- Page 1 DEMONTAGE DU SUPPORT / FER A VAPEUR DISASSEMBLING THE SUPPORT / STEAM IRON Equipement nécessaire / Necessary equipment Tournevis plat Flat screwdriver Tournevis Torx T20 Torx T20 screwdriver GV67…. 01/12/2015 1/10 EFFECTIS...
- Page 2 DEMONTAGE DU SUPPORT / FER A VAPEUR DISASSEMBLING THE SUPPORT / STEAM IRON Démontage du fond / Disassembly the bottom Dégager le cordon / Extricate the cord GV67…. 01/12/2015 2/10 EFFECTIS...
- Page 3 DEMONTAGE DU SUPPORT / FER A VAPEUR DISASSEMBLING THE SUPPORT / STEAM IRON Démontage du support / Disassembly the support Emplacement des clips sur produit. Location of clips on product. GV67…. 01/12/2015 3/10 EFFECTIS...
- Page 4 DEMONTAGE DU SUPPORT / FER A VAPEUR DISASSEMBLING THE SUPPORT / STEAM IRON Accès aux clips / Access to the clips Accès aux clips au fond du boîtier. Access to clips in the bottom of the housing. Détail des clips (photo réalisée sans le boîtier decommande) Details of clips (photo taken without the control panel) GV67….
- Page 5 DEMONTAGE DU SUPPORT / FER A VAPEUR DISASSEMBLING THE SUPPORT / STEAM IRON Déverrouillage des clips / Unlocking the clips GV67…. 01/12/2015 5/10 EFFECTIS...
- Page 6 DEMONTAGE DU SUPPORT / FER A VAPEUR DISASSEMBLING THE SUPPORT / STEAM IRON Déverrouillage des clips / Unlocking the clips GV67…. 01/12/2015 6/10 EFFECTIS...
- Page 7 DEMONTAGE DU SUPPORT / FER A VAPEUR DISASSEMBLING THE SUPPORT / STEAM IRON Casse des clips possible / Clips can break Risque de casser un clip au démontage. Risk of breaking a clip during disassembly. GV67…. 01/12/2015 7/10 EFFECTIS...
- Page 8 DEMONTAGE DU SUPPORT / FER A VAPEUR DISASSEMBLING THE SUPPORT / STEAM IRON Solution de remontage clip cassé / Broken clip mounting solution Existence de 2 futs de vissage pour vis Ø3x16 pour plastique. Existence of 2 barrels of a bolt for screw Ø3x16 for plastic. GV67….
- Page 9 DEMONTAGE DU SUPPORT / FER A VAPEUR DISASSEMBLING THE SUPPORT / STEAM IRON Solution de remontage clip cassé / Broken clip mounting solution GV67…. 01/12/2015 9/10 EFFECTIS...
- Page 10 DEMONTAGE DU SUPPORT / FER A VAPEUR DISASSEMBLING THE SUPPORT / STEAM IRON Solution de remontage clip cassé / Broken clip mounting solution GV67…. 01/12/2015 10/10 EFFECTIS...
