Fusionadora de mano
ES
Hand-held fusion splicer
EN
Fusionneuse de poche
FR
Giuntatrice palmare
IT
Handspleißgerät
DE
Spawarka podręczna
PL
Ref. 232130, 232131
Manual de Instrucciones
Operating instructions
Manuel d'utilisation
Manuale d'utilizzo
Bedienungsanleitung
Instrukcja obsługi
w w w . t e l e v e s . c o m
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Televes 232130
Summary of Contents for Televes 232130
- Page 1 Ref. 232130, 232131 Manual de Instrucciones Fusionadora de mano Operating instructions Hand-held fusion splicer Manuel d’utilisation Fusionneuse de poche Manuale d’utilizzo Giuntatrice palmare Bedienungsanleitung Handspleißgerät Instrukcja obsługi Spawarka podręczna w w w . t e l e v e s . c o m...
-
Page 3: Table Of Contents
Hand-held fusion splicer Ref. 232130, 232131 Contents General Information ............... . . - Page 4 You should immediately remove the power supply adap- tor and turn the fusion splicer off, if it happened to be turned on. Then, contact Technical Support of Televes in order to proceed with its inspection or repair. Internal manipulation of the fusion splicer involves loosing the product warranty (do not take the equip- ment apart).
-
Page 5: General Information
Warning Televes reserves the right to modify the product without due notice. Under no circumstances shall Televes be held responsible for damages or harm of any nature, that could derive from this manual or the information contained in it. -
Page 6: Fusion Splicer
Hand-held fusion 2. Fusionadora 2. Fusion splicer: Front view: Cover Over LCD screem SD card port USB port Top view: Cover Fibre clamp LCD screen keyboard Oven External changer connection... -
Page 7: Keyboard
3. Keyboard 4. Use Basic guide The keyboard has only 3 buttons, enough for handling all of the equipment’s functions and menus. NOTE: This is a basic guide to start using the fusion splicer. The keyboard operation will depend on the working mode. Should you encounter any problems or wish to see the processes in detail, please refer to section 7 of On top of each button, the fusion splicer screen will display... - Page 8 Hand-held fusion Fusion Place the fibre in the heads (250 μm on the black bracket and 900 μm on the blue bracket). The fibre should stick out around 3 or 4 cm. Both fibre ends should be visible on the screen: Do not forget to put some heat-shrink tubing on one of the fibre ends before starting.
-
Page 9: Main Menu
5.Main menu To access the main menu, push “MENU” on the initial screen. To go through the menu options, use the up and down buttons. Select the desired option by pushing the “SELECTION” button. 5.1 Electrode cleaning Run the “ELECTRODE CLEANING” programme to get rid of dirt and impurities on the electrodes. - Page 10 Hand-held fusion 5.4 Settings Put the fibre directly on the V-groove (V-shaped groove) without fibre head (see image) and shut the fibre clamp. The settings menu displays the following functions (see section 6, “Configuration”, for further details): Fibre selection Set time Oven Language Fibre position...
-
Page 11: Configuration
6. Configuration In order to configure the different parameters of the fusion splicer, we need to access the “SETTINGS” menu. 6.3 Oven Adjust the oven operation duration by pushing “UP” and “DOWN”. Push “SELECTION” to choose the new value, or go to the top and select “EXIT”... - Page 12 Hand-held fusion 6.6 Electrodes The “ELECTRODES” menu has the following options: 6.5 Fibre position This option helps us calibrate fibre positions when they are not in the correct position on the V-groove (V-shaped gro- ove). ““ADJUST”. In order to adjust the electrodes, you need to have a single stripped fibre on both V-grooves (shut the fibre clamp).
- Page 13 6.7 Auto mode 6.9 Pause fusion When this function is selected, the fusion splicer will pau- When this function is activated, the fusion splicer will start se and display the fibre angles before proceeding with the the fusion operation by just shutting the cover (no need to fusion;...
-
Page 14: Advice For The Appropriate Handling Of Fibre
Hand-held fusion 7. Advice for the appropriate handling of fibre Incorrect fibre handling or preparation often produces bad quality splices. One key aspect is working with very clean tools, fibre and materials. The time spent in learning the correct handling of both fibre and tools is largely made up by the reduction in the effort required to solve an incident. - Page 15 Correct La fibra se cortará y obtendrá una fibra con un corte a 90º . Abra la tapa y retire la fibra. 7.6 Placing the fibre Put the cut and ready fibres in the splicer; to do so: 1.- Open the fusion splicer main cover and lift the fibre clamp.
-
Page 16: Cleaning
Hand-held fusion 8. Equipment cleaning Should the estimated loss be equal or higher than 0.1 dB (loss highlighted in red), fusion would be incorrect, and the whole fusion process should be repeated from the start. 8.1 Cleaning the splicer’s V-shaped groove (V-gro- ove) The V-groove’s high-precision surface is very sensitive and should be kept clean. -
Page 17: Sd Card
9. SD Card It allows the downloading of the values extracted for each fu- sion to the card (provided the card is inserted). The values can thus be read or extracted into a PC later on. 10. Specifications Manufactured in Europe. Accepted fibre types: SM (9/125 micron, with 250-micron or 900-micron protection), MM (50/125 micron and 62.5/125 mi- cron). - Page 18 televes.com...
