- Page 1 QLT 25 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-800-359-5520 We’re ready to help! Scan for easy install video san.us/1144...
- Page 2 Use with products Yes? This mount is NOT compatible. weigh MORE than heavier than the maximum weights indicated may result Visit secura-av.com or (49.8 kg) call 1-800-359-5520 in collapse of the mount and its accessories, causing 110 lbs. (49.8 kg) ? (UK: 0800 056 2853) to fi...
- Page 3 Dimensions TV INTERFACE 7.87in .59in [200mm] [15mm] 1.81in [46mm] 15.98in [406mm] 23.62in [600mm] WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 5° 8° 24.17in 10° [614mm] 8.03in 6.22in [204mm] [158mm] 5.07in 8.74in [222mm] [129mm] 3.60in 16.06in .35in [91.3mm] [408mm] [9mm] 25.59in...
-
Page 4: Parts And Hardware
Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used. - Page 5 Parts and Hardware for STEP 2 Lag Bolts 5/16 x 2¾ in. Wall Plate Lag Bolt Washers 5/16 in. For concrete installations ONLY CAUTION : Do not use in drywall or wood Concrete Anchors Fischer UX 10 x 60R...
- Page 6 STEP 1 Attach Brackets to TV 1.1 Select Angle of TV Tilt Using the preattached angle brackets, TV can be set to either a 10° or 8° tilt. 10° Tilt 8° Tilt...
- Page 7 For no tilt, remove the preattached angle brackets. 5° Tilt For 5° tilt, remove the preattached angle brackets, rotate the brackets as shown and reattach the brackets. 0° Tilt...
- Page 8 Standard configurations 1.2 Select TV Screw Diameter 1.3 Select TV Screw Length are shown. For special applications, or if you Hand thread screws into the threaded inserts If your TV has a flat back AND you want your TV closer to are uncertain about your on the back of your TV to determine which the wall, use the shorter screws (a).
- Page 9 1.4 Attach TV Brackets Ensure that your brackets are level and centered on the back of the TV. Install using the TV screw/washer/spacer confi guration you selected for your TV. CAUTION: Avoid potential personal injuries and property damage! DO NOT use power tools for this step. Tighten the screws only enough to secure the TV bracket to the TV.
- Page 10 STEP 2A Attach Wall Plate to Wall Wood Stud Option CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall, must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm) ●...
- Page 11 Drill pilot holes using a 7/32 in. (5.5 mm) diameter drill bit. IMPORTANT: Pilot holes must be drilled to a depth of 2¾ in. (70 mm). Be sure to drill into the center of the studs. Install wall plate using four lag bolts and four washers .
- Page 12 STEP 2A Attach Wall Plate to Wall Solid Concrete or Concrete Block Option CAUTION: Avoid potential personal injury or property damage! ● Mount the wall plate assembly directly onto the concrete surface. ● Minimum solid concrete thickness: 8 in. (203 mm) ●...
- Page 13 Insert four anchors CAUTION: Be sure the anchors are seated flush with the concrete surface. Install wall plate using four lag bolts and washers . Tighten the lag bolts only until they are pulled firmly against the wall plate. CAUTION: Improper use could reduce the holding power of the lag bolt.
-
Page 14: Step 3 Attach Tv To Wall Plate
STEP 3 Attach TV to Wall Plate Hang TV/bracket assembly onto wall plate using predetermined angle (Step 1.1 pages 6-7), then lower the bottom of the TV in place. IMPORTANT: You will hear an audible click when the TV bracket is securely fastened to the wall plate. HEAVY! You may need assistance with this step. - Page 15 Adjustments HEAVY! You may need assistance with this step. To remove the TV from the wall plate, pull down on the release straps, and then lift the TV up and out away from the wall.
- Page 16 Thank you for choosing Secura! Please take a moment to let us know how we did: Email us: info@secura-av.com Call us: 1-800-359-5520 UK: 0800 056 2853 Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations.
