Cool Products for Cool Pets!


General Use guidelines
1. Is your pet too heavy for this basket???
a. Body Size and Leg Length are KEY!! ... not your pets weight.
b. Generally pets up to 20 pounds will fit comfortably in the MAX Wicker basket.
2. Please use Caution! The weight of the basket and your pet on the handlebars will change the
steering and braking characteristics of your bicycle.
a. We recommend a few "practice" rides with a weight (close to your pets weight) placed
inside the basket so you can become familiar with braking and steering changes.
3. Never leave your pet unattended inside the basket. Most bicycle kickstands are not designed to
hold your bike upright with a basket and a pet mounted on the handlebars.
page 1 of 4

2019 Pet‐Pilot® MAX Wicker ‐ owners guide























visit travelin‐k9.com to purchase accessories
®
Pet‐Pilot
 MAX Wicker owners guide (rev19‐05b)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pet-Pilot MAX Wicker 2019 and is the answer not in the manual?

Questions and answers

Summary of Contents for TRAVELIN K9 Pet-Pilot MAX Wicker 2019

  • Page 1 Cool Products for Cool Pets!   2019 Pet‐Pilot® MAX Wicker ‐ owners guide                                                 visit travelin‐k9.com to purchase accessories    General Use guidelines  1. Is your pet too heavy for this basket???  a. Body Size and Leg Length are KEY!! … not your pets weight.  b.
  • Page 2 Parts Included ‐ shown below   Some assembly required                                                        Installing the Mount on your handlebars     1. Attach sliding support bar as shown above (loosely tighten both screws).  2. Place both rubber bushings (see above) on handlebars, cut edge forward and centered.  a. Hold mount main body upper clamps in position over rubber bushings.   b. Place (1) galvanized lower clamp tab in appropriate rear slot.  c. Install the threaded bolt for the galvanized lower clamp from the top, through the  hole in the upper clamp (snug but not tight). Repeat for other side.  3.
  • Page 3   Locking (Latching) your Pet‐Pilot on the mount    1. Position both Mount Hooks under the horizontal support bar (in opening on rear of basket).  a. Wicker MAX – ensure 4 vertical wires between hooks  2. Lock the basket to the mount  a. Insert the Latch Hook (in Step‐1) located on the basket handle, with the handle  straight up.  b. Give a slight squeeze to ensure the latch is fully through the latch slot.  3. Rotate handle down (Step‐2) to close and lock the basket to the mount.            Installing the Safety Containment Top (with sunshade)   1. Unbuckle all 4 straps  2. Place the wire top snugly inside the basket (about an inch below the basket rim) and then  wrap the (4) straps over the bottom wire rim … re‐buckle to secure.  3. Sunshade is held in place with 4 velcro strips. This may be removed at your discretion.        WARNING! –  With any cargo loaded in the Pet‐Pilot®, the additional weight on the handlebars will  affect steering and braking ‐ please use caution! Travelin’K9 is not liable for any damage caused by  aggressive, destructive, immature or untrained pets; additionally, Travelin’K9 is not liable for damage  or injury caused by a bicycle operators loss of balance caused by the additional weight of the mounted  basket and/or a pet in the basket, or improper mount installation.   Not intended for long legged (Tall) pets. The Pet‐Pilot has been designed to support smaller,  non‐aggressive pets. Never leave your pet unattended in the Pet‐Pilot. ...
  • Page 4     Looking for additional Accessories?       Extra Mount – for an extra bike?     New Liner?     Extra Safety Tether?    Order these items online at www.travelin‐k9.com      Limited 1‐year warranty ‐    (48 contiguous USA only)   Travelin’K9, Inc. warrants to the original consumer, that this product will be free of  defects for a period of one year from the date of purchase. Travelin’K9’s liability here  under is limited to the replacement of the product only. This warranty is void if the  product has been damaged by accident, unreasonable use, neglect, tampering or other  causes not arising from defects in material or workmanship.  To exercise your warranty: If during the warranty period, your product malfunctions,  return it to the place of purchase with your original receipt. If this cannot be done, return  the product, postage prepaid, to Travelin’K9, Inc. with dated proof of purchase or original  receipt. All returns to Travelin’K9 require an RMA which can be obtained by going to  www.travelin‐k9.com and completing the Return Request Form which provides us the  details of your return request. A response email will be returned to you with the RMA and  return instructions to the email address you provide.        Travelin’K9 Customer Service Help Center  info@travelin‐k9.com  • (309) 550‐7248  610 N. 5  Street, Suite B, Pekin, IL 61554  •   ®...
