- Page 1 RMB45CFBL/SS ECL45CFBL/BL User Guide & Installation & Service Instructions U110868 - 02...
-
Page 2: Table Of Contents
Contents Before You Start... Troubleshooting Before First Use Installation Personal Safety Installation warnings Before the installation Provision for Ventilation Electrical Safety Before the installation Installation and Maintenance Location of the appliance Provision for Ventilation Installation Location of the appliance Automatic cup tray light Cleaning Electrical Connection Overview... -
Page 3: Before You Start
Before You Start... and knowledge if they have been given supervision Thank you for buying a Rangemaster appliance. It should give or instruction concerning use of the appliance in a you many years trouble-free cooking if installed and operated correctly. It is important that you read this section before you safe way and understand the hazards involved. -
Page 4: Electrical Safety
Warning: After the appliance is installed you should Provision for Ventilation make sure you can access the electrical isolation The appliance housing used must provide adequate point. ventilation. Electrical Safety For built-in installation, a minimum ventilation space of 85 – 90mm 40mm must exist between the rear of the appliance The electrical installation must be installed in accordance and the back of the housing or an adjacent wall. -
Page 5: Overview
Overview Fig. 2.1 milk jug Fig. 2.2 12.00 Key: Fig. 2.1 Key: Fig. 2.1 Display screen Drip tray On / Standby Milk / Cream knob Metal drip tray Cappuccino Cream nozzle Tank Latte Coffee nozzle Coffee bean container Espresso Main switch Coffee bean cover Coffee Adjustable mill knob... -
Page 6: Using The Appliance For The First Time
RMB45CFBL/SS Voltage grinding adjustment knob (Fig. 2.3). Proceed one click at a Frequency Power Serial No. AGA Rangemaster Limited time until coffee delivery is satisfactory. Leamington Spa Warwickshire CV31 2AD England NOTE: If the coffee is delivered too fast and the cream is not satisfactory, turn the grinding adjustment knob (Fig. - Page 7 Tips for a hotter coffee To make a small coffee (less than 60 cc), rinse the cup with hot water to preheat the cups. If you need to change the temperature please refer to the "Change the temperature" page 10. •...
- Page 8 Coffee Machine Menus Main Menu Purpose Use powder This mode will force the appliance to make the coffee from the pre-ground coffee container. Hot milk Adjust milk capacity and settings. Hot cream Adjust cream capacity and settings. Sub Menu Menu Brew clean Descale •...
-
Page 9: Setting Water Hardness
Setting water hardness Step 1. Press the "On / Standby" button. If the appliance has not been used for awhile it will rinse. The descale message is displayed after the appliance has been operated for a set period of time, calculated on the basis of the maximum quantity of lime scale which may be SELF CHECK contained in the water used. -
Page 10: Setting The Clock For The First Time
Setting the clock for the first time Changing the time Once the appliance is connected and switched on, the If the clock time needs to be reset or adjusted, please display will start to flash. The clock must be set to the time follow the procedure below. - Page 11 How to change the aroma with coffee beans? Step 1. Press the "On / Standby" button. Step 7. Machine displays SELF CHECK READY Step 2. If the coffee machine has not been used for awhile it will rinse. RINSING Step 3. When the machine displays "READY" press the "Enter" button.
- Page 12 Change the temperature If you want to adjust the temperature of your drink. Please Step 7. Press "Enter" to confirm selection. follow the below steps: SELF CHECK HIGH Step 1. Press the "On / Standby" button. If the coffee machine has not been used for awhile it will rinse. Step 2.
- Page 13 If an extra rinse is required Making coffee using coffee beans If an extra rinse is required follow the process below. This will Step 1. Press the "On / Standby" button. If the coffee force an extra rinse cycle. machine has not been used for awhile it will rinse. NOTE: If the forced rinse cycle does not start, the coffee machine is too hot.
- Page 14 Making espresso with pre-ground coffee (instead of beans) Step 1. Press the "On / Standby" button. If the appliance has Step 6. Open the coffee powder cap. Use the measuring not been used for awhile it will rinse. cup provided. Add one level measure to the powder unit. SELF CHECK Step 2.
- Page 15 Making cappuccino using coffee beans Step 1. Press the "On / Standby" button. If the coffee Step 5. Once the brewing has ended, the appliance will machine has not been used for awhile it will rinse. steam heat the milk. SELF CHECK STEAM HEATING Adjust the aroma, temperature, before making a coffee.
