VILTA-M Pro
Stabilizer for Smartphone
User Manual
Freevision Intelligent Technology Co.,Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VILTA-M Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for FreeVision VILTA-M Pro

  • Page 1 VILTA-M Pro Stabilizer for Smartphone User Manual Freevision Intelligent Technology Co.,Ltd.
  • Page 2: Table Of Contents

    Contents Overview Packing List Product Overview Installation App Installation Smartphone Installation and Balance App Connection Start Up Control Panel Introduction App Menu Introduction App Operation Specifications Specifications Parameter Technical Parameter Other Specification Warning Warranty Information...
  • Page 3: Packing List

    OVERVIEW Packing List VILTA-M pro Portable Bag Charging Cable Tripod User Manual Lanyard Warranty Card...
  • Page 4: Product Overview

    OVERVIEW Product Overview Smartphone USB-A Mounting Holder Charging Port Wireless Charging Tilt Axis Adjustable Arm Roll Axis Balance Roll Axis Buckle Adjustment Knob Pan Axis Connection Indicator LED Scene Mode Switch Status Indicator LED Camera Parameter Adjustment Wheel Power Button Focus/Zoom Wheel OK/DISP Button Focus/Zoom Button...
  • Page 5: App Installation

    Installation App Installation Download FV Share App For Android users, please search FV Share App in Google Play. (Android 5.0 or above) For iOS users, please search FV Share App in App Store.( iOS 9.0 or above) Available on the App Store...
  • Page 6: Smartphone Installation And Balance

    Installation Smartphone Installation and Balance Place the mobile phone in the smartphone mounting holder while pulling the sides of the holder outwards, then release the sides of the holder. It is recommended that you position the mobile phone close to the tilt axis. Turn the mobile phone over facing downwards, adjust the position of the phone in the holder to balance the tilt axis(refer to the picture below) and then tight up the balance adjustment knob.
  • Page 7 Installation Manually rotate the phone holder to switch between horizontal and vertical screens.
  • Page 8: App Connection

    Power Button App Connection FV Share Connection For Android users, please turn on GPS) Power on VILTA-M Pro Open FV Share Tap Connect to Gimbal and choose your gimbal to connect. After successfully connecting, the blue connection indicator LED stops flashing and turns solid blue.
  • Page 9 Start Up Operating instructions Shooting Subject Switching Choose two different depth of fields of the shooting subject. Use Focus/Zoom Wheel to choose one of your subjects. Long press the Mark A button to confirm. Use Focus/Zoom Wheel to choose the other subject. Long press the Mark B button to confirm.
  • Page 10 Start Up Mode indicator LED and Mode switch Follow Mode Status Gimbal Mode Button Indicator LED Single tap Yellow Semi follow mode Double taps Full follow mode For quick positioning Three taps of the direction Yellow light Four taps POV mode flashes To lock the current Long press...
  • Page 11 Start Up Record Button Single tap to start/exit recording. Double tap to switch front and rear facing camera. Shutter Button Light press Shutter Button to focus. Deep press Shutter Button to take a photo. Record Button Shutter Button Custom mode Button Default hand following mode, customized flash, white balance and wireless charging power switch.
  • Page 12 Start Up OK/DISP Button When adjusting the camera parameters, single tap OK to confirm the parameters. When viewing the album, single tap OK to confirm the playback. When the APP is on the primary interface display, single tap the DISP button to display the current camera parameters.
  • Page 13: App Menu Introduction

    Start Up App Menu Introduction Due to the limitations of Android phones, VILTA-M Pro Android users will not be able to use all the functions for the time being. Thank you for your understanding and support. Phone Gimbal Camera Settings...
  • Page 14 Preview and storage location of photos and videos. IntelliTrace to turn on IntelliTrace. Tap to turn off IntelliTrace. Frame the subject and VILTA-M Pro will track in real time. Answering a phone when recording or in IntelliTrace, the recording will be automatically stopped.
  • Page 15: App Operation

    1. Tap and choose sport mode in scene mode. 2. Tap to start IntelliTrace. 3. Tap or draw a frame of the subject on your phone screen. VILTA-M pro will intelligently identify and automatically track subject. 4.Tap to start shooting.
  • Page 16 Start Up Time Lapse 1. Tap and choose time lapse. 2. Set shutter interval and time of duration. Tap Start. 3. Tap to exit shooting. Video will be automatically saved to documents. Motion Time Lapse 1. Tap and choose motion time lapse. 2.
  • Page 17 Start Up Slow Motion Video 1. Tap and choose slow motion. 2. Tap to start shooting. Tap to exit shooting. Videos will be automatically saved to documents. Photo/Video Editing 1. Photo Editing Enter App home page and tap at the bottom. to choose the photo and editing ( Filter, Beautify, Adjust, Mosaric, Crop, Paint ) to confirm editing.
  • Page 18 Start Up 2. Video Editing Enter App home page and tap at the bottom. Choose video. to editing (Add Video, Video Editing, Add Music, Filter, Adjust) to confirm editing. Camera Manual Mode iPhone Gimbal Adjust exposure,shutter,ISO, white balance, manual focus and zoom of your phone camera.
  • Page 19: Technical Parameter

    SPECIFICATIONS Technical Parameter 01 Mechanical Rotation Range Tilt 330° Roll 325° 360° unlimited 02 Maximum Control Speed Adaptive Rotation Speed(± 5 0 0 ° / s ) Battery Battery Type Intelligent Lithium Battery Voltage 7.4V Working Current Static: 93mA Dynamic:3.6A Battery Capacity 2000mAH Energy...
  • Page 20: Warning

    Buckles will cause slight wear and tear due to friction during use. Do not expose to fire or high heat. Drop and collision will break VILTA-M Pro. Please use it carefully. Not water-proof. Keep away from liquids or do not clean with liquid detergent.
  • Page 21 Brand Name: FREEVISION Hangzhou Freevision Intelligent Technology Co., Ltd. E-mail: Support@freevisiontech.com Hereby declares that this [Name: VILTA-M Pro, Model: VT30] is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the internet address: www.fvshare.com...
  • Page 22 WARNING FCC Warning This device complies with part 15 and part 18 of the FCC Rules. Operation is subjectto the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 23 2) If the product does not conform to the conditions for free repair, Freevision will assess the problem and cost of repair, the customer has the right to repair or deliver it back. 3) When you receive the repair service, please provide valid purhase proof and this warranty card.
  • Page 24: Warranty Information

    Warranty Information The customer is at first required to pay the product return delivery free. After Freevision after-sale service center receives the product, it will un dergo a test. If the product does not conform to the conditions for free repair, Freev ision will assess the problem and cost of repair, the customer has the right to repair or deliver it back.
  • Page 25 WARRANTY INFORMATION Customer Information Name: Tel: Zip Code: Email: Address: Dealer Information Name: Tel: Zip Code: Email: Address: Product Information Item No. Product Code: Purchase Date:...
  • Page 26 WARRANTY INFORMATION Warranty Card...
