Summary of Contents for Oblica ARGOS
-
Page 1: Table Of Contents
Technical DaTa insTallaTion operaTe The argos safeTy rules cerTificaTion... -
Page 2: Technical Data
ø532mm Dimensions flue sections Double skin 175/225mm roof/ceiling penetration Triple skin 275mm fuel Wood / 400mm long log max (or 500mm upright) Modes of use ignition / normal rate / slow combustion oblica | argos model specifications page 2... -
Page 3: Installation
100mm (as per Bca regulation). floor protector. if the argos is to be installed on top of a combustible surface (e.g. Timber floor), a floor protector must be placed directly underneath the argos. The floor protector shall be made of heat resistant material (e.g. steel, cement sheet, tiles, glass…) and shall extend not less than 300mm from the front and 200mm from the side of the base. - Page 4 (indicator no. 2 on sketch). step let the front of the deflector sit on the front stops (indicator no. 3 on sketch). stops oblica | argos model specifications page 4...
-
Page 5: Operate The Argos
30 minutes to avoid overheating damage. The appliance must be attended during the whole duration of operation in this position. oblica | argos model specifications page 5... - Page 6 (make sure air vents aren’t obstructed too much). Warning: ignition position only to be used during ignition (30 min max). the appliance must be attended during the whole duration of operation in this position! oblica | argos model specifications page 6...
- Page 7 6 to 8 kg load of large hard un-split wood and by totally shutting the heat control. first carry out a reduced heat control regime by shutting the heat control and then load over a very low reddish ember bed. oblica | argos model specifications page 7...
-
Page 8: Safety Rules
The use of fuels that are not recommended or unsuitable for the stove are forbidden, including liquid fuels. The combustion chamber must always remain closed, except during reloading and removing ash. never overheat the stove. using the stove as an incinerator is forbidden. oblica | argos model specifications page 8... -
Page 9: Certification
The argos has been Tested and approved under as/nZs standards as per below: laBoratory: Vipac engineers & scientist 279 normanby rd, port Melbourne Vic 3207 (03) 9647 9700 Vipac is a naTa accredited laboratory. registration number: 676.
