- Page 1 Sous Vide...
- Page 2 Features Product Parameters Button Icon Instruction Inkbird Smart APP (ISV-100W model support) Notes...
- Page 3 Features Precise Control of Temperature Precise Control of Time Dot matrix LCD display, with a recipe to guide the temperature and time Intelligent humanization and support WiFi (ISV-100W) Warranty: 1 year Product Parameters Input power(USA):120v 60Hz Length of the Cable:1.2m LCD: (W)36mm*(L)42mm ,128*128 Dot Matrix LCD Heating Power:1000W...
- Page 4 Temperature Controlling Accuracy:0.1℃ Range of Time Setting:Max 99 hours 59 minutes Time Setting Minimum Interval:1 minute Reminder:There will be hint tone when reaching the target temperature and temperature control target time； Water Shortage Protection:When the water level is lower than the minimum water level, it will stop working and have an audible alarm Temperature Probe Failure Protection:...
- Page 5 Set button Quickly press:switch temperature and time settings, if on the page of recipe guide and configuration, can be used to switch options. Long press (3s):enter the page of recipe guide; in addition, you can save the config- uration and exit on the configuration page. -/cfg button Quickly press:set the temperature and time for decrement adjustment...
- Page 6 Run stop button Start and stop button, the top left of the LCD shows the current working state. Inkbird Smart APP (ISV-100W model support) 4.1. Download the APP Search the keyword ‘InkbirdSmart ’ in Appstore or Google Play, or scan the following QR code to download and install the APP.
- Page 7 4.2. Pair with your phone Open the app, it will ask you to register or log in your account on the APP. Select the country and enter your Mobile number or Email to finish the registration. Then press “Add Home” button to create your home. Tap “+”...
- Page 8 If the device is in the normal working state, you can long press 5 seconds to reset the WIFI. It will enter the Smartconfig configuration state by default. You can quickly press to switch the Smartconfig configuration state and the AP mode. If you change the WIFI state, it will take about 5 seconds to display the corrspond ing LCD symbol and state, because of the...
- Page 9 Add device in AP mode: Plug the device in the socket and make sure that the device is in the AP Configu ration State (the LCD symbol is flashing slowly, interval flashing 1500ms). Click “AP mode” to enter device adding interface,click “Confirm indicator slowly blink”...
- Page 10 WLAN Setting in your smart phone, select the “SmartLife-XXXX” to directly connect to the router without putting in password. Go back to app to enter into the automatic connection interface. Click “Done” after adding device succeed ed and enter into device controlling inter face .
- Page 11 App icon Device Name recipe Working status: In preparation, cooking, completion, total three states, in addition, water level alarm and probe Current alarm will also be Temperature displayed here. Remaining cooking time Click on the configuration page to switch between temperature units and corrected temperatures.
- Page 12 "MAX" scale line of the stainless steel part. Please disconnect the power when not in use or before cleaning. If the Sous Vide falls into the water, please disconnect the power as soon as possible to avoid electric shock. If this happens,...
Need help?
Do you have a question about the Sous Vide and is the answer not in the manual?
Questions and answers
How do I connect my InkBird ISV 100watt to the personal hotspot on myiPhone?
The Inkbird ISV-100W sous vide device only supports 2.4GHz Wi-Fi networks. iPhone personal hotspots typically use 5GHz by default, which is not compatible. To connect it using an iPhone hotspot:
1. Go to iPhone Settings > Personal Hotspot.
2. Change the hotspot to use 2.4GHz (if your iPhone allows changing the band).
3. Turn on the hotspot and note the name (SSID) and password.
4. Plug in the sous vide device and ensure it is in Smartconfig mode (LCD symbol flashes rapidly, 250ms interval).
5. Open the InkbirdSmart app.
6. Tap "+" or "Add device."
7. Select the 2.4GHz hotspot network, enter the password, and follow prompts to connect.
If the device does not support connection through a hotspot or the iPhone does not allow 2.4GHz configuration, it may not work.
