Light Drive²
B e n o i t S y s t è m e s
7 r u e d u P o n t , 2 1 4 5 0 B i l l y - l è s - C h a n c e a u x

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Light Drive 2 and is the answer not in the manual?

Questions and answers

Related Manuals for BENOIT SYSTEMS Light Drive 2

Summary of Contents for BENOIT SYSTEMS Light Drive 2

  • Page 1 Light Drive² B e n o i t S y s t è m e s 7 r u e d u P o n t , 2 1 4 5 0 B i l l y - l è s - C h a n c e a u x...

  • Page 2: Table Of Contents

    I. CONTENTS I. CONTENTS II. OVERVIEW A. L IGHT RIVE B. B , 12A , 18A ATTERY H AND C. A D. C ONTROL III. CENTRAL UNIT AND NOMENCLATURE IN DETAIL A. C ENTRAL UNIT AND ELECTRONICS UNIT B. M OTOR MODULE C.

  • Page 3: Overview

    II. OVERVIEW A. Light Drive Update : 28/11/2018 Index : 03 Version : 00...

  • Page 4: Battery Rack 9Ah, 12Ah, 18Ah And 24Ah

    B. Battery Rack 9Ah, 12Ah, 18Ah and 24Ah C. Anti-tip D. Control Update : 28/11/2018 Index : 03 Version : 00...

  • Page 5: Central Unit And Nomenclature In Detail

    III. CENTRAL UNIT AND NOMENCLATURE IN DETAIL A. Central unit and electronics unit Central unit Ref. Qty / unit Name 282-000 Light Drive² central unit with NVR2 electronics 285-000 Light Drive² central unit with VR2 electronics (dual attendant control) Central unit and electronics unit exploded view Update : 28/11/2018 Index : 03 Version : 00...
  • Page 6 Central unit and electronics unit nomenclature Num. Ref. Qty/unit Name 270-015 NVR2 plastic cover 210-080 NVR2 electronics unit 210-020 VR2 electronics unit (compatible with dual attendant control) A00-118 M4x20 flat head screw A00-395 Spacer Ø6 length 30 A00-136 M6x45 flat head screw 210-030 50A power cable 000-630...

  • Page 7: Motor Module

    B. Motor module Light Drive² motor module Ref. Qty/unit Name Complete 24V 71,5W motor with brake 423-000 40 mm polished cup Complete 24V 130W motor with brake 475-000 40 mm polished cup Light Drive² motor without cup nor roller cover Picture Reference Name...
  • Page 8 Motor module exploded view and nomenclature Qty / Num. Reference Name unit 400-056 Roller cover base 400-045 400-030 Ø20 motor roller 400-052 Polished roller cover 000-190 608 motor bearing 400-042 Polished roller cover cap 400-026 40 mm polished motor cup 000-400 Stainless steel M4x16 cap screw 000-410...

  • Page 9: Right Clutch Collar Module

    C. Right clutch collar module Qty / Ref. Name Width Colour unit 310-000 25 mm 310-210 25 mm Blue Right clutch collar 310-410 25 mm Gold 310-510 25 mm Lime Right clutch collar module exploded view (in 2 parts) Update : 28/11/2018 Index : 03 Version : 00...
  • Page 10 Right clutch collar exploded view nomenclature Num. Reference Qty/unit Name 310-090 Right main collar 25mm width A00-068 M5x16 flat head screw 300-090 Axle washer Red 300-091 Axle washer Blue 300-093 Axle washer Gold 300-094 Axle washer Lime A00-154 Spacer Ø6 000-690 Washer Ø6 A00-135...

  • Page 11: Left Clutch Collar Module

    D. Left clutch collar module Qty / Ref. Name Width Colour unit 320-000 25 mm 320-210 25 mm Blue Left clutch collar 320-410 25 mm Gold 320-510 25 mm Lime Left clutch collar module exploded view (in 2 parts) Update : 28/11/2018 Index : 03 Version : 00...
  • Page 12 Left clutch collar exploded view nomenclature Num. Reference Qty/unit Name A00-094 M4x20 flat head screw 320-072 Couvercle Entretoise de Butée Réglable 320-073 Anti-swing stop spacer 320-070 Anti-swing stop 320-080 Small anti-swing stop 320-090 Main left collar 25mm width A00-154 Spacer Ø6 000-690 Washer Ø6 A00-135...

  • Page 13: Central Tube Module

    E. Central tube module Motor tube module Composed of 2 motor tubes and 1 central tube Dimension Name Motor tube reference (mm) 340<L<400 2 X 140 mm motor tubes 100-114 400<L<510 2 X 170 mm motor tubes 100-117 510<L<630 2 X 220 mm motor tubes 100-122 Central tube colours Colour...

  • Page 14: Controller Bracket Fixation And Joystick Support Module

    Controller bracket fixation and joystick support module Joystick support module Num. Ref. Qty / unit Name 240-121 Right side hand rest 240-126 Left side hand rest 240-065 5 position plate 240-027 T1 joystick swivel support 000-525 M5x10 button head screw 240-051 250mm joystick extension 240-056...
  • Page 15 Controller bracket + fixation module Num. Reference Qty/unit Name 000-525 M5x10 button head screw 240-090 Mobile axle A00-122 M5x25 cap screw 000-020 Washer Ø5 A00-074 M5x20 flat head screw 000-520 M5x20 button head screw A00-100 M5x25 flat head screw A00-118 M5x25 button head screw A00-505 M5x8 low head screw...

