- Page 1 TECHNICAL INFORMATION ASSEMBLY, USE AND MAINTENANCE INSTRUCTIONS Reversible heat pumps BESST - BESST/R SERIES...
-
Page 2: Conformity
This instruction manual contains important indications and suggestions which must be followed for a simpler installation and the best possible use of the unit. Thank you once again, Tecnoclima S.p.A CONFORMITY Reversible heat pumps: • Machinery Directive 98/37/CEE;... -
Page 3: Table Of Contents
TABLE OF CONTENTS GENERAL CONFORMITY ................................... 2 RANGE....................................2 WARRANTY..................................2 GENERAL DIRECTIONS ..............................4 FUNDAMENTAL SAFETY RULES............................. 5 EQUIPMENT DESCRIPTION............................. 6 TECHNICAL DATA - WEIGHTS............................7 ELECTRIC BOARD AND MULTIFILAR WIRING DIAGRAM....................9 COOLING CIRCUIT ................................. 14 ACCESSORIES ................................15 CONTROL PANEL ................................ -
Page 4: General Directions
IDENTIFICATION The unit can be identified through: - - Rating plate It bears the technical and performance data of the equipment. Should this plate be damaged or mislaid, ask your local Technical Support Service for a duplicate. Tampering with the rating plate, removing it or whatever else does not allow a sure identification of the product hinder any installation or maintenance interventions. -
Page 5: Fundamental Safety Rules
The manufacture is not held responsible for the non-observance of the instructions contained in this manual, for the consequences of any unexpected operation or for any translations from which wrong interpretations may arise. This appliance must be installed in accordance with the applicable national and local regulations and must be only used in a sufficiently ventilated environment. -
Page 6: Equipment Description
The units are divided into two families: They use a scroll-type rotating compressor, mounted on antivibration supports inside an adequate compartment, and – HEAT PUMPS, BESST series: some available with single- electronically-controlled variable-speed helical fans, which phase power supply, others with three-phase power ensure... -
Page 7: Technical Data - Weights
TECHNICAL DATA - WEIGHTS BESST - BESST/R SERIES Ref. UNI-EN 14511:2004 standard TIPO 2/10 3/11 4/12 5/13 6/14 7/15 8/16 Heating capacity 11,0 15,0 19,9 22,2 28,0 37,2 Power input 1,74 2,11 2,81 3,61 4,28 4,83 6,48 8,44 Heating capacity 13,0 16,6 18,9... - Page 8 HYDRAULIC DATA The following diagram shows the residual lifts with nominal water flow-rate ± 20%. WATER FLOW RATE – LIFT DIAGRAM Type 7-15 Type 5-13 Type 8-16 Type 3-11 Type 1-9 Type 6-14 Type 4-12 Type 2-10 WATER FLOW RATE m Do not work outside these curves...
-
Page 9: Electric Board And Multifilar Wiring Diagram
ELECTRIC BOARD AND MULTIFILAR WIRING DIAGRAM The units are provided with an electric board consisting of the following components. Factory-installed components Compressor Type 1, 2, 9, 10 Run capacitor Fan capacitor Control protection fuse Pump protection fuse Resistor protection fuse Compressor remote switch Resistor remote switch Control panel... - Page 10 Factory-installed components Compressor Type 3 and 11 Run capacitor CV1/2 Fan 1/2 capacitor Control protection fuse Pump protection fuse Resistor protection fuse Compressor remote switch Resistor remote switch Pump remote switch Control panel Conn.A Input terminal block Conn.B Load output terminal block Pump/ Circulating pump Flow controller Protection thermostat...
- Page 11 Factory-installed components Compressor Type 4 and 12 CV1/2 Fan 1/2 capacitor Control protection fuse Pump protection fuse Resistor protection fuse Compressor remote switch Resistor remote switch Pump remote switch Control panel Conn.A Input terminal block Conn.B Load output terminal block Pump/Circulating pump Flow controller Protection thermostat...
- Page 12 Factory-installed components Compressor Type 5, 6, and 13, 14 CV1/2 Fan 1/2 capacitor Control protection fuse Pump protection fuse Resistor protection fuse Compressor remote switch Resistor remote switch Pump remote switch Control panel Fan modulation board Conn.A Input terminal block Conn.B Load output terminal block Pump...
- Page 13 Factory-installed components Compressor Type 7, 8 and 15, 16 CV1/2/3/4 Fan 1/2/3/4 capacitor Control protection fuse Pump protection fuse Resistor protection fuse Compressor remote switch Resistor remote switch Pump remote switch Control panel Fan modulation board Conn.A Input terminal block Conn.B Load output terminal block Pump...
-
Page 14: Cooling Circuit
COOLING CIRCUIT HEAT PUMP In Winter cycle In Summer cycle COMPONENTS: Plate heat exchanger Finned coil (condenser) Cycle reversing valve Check valve High pressure safety switch Thermostatic valve (Summer cycle) Compressor Thermostatic valve (Winter cycle) Liquid receiver Filter Low pressure safety switch Liquid indicator Pressure transducer Flow controller... -
Page 15: Accessories
ACCESSORIES Below is a list of available accessories to be separately ordered. ACCESSORY CODE Remote control kit 4TRRT02 Antivibration mount kit 4TRAV01 Soft start kit 4TRRS01 Enclosure kit 4TRKP01 - 4TRKP02 - 4TRKP03 - 4TRKP04 SUPPORTING RESISTOR. The control panel enables all necessary settings for the heat pump operation and displaying of main parameters and alarms. - Page 16 Keys Press and immediately release Symbol printed on Press and hold (if key is front frame properly configured) Scroll menu items, increase parameter Request for manual values defrosting Scroll menu items, decreases Device switch on/off (and parameter values vice-versa) Manual alarm reset Acces to machine status menu (set disp Access to essential...
