet.
Page 53: Chapter 11 Notice
Mytrix Technology - http://www.mytrixtech.com unplug the cooling fan of machine. 3、Q：Unable to load the filament A：the reasons could be as follows 1. The temperature has not reached the best melting point of the filament. Adjust the temperature, usually to increase.
Page 54: Chapter 12 Maintanence
Mytrix Technology - http://www.mytrixtech.com 3. Do not touch the nozzles and heating plate in the process of printing or when they are still hot, to avoid injury. 4. Do not repair, modify, dismantle the 3D printer, nor remove screws, it may cause warranty invalidation.
Page 55 Thank you for reading this, if you have any further question, please feel free to call Mytrix Technology service hotline: +1-603-310-9188, or email us: info@Mytrixtech.com, our engineers will provide profession assistance. 2014 Mytrix Technology...
Page 56 Mytrix Technology - http://www.mytrixtech.com Thank you for choosing Dreamweaver 3D printer! Print and Prosper! Website: www.mytrixtech.com Technical support hotline: +1-603-310-9188 Contact email: info@Mytrixtech.com Mytrix Technology Address: 548 Donald St. Ste.3, Bedford, NH 03110 USA 2014 Mytrix Technology All rights reserved Third Version...
