- Page 1 USER’S GUIDE Installation & Operation Instructions Electromagnetic Flow Meter Model ALIT-BT...
- Page 2 AFLO-Electromagnetic Flow Meter...
-
Page 3: Table Of Contents
AFLO-Electromagnetic Flow Meter INDEX Introduction…………………………………………………………………………………………….3 1.1. Sensor……………………………………………………………………………………………………………………..3 1.2. Transmitter………………………………………………………………………………………………………………..4 2. Technical Specifications………………………………………………………………………….4 3. Technical Drawings ……………………………………………………………………………… 5 4. Wiring ……………………………………………………………………………………………………7 4.1. Compact type Terminal …………………………………………………………………………………………….……7 4.2. Remote type Terminal ……………………………………………………………………………………………………9 5. Digital outputs……………………………………………………………………………………..12 6. Operating…………………………………………………………………………………………….13 6.1.Compact Transmitter Display …………………………………………………………………………………….…13 6.2.Remote Transmitter Display ……………………………………………………………….…………………..……13 6.3. -
Page 4: Introduction
AFLO-Electromagnetic Flow Meter 1. Introduction AFLO electromagnetic flowmeters offer reliable, precise and inexpensive flow measurement on all electrically conductive liquids. Typical applications are found in all industries. E.g.: Water sector: Potable water, treatment of chemicals, waste water and sludge. -
Page 5: Transmitter
AFLO-Electromagnetic Flow Meter 1.2.TRANSMITTER The transmitter consists of a number of function blocks which convert the sensor voltage into flow readings. Figure (2) 2. Technical Specifications Transmitter ≥ 5 μS / cm Fluid conductivity ±0.5% Accuracy Keypad 4 control buttons -20…+60 ˚C... -
Page 6: Technical Drawings
AFLO-Electromagnetic Flow Meter Technical Drawings Figure (3) Figure (4) - Page 7 AFLO-Electromagnetic Flow Meter Dimensions according to Nominal Pressure Value for Remote and Compact Type Figure (5) Dimensions(Pressure 1.6MPa) Dimensions(Pressure 4.0MPa) Weight Pressure 1.6 Mpa Pressure 1.0MPa Pressure 1.0 MPa Pressure 0.6MPa 1015 1002 1115 1050 1075 1020 1107 1000 1230...
-
Page 8: Wiring
AFLO-Electromagnetic Flow Meter 4. Wiring 4.1.Compact type Terminal Figure (6) Output Current for Flow Measurement G: RS232 Communication Ground COM： Output Current (Ground) for Flow Measurement L1：220V（24V）Power Supply P+： Frequency(Pulse) Output for Bi-directional Flow L2：220V（24V）Power Supply COM： Frequency (Pulse) Output (Ground) AL：... - Page 9 AFLO-Electromagnetic Flow Meter Signal lines labels in compact type Figure (7) White twisted-pair cable (for exciting current) 12 Conductors (Red) 12 Conductors (Black) Grey shielded twisted-pair cable 10 Conductors (Red) connected to “Signals 1” 13 Conductors (White) connected to “Signals 2”...
-
Page 10: Remote Type Terminal
AFLO-Electromagnetic Flow Meter 4.2.Remote type Terminal Figure (8) SIG 1 Signal 1 SGND Signal Ground SIG 2 Signal 2 To Separate Model Sensor Shielded Exciting 1 Shielded Exciting 2 EXT+ Exciting Current+ EXT- Exciting Current- VDIN Current two lines 24V Spots... - Page 11 I com Figure (9) output current circuit When DIP switch set to ON, AFLO Transmitter can provide +28V as a power supply and up-pull 10kΩ resistance to output Frequencies (PUL) to isolated OC gate, Alarm Output (ALMH.ALML), and Status Control （INSW）.
- Page 12 AFLO-Electromagnetic Flow Meter Alarm output connection as shown in figure (12) Figure (12) OC gate connection as shown in figure (14) Figure (14) ON/OFF Switch Diagram Key 1 ON: Supply up power (24V) for ALML output. OFF: No connection. Key 2 ON: Pulse output to OC gate when flow verification was taken.
