- Page 1 KAKADU INSTALLATION MANUAL WARRANTY sealcom www.kakadu.sealcom.pl...
- Page 2 DESCRIPTION The "KAKADU" bell has been designed for the purpose of meeting the expectations of even the most demanding Users. The applied technical solutions ensure a high functionality of the bell and a wide range of possibilities. selection of signals...
- Page 3 The bell is protected against the "jokers", who block the bell switch-keys in a position "pushed in" for purpose of producing a continuous reproduction of the signal. In the case of such treating the KAKADU bell, the signal will be reproduced only once, and it can be started again only after release and re-pressing the switch-key.
- Page 4 Fig. 1 - BOTTOM installation hole connector J3 (blue) for switching on through short-circut connector J2 (red) for switching on through supplying of the voltage of ~230V installation hole cable holes installation hole 5.Connect the wire of the door bell push-button: a) in the case of the wiring switched on through short-circuit (Fig.
- Page 5 Fig. 2 - COVER holder of the battery hole of the bolt connector for programming button for changing a mode / signal hole for sound regulation Fig. 3 bell bell ~230V door bell door bell push-button push-button a) diagram of the wiring b) diagram of the wiring switched on through switched on through...
- Page 6 OPERATION sound control The changes in the sound level are made using the screwdriver (cruciform). After the small flap has been removed, the end of the screwdriver should be insert into the round hole marked with a symbol of sound control - Fig.
-
Page 7: Technical Data
Reprogramming of the bell (i.e., introducing the different signals) is made with the help of a computer (IBM PC compatible). Necessary software is available on the site www.kakadu.sealcom.pl (free of charge). The computer should be connected to the bell by an appropriate connecting... -
Page 8: Serial Number
1. If your unit needs service during the warranty period, please contact the local authorized distributor for this product. 2. Please ensure to fill out the warranty certificate correctly. SEALCOM reserves the right to refuse the guarantee service if the documents are missing or incomplete in the understanding of this terms.