- Page 16 Making latte using coffee beans Step 1. Press the "On / Standby" button. If the coffee Step 5. Once the brewing has ended, the appliance will machine has not been used for awhile it will rinse. steam heat the milk. SELF CHECK STEAM HEATING Note: Latte will take longer to make then cappuccino.
- Page 17 Making Hot milk or Milk froth Step 1. Set up the appliance as shown below. Step 5. Press the "+" or "-" and select either the "Hot Milk" or "Hot Cream". READY HOT MILK milk jug Step 6. Press "Enter", “steam heating” will display. HOT MILK Step 2.
-
Page 18: Changing And Setting The Parameters
Changing and Setting the Parameters Changing the units (not in menu list) Step 1. You can modify the parameters and functions of your appliance. Step 1. Follow the "Changing and setting the parameters" steps. Scroll to "Display" using the "+" button and press SELF CHECK "Enter"... -
Page 19: Setting Auto-Start Time
Setting auto-start time This function mean the machine will come on automatically Step 5. Press the "+" button to scroll to "AUTO ON". to be ready for use. Before use please ensure: • The correct time has been set. AUTO ON •... - Page 20 Step 11. Decrease the minutes. 08.15 Step 12. Press “enter” key which confirms the "AUTO ON". 08.15 NOTE: Do not switch off from the main switch, otherwise it will reset.
-
Page 21: Setting Auto-Off Time
Setting auto-off time Step 1. Press the "standby" button. If the appliance has not been used for awhile it will rinse. After setting the time you have the option to automatically turn off the appliance. Make sure the correct time has been set. -
Page 22: Reset
Reset Step 6. Press "Enter" This feature can be used to restore factory settings. RESET Step 1. Press the "standby" button. If the appliance has not Step 7. Select either YES or NO and press "Enter". been used for awhile it will rinse. SELF CHECK Step 2. -
Page 23: Number Of Use
Number of use Step 6. Press "Enter" The feature can be used to check the number of cycles your appliance has completed, please see full list at the end of this section. INFORMATION Step 1. Press the "On / Standby" button. If the appliance has Step 7. -
Page 24: Language
Language Step 1. Press the "On / Standby" button. If the appliance has not been used for awhile it will rinse. The language can be changed by following these steps. SELF CHECK Step 2. When the appliance displays "READY" press the "Enter"... -
Page 25: Emptying
Emptying Step 6. Press the "Enter" button When the appliance is not in use or to transport to another location we suggest to use this function: EMPTY READY Step 1. Press the "On / Standby" button. If the appliance has not been used for awhile it will rinse. -
Page 26: Cleaning And Maintenance
Cleaning and Maintenance Essential Information Control Panel Allow the appliance to cool and isolate the electricity supply Avoid using any abrasive cleaners, including cream cleaners, before carrying out any thorough cleaning and maintenance. on brushed stainless steel surfaces. For best results use a liquid detergent. -
Page 27: Cleaning The Drip Tray
Fig. 4.1 Water Tank Pre-ground co ee funnel Water Spout Co ee Grounds Container Load Tray Pre-ground Drip Tray Metal Co ee unit Drip Tray Cleaning the drip tray Cleaning the coffee grounds container Important! If the drip tray is not emptied regularly, the water could overflow from the edge and seep Until the ground container has been cleaned, the appliance inside or around the coffee maker. -
Page 28: Cleaning The Infuser/Clean Brew
Cleaning the infuser/clean brew When you make total 300 cup of coffee, the display will show Step 6. Press the "+" button to scroll to "BREW CLEAN". “clean READY”. We recommend to clean the infuser / brew as soon as possible. Propriatary tablets to clean your appliance can be readily purchased. -
Page 29: Manual Operation Of Cleaning The Infuser/Clean Brew
Manual operation of cleaning the infuser/clean brew Step 6. Press the “Enter” button. A cleaning cycle can be completed by following the steps. Propriatary tablets to clean your appliance can be readily purchased. Follow the instructions provided with the tablets. CLEAN READY It is reccomended that following use of a cleaning tablet that the water tank is washed and refilled with fresh water and a... -
Page 30: Cleaning The Water Tank
Cleaning the water tank NOTE: After about 15 coffees. The appliance displays ‘EMPTY GROUND”, indicating that the ground container is full and must Clean the water tank (Fig. 4.1) regularly (about once a be emptied and cleaned. Until the ground container has been month) with a damp cloth and a little mild washing up cleaned the appliance continues to display the message and liquid. -
Page 31: Descaling
Descaling Step 4. The appliance will display “Tray Missing”. Reassemble the appliance after cleaning the drip tray. Important! Descaler contains acids which may irritate the skin and eyes. It is vital to respect the manufacturer’s safety TRAY MISSING warnings given on the descaler pack and the warning relating to the procedure, in the event of contact with the skin and eyes. - Page 32 Step 8. Press “Enter” the appliance will begin to descale. DESCALING Step 9. Add fresh water to the water tank. Return the water tank to its original position. CHANGE WATER Step 10. Press “Enter” the appliance will begin to descale. DESCALING Step 11.