  • Page 16: Joystick

    G. Joystick Qty / Ref. Name unit VR2 joystick (compatible with 210-040 dual attendant control) 210-050 VR2 joystick cable 210-060 NVR2 joystick 210-095 NVR2 joystick cable Ref. Name Dual attendant control command (only 770-030 compatible with VR2 electronics unit and joystick) Dual attendant control (L plate, controller 770-035...

  • Page 17: Lithium Battery Rack 9Ah, 12Ah, 18Ah And 24Ah

    H. Lithium Battery Rack 9Ah, 12Ah, 18Ah and 24Ah Ref. Qty / Unit Name 570-000 12Ah Lithium rack 574-000 9Ah Lithium rack 571-000 18Ah Lithium rack 572-000 24 Ah Lithium rack Update : 28/11/2018 Index : 03 Version : 00...
  • Page 18 Lithium rack exploded view Num. Reference Qty/unit Name Lithium rack electric cable (connected to the 570-045 red connector) A00-091 M4x16 button head screw 570-020 ST battery case cover 2mm 570-008 9Ah battery case 570-005 12Ah battery case 570-006 18Ah battery case 570-007 24Ah battery case Wedging rubber...

  • Page 19: Charger

    Charger Ref. Qty / Unit Name 500-051 Light Drive² charger (Euro/France) 500-052 Light Drive² charger (UK/EIRE) 500-053 Light Drive² charger (US/CAN) 500-054 Light Drive² charger (AUS) Num. Reference Qty/unit Name 000-200 50A connector 500-070 50A connector handle 500-080 XLR 3 pin plug 500-090 Charger power cord type C (Euro) 500-091...

  • Page 20: Car Charger

    Car charger Ref. Qty / Unit Name 500-067 Car charger for Lithium battery Num. Reference Qty/unit Name 000-200 50A connector 500-070 50A connector handle Lighter socket Update : 28/11/2018 Index : 03 Version : 00...

  • Page 21: Anti-Tip Module

    Anti-tip module Ref. Qty / Unit Name 600-051 Complete castor tube - Blue 600-052 Complete castor tube - Grey 600-053 Complete castor tube - Lime 600-054 Complete castor tube – Gold 600-055 Complete castor tube - Red 600-056 Complete castor tube - Pink 600-057 Complete castor tube - Black 600-061...
  • Page 22 Anti-tip exploded view Num. Reference Qty/unit Name 600-034 Conical guide 600-031 Spring lock (available soon) 600-136 130° anti-tip tube - grey 600-167 130° anti-tip tube - black 600-146 140° anti-tip tube - grey 600-147 140° anti-tip tube - black 600-032 Anti-tip ring 600-033 EAVP25 black plug...

  • Page 23: Installation Components And Spare Parts

    IV. INSTALLATION COMPONENTS AND SPARE PARTS A. Installation components Picture Ref. Name 720-010 Multi position L plate Multi position large L plate 720-020 Large L plate (Invacare Action 720-030 for example) 720-040 Simple plate 720-055 RGK plate 720-085 Spin X plate 720-090 Panthera plate Update : 28/11/2018...
  • Page 24 Picture Ref. Name 720-060 Small half-moon clip 720-070 Large half-moon clip 720-075 Deep link half-moon clip A00-144 Nut cover 700-300 Hook bar - 300 mm 700-500 Hook bar - 500 mm 700-700 Hook bar - 700 mm 700-050 M6 hook bar nut A00-015 M6x20 headless screw 700-060...

  • Page 25: Hooks

    B. Hooks Mounted hook Ref. Name 700-040 Red mounted hook 700-042 Gold mounted hook 700-043 Blue mounted hook 700-045 Lime mounted hook Mounted hook exploded view Num. Reference Qty/unit Name A00-099 M5x16 CHC screw Hook (see below for colours) 700-030 M5 nut 700-015 Hook plate...

  • Page 26: Wheelchair Accessories

    C. Wheelchair accessories Picture Ref. Name Schwalbe Marathon Plus black 750-010 24’x1 tyre Schwalbe Marathon Plus black 750-035 22’x1 Ø489 tyre Schwalbe Marathon Plus black 750-110 26’x1 tyre 750-120 Schwalbe Marathon Plus black 24’x1 3/8 tyre 750-125 Schwalbe Marathon Plus black 25’x1 tyre 750-045 Schwalbe HS 110...
  • Page 27 Picture Ref. Name 750-115 Inner tube 26’x1 750-015 Inner tube 24’x1 750-025 Inner tube 24’x1 3/8 750-040 Inner tube 22’x1 750-050 Inner tube 22’x1 3/8 750-090 Inner tube 20’x1 750-130 Inner tube 25’x1 750-080 5' castor (125x25) 36 mm fork width 750-060 6’...

  • Page 28: Options

    V. OPTIONS Picture Ref. Name 770-020 PP1 programmer 770-060 Installation gauge 400-095 Mudguard Update : 28/11/2018 Index : 03 Version : 00...

  • Page 29: Joystick Knobs

    VI. Joystick knobs Picture Ref. Name Standard 220-010 30 mm Stick 220-015 80 mm 220-020 Chin Ø 38 mm Mushroom 220-025 Ø 48 mm 220-030 Ball Ø 38 mm Soft ball 220-035 Ø 70 mm « T » bar 220-040 Dim.
