QLF 315- B 2
INSTRUCTION MANUAL
If you have any questions along the way, just give us a call.
P: +31 (0) 495 580 852 • UK: 0800 056 2853 • AUS: +61 (0) 7 3299 7000
For HeightFinder
Scan or visit san.us/2744
Texto en español, página 16
Texte français page 19
Let Us Help
, MountFinder
Deutscher Text Seiten 22
Nederlandse tekst op pagina 25
and Mount Info,
Svensk text sida 28
Русский текст: стр. 31
日本語は 34 ページ
中文文字说明请参见第 37 页

Advertisement

loading
Need help?

Need help?

Do you have a question about the QLF315-B2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Secura QLF315-B2

  • Page 1 QLF 315- B 2 INSTRUCTION MANUAL Let Us Help If you have any questions along the way, just give us a call. P: +31 (0) 495 580 852 • UK: 0800 056 2853 • AUS: +61 (0) 7 3299 7000 For HeightFinder , MountFinder and Mount Info,...
  • Page 2 This mount is NOT compatible. 80 lbs. with the maximum weights indicated. Use with products weigh MORE than Visit secura-av.com or heavier than the maximum weights indicated may result call P: +31 (0) 495 580 852 (36.2 kg) in collapse of the mount and its accessories, causing 80 lbs.
  • Page 3 Dimensions in. [mm] TV INTERFACE 24.43 620.4 0.33 16.93 430.0 1.02 3.94 26.0 100.0 WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 15° 0.33 6.30 160.0 8.88 7.78 10.02 25 ° TO 45° 225.5 197.5 254.5 16.00 10° 14.21 406.4 360.9...
  • Page 4 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;...
  • Page 5 STEP 2 Parts and Hardware Lag Bolt 5/16 x 2¾ in. (qty. 4) Washer (Lag Bolt) (qty. 4) 5/16 in. Wall Plate Assembly For concrete installations ONLY (qty. 1) CAUTION : Do not use in drywall or wood Concrete Anchor (qty.
  • Page 6 STEP 1 Attach Brackets to TV 1.1 Select TV Screw Diameter 1.2 Select TV Screw Length and Spacers Only one screw size fits your TV. NO SPACER SPACER NEEDED • Flat Back TV • Flat Back TV • Rounded or with Irregular Back TV Extra Space Needed...
  • Page 7 1. 3 Attach TV Brackets to Your TV Level and center your TV brackets over your TV's mounting hole pattern, and install using the screw combination you selected. CAUTION: Avoid potential personal injuries and property damage! DO NOT use power tools for this step. Tighten the screws only enough to secure the TV bracket to the TV.
  • Page 8: Wood Stud Installation

    Attach Wall Plate STEP 2A Wood Stud Installation CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall, must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1½ x 3½ in. (38 x 89 mm) ●...
  • Page 9 CAUTION: Avoid potential injuries or property damage! Improper use could reduce the holding power of the lag bolts Do not over-tighten the lag bolts Go to STEP 3 on PAGE 12. THIS SIDE UP 2¾ in. (70 mm) 7/32 in. (5.5 mm)
  • Page 10 Attach Wall Plate STEP 2B Solid Concrete or Concrete Block Option CAUTION: Avoid potential personal injury or property damage! ● Mount the wall plate assembly directly onto the concrete surface ● Minimum solid concrete thickness: 8 in. (203 mm) ● Minimum concrete block size: 8 x 8 x 16 in.
  • Page 11 CAUTION: Avoid potential injuries or property damage! Improper use could reduce the holding power of the lag bolts Do not over-tighten the lag bolts THIS SIDE UP...
  • Page 12: Step 3 Attach Tv To Wall Plate

    STEP 3 Attach TV to Wall Plate HEAVY! You may need assistance with this step. CAUTION: Avoid potential personal injuries and property damage! TV brackets must be centered AND span the faceplate of wall plate assembly...
  • Page 13 IMPORTANT: You may need to back out locking screws to allow the TV brackets to rest flat against the wall plate assembly CAUTION: Avoid potential personal injury or property damage! Locking screws must be tightened BEHIND wall plate assembly to secure the TV in place .
  • Page 14 TV Adjustments TILT ADJUSTMENT To adjust the tilt level of your TV, loosen the tilt adjustment knob , adjust the TV to the desired tilt angle and retighten the tilt adjustment knob NOTE: Once your TV is in place, tighten the tilt adjustment knob to prevent unwanted movement.
  • Page 15 REMOVING THE TV HEAVY! You may need assistance with this step.
