Summary of Contents for Linea Plus FD10-5037BR5
- Page 1 DEHUMIDIFIER Operation instruction FD10-5037BR5(-1) Model FD12-5037BR5(-1)
- Page 2 Precautions CONTENTS Please read "Precautions" carefully before operating your dehumidifier. The warnings and the cautions stated in "Precautions" must be observed for safe operation. Warning means improper handling may result in a death or a serious injury to a person. Cautions means improper handling may result in an injury or damage to properties.
- Page 3 To avoid damages to the power cord, do not pinch the cord in a door. Prohibit Do not use the dehumidifier outside. Exposure to direct sunlight or rain Never put rods or objects into the openings of the dehumidifier. Because this Prohibit may result in overheating, electric shock and fire.
-
Page 4: Operation Panel
Operation panel Select proper functions Lower the indoor humidity to a comfortable humidity. Indoor humidity or prevent condensation and mildewing on the ceiling or wall. Dehumidify for the wardrobe Timing SPEED TIMER MODE CHILD SLEEP Small space dehumidification LOCK Mode Schalter Indoor air filtration... -
Page 5: Part Names And Functions
Part Names and Functions Operation and efficiency Defrosting operation Back Front The evaporator in the dehumidifier may defrost automatically if it is operated in the room temperature less than 18 C. The defrosting device may start up and operate for some time (about 5 minutes) Power switch automatically every 25 minutes or even longer. - Page 6 Operation manual Preparations and inspection while beginning the operation Confirm the tank is installed in position. 1. Power Button: This button can control the machine on and off; The dehumidifier can't operate if the water in the tank is full or isn't installed well. 2.Mode: The key can enter the mode selection state, can be switched to 1.
-
Page 7: Maintenance Notices
Maintenance notices Warning Clean filter net (Maintain it every two weeks.) Please don't plug in with wet hands to avoid electric shock. Prohibit wet hand The dehumidify capacity may reduce when the Notice filter net is clogged with defilement. Please cut off the power supply before daily cleaning and maintenance. Pull off plug Don't dismantle the floater from the water tank. -
Page 8: Performance Parameters
Malfunction disposals Performance parameters Please check each item first before applying for maintenance: Model: FDD10-5037BR5(-1) Power supply: AC220V-240V~ 50Hz 10L/day (30°C 80%) Dehumidifying capacity: 5 L/day (27°C 60%) Input power: 200W Rated current: 1.25A Water tank capacity: 2.2L Net weight: 9.5kg Overall dimensions: height 525mm, length 320mm, width 284mm °C Application scope: 5-32...