-
Page 33: Troubleshooting
Troubleshooting DocNo.054-0001 - Troubleshooting BI oven Display Message Possible Cause Remedy The water tank is empty or positioned Fill the tank with water and / or insert it Fill Water incorrectly. correctly, pushing it as far as it will go. The grinding is too fine and the coffee is Turn the grinding adjustment knob one Fault 3... - Page 34 Problem Possible Cause Remedy Warm the cups by rinsing them with hot The coffee is not hot The cups were not preheated water The infuser has cooled down because Before making coffee ,heat the infuser 2/3 minutes have elapsed since the last by press rinse coffee was made Turn the grinding adjustment knob one...
-
Page 35: Installation
INSTALLATION Check the appliance is electrically safe when you have finished. Installation Dear Installer • Before using your appliance, wipe all parts with a solution of warm water. Then, rinse with clean water and Before you start your installation, please complete the details dry. -
Page 36: Installation
INSTALLATION Check the appliance is electrically safe when you have finished. This appliance should not be installed in a boat or caravan. The appliance must be installed in accordance with the relevant Building regulations and IET regulations. You will need the following tools and equipment to complete the installation satisfactorily: Electric drill Steel tape measure... - Page 37 INSTALLATION Check the appliance is electrically safe when you have finished. Fig. 6.1 275cm (All dimensions in mm unless otherwise shown)
-
Page 38: Electrical Connection
INSTALLATION Check the appliance is electrically safe when you have finished. Electrical Connection DOUBLE POLE SWITCHED Fig. 6.2 FUSE SPUR OUTLET This appliance must be installed by a qualified electrician to comply with the relevant Institution of Engineering and Technology (I.E.T.) regulations and also the local electricity supply company requirements. - Page 39 INSTALLATION Check the appliance is electrically safe when you have finished. Step 4. Place the coffee machine on the guide runners. Step 1. install guide connect bracket. Fix screws to side of cabinet. Step 2. Fix screws to base of cabinet. Step 4a.
- Page 40 INSTALLATION Check the appliance is electrically safe when you have finished. Take out the tank and fill with water, re-insert in original position. Turn on main switch (E) the appliance will switch on slide back the appliance into the unit. If the appliance is installed over a warmer drawer (500W max allowed).
-
Page 41: Circuit Diagram
Circuit Diagram CON4 CON3 CON6... -
Page 42: Technical Data
RMB45CFBL/SS Model identification ECL45CFBL/BL Volume (water tank) Litres Pump max pressure Bars Maximum total electrical load at 220-240 V~50/60 Hz 1300-1500 W Fig. 8.1 RMB45CFBL/SS Model Voltage Frequency Power Serial No. AGA Rangemaster Limited Leamington Spa Warwickshire CV31 2AD England... -
Page 43: Warranty/After Sales Service
Warranty/After Sales Service DocNo.111-0003 Warranty No.10 If consultation or technical assistance is needed, please provide the local authorised service agent with the purchase invoice and the product code/serial number. The 2 years free maintenance for the operation of the appliance started from the date of purchase of this product. Any cosmetic damage to the appliance must be reported within 90 days of delivery. - Page 48 Clarence Street, Royal Leamington Spa, Warwickshire, CV31 2AD, England. Tel: +44 (0) 800 8046261 E-mail: consumers@agarangemaster.co.uk...