-
Page 13: Digital Outputs
AFLO-Electromagnetic Flow Meter 5. Digital outputs Digital output means frequency output and pulse output, and both of them use the same output point, so user can choose only one type of them not both Digital voltage output connection as shown in figure (15) Figure (15) Photoelectricity coupling (PLC etc.) connection as shown in figure (16) -
Page 14: Operating
AFLO-Electromagnetic Flow Meter 6. Operating 6.1.Compact Transmitter Display + 282.92 Flow volume ×1 Unit ( FLS) Flow velocity + 00000013 . 5 m ∑ ( FQP) Percentage Ratio of emptiness ( MTP) Forward and reverse intergated volumes Alarm Deference of forward and reverse... -
Page 15: Keys Functions
AFLO-Electromagnetic Flow Meter 6.3.Keys function “Down” key: Selecting displayed data on lower line in turn “Up” key: Selecting displayed data on higher line in turn “Compound” key + “Enter” key: Come into parameter setting “Enter” key: Press it to come into selected function Adjust LCD contract using “Compound”... - Page 16 AFLO-Electromagnetic Flow Meter ～1m Pulse Fact Select 0.001m , 0.001L～1L Freque Max Select 1～ 5999 HZ Mtsnsr Ena Select Enable/Disable Mtsnsr Trip Set count 59999 % Alm Hi Ena Select Enable/Disable Alm Hi Val Set count 000.0～ 599.99 % Alm Lo Ena...
-
Page 17: Passwords
300, 1200, 2400, 4800, 9600, 38400, baud rate. 4- Snsr Size AFLO transmitters can be equipped with some different sensors that have deferent diameter of measuring pipes. The pipes in different diameters from 10mm to 3000mm can be chosen in relative table. - Page 18 AFLO-Electromagnetic Flow Meter 8- Flow Direct If users think the direct and design are different, just change the direct parameter is OK, but not change exciting or signal. 9- Flow zero Make sure the sensor is full of fluid, and the fluid is stable. Flow zero is shown as velocity of flow, mm/s.
- Page 19 AFLO-Electromagnetic Flow Meter 13- Output currents Output current types can be chosen by users as 1~10mA or 4~20mA practically. 14- Pulse Type Two kinds of Pulse Outputs can be chosen: Frequency Output and Pulse Output. Frequency Output is continuous square waveform and Pulse output is a serial wave of square wave. Frequency output is mainly used for instant flow and total integrated flow in short time measurement.
- Page 20 Sensor Coefficient Parameter when it runs with converter. 25- Field Type AFLO affords three exciting frequency types: 1/16 frequency (type 1), 1/20frequency (type 2), 1/25 frequency (type 3). The small-bore one should use 1/16 frequency, and large-bore one should use 1/20 or 1/25 frequency.
- Page 21 This coefficient can select the width of time of restrain cuspidal disturb and the unit is ms. If the duration is shorter than flow change in some time, AFLO will think it is cuspidal disturb, and if it is longer, AFLO will think it is natural.
-
Page 22: Alarm Information
AFLO-Electromagnetic Flow Meter 6.6. Alarm information Without trouble of power and hardware circuit, the normal trouble can be alarmed correctly. This information displays on the left side of the LCD, the trouble is like this: FQH ---- Flow high limit alarm ;... -
Page 23: Mounting Conditions
AFLO-Electromagnetic Flow Meter 8. MOUNTING CONDITIONS CAUTION Sensor should always be full with fluid. The direction of flow in vertical pipes must be upward. In case of sensor nominal size is less than pipe size reduction should be done with 8° angle. -
Page 24: Shipping And Storage Conditions
- Humidity must be less than 80% NOTE: Because of AKTEK’s policy of improving their products, the AFLO, would be revised and improved. Please inform us about misunderstandings or errors which you may find in this manual comparing it to the device you bought. Do not hesitate to contact us to suggest how to improve our devices.