-
Page 17: Fault Indications
FAULT INDICATIONS In case of abnormal operation of the equipment, alphanumerical DESCRIPTION INDICATION RESET High pressure Er01 manual codes alternating with the system Low pressure Er05 manual return temperature are displayed on the control panel display. Flow controller Er20 manual Some alarms are automatically reset, whereas others can only be Er30 Water circuit antifreeze... - Page 18 Heating (WINTER CYCLE)) Selecting HEAT the symbol lights up Cooling (SUMMER CYCLE) Selecting COOL the symbol lights up. Switching off the heating/cooling modes Hold for some seconds until COOL” or HEAT (cycle on) is displayed. Select with the key STBY and confirm with SET ;...
-
Page 19: Inactivity For A Long Period Inactivity For A Long Period
In case of power failure for less than four hours, after restoring the unit, keep it powered but switched off for the same number of hours the power failed It is recommended to switch the operating mode only once a day. -
Page 20: Upon Receiving The Product
UPON RECEIVING THE PRODUCT Check if the received product is intact and whether the packing The instruction manual is an integral part of the equipment, list matches the labels on the package. Should the content not therefore we recommend you to read it and keep it with care. match your order, please contact the retailer who sold the equipment and the carrier. -
Page 21: Location
LOCATION The installation site must be determined by the system designer or a The unit is destined for outdoor installation and must be located competent person and must take into account technical requirements within a buffer area in accordance with the figure below. The defined and applicable laws and regulations which prescribe special clearances are required to enable a correct air flow and allow for authorizations, (ex.: city planning, architectural, environmental... -
Page 22: Hydraulic Connections
HYDRAULIC CONNECTIONS The choice and installation of the components is the installer’s A system “calibration” by-pass MUST be made for types 5- responsibility who must work according to the best practice rules and 6-7-8 and 13-14-15-16 (see drawing below). The by-pass the regulations in force. -
Page 23: Dimensions
The hydraulic connections must be completed installing: – air vent valves in the piping upper points; – a 0.5 mm inlet mesh filter (return from system). - flexible couplings; - an outlet liquid flow switch (delivery to system) to be sized and set - check valves;... - Page 24 SIZE AND LOCATION OF CONNECTIONS Type 1-2 and 9-10 Type 3-4 and 11-12 M: delivery to system R: return from system r: water top-up...
-
Page 25: Electrical Connections
SIZE AND LOCATION OF CONNECTIONS Type 5-6 and 13-14 Type 7-8 and 15-16 M: delivery to system R: return from system r: water top-up ELECTRICAL CONNECTIONS Units leave the factory completely wired and ready for For electrical connections use double insulation cables. connection to the mains electricity supply and for the flow switch connection, which must be carried out by qualified personnel in accordance with current legislation. - Page 26 power input values indicated electrical connection is prohibited. characteristics table, also considering any other equipment in parallel operation. Failure to earth the appliance or observe the wiring diagrams – if the supply voltage matches the rated value ± 10%, with a 3% relieves the manufacturer of all liability for damage.
- Page 27 NOTE FOR FIRST STARTUP: THE APPLIANCE MUST BE ALWAYS POWERED TO ENABLE CORRECT PRE-HEATING OF THE COMPRESOR OIL. THE APPLIANCE MUST HAVE BEEN POWERED FOR AT LEAST EIGHT HOURS BEFORE THE FIRST STARTUP IS POSSIBLE. The electric board with the connection terminal block is located inside the equipment, in the upper part of the circuit component compartment.
- Page 28 – Make the connections as shown in the figure. COLLEGAMENTI ESTERNI COLLEGAMENTI ESTERNI (A CURA DELL’INSTALLATORE) (A CURA DELL'INSTALLATORE) Versione Monofase Versione Trifase Versione Monofase Versione Trifase REMOTE ALARM SIGNAL REMOTE ALARM SIGNAL AL 12 V DC OUTPUT AL 12 V DC OUTPUT FLOW SWITCH FLOW SWITCH REMOTE SWITCHES...
-
Page 29: Enabling The "So" And "Sei" Controls
ENABLING THE “SO” AND “SEI” CONTROLS” DO THE FOLLOWING FROM THE CONTROL PANEL: The operations described below must be carried out with the maximum care so as not to affect the equipment regular operation. In case of errors or interpretation doubts, please WAIT 15 SECONDS WITHOUST PRESSING ANY KEYS. To enable the SO and SEI controls, act as follows: Power on the unit, by turning ON the main system circuit breaker and the main equipment switch”. -
Page 30: Recommended Working Conditions
– Open the system shut-off devices – Start the filling by slowly opening the system water fill cock “A” outside the appliance – When water begins to come out of the vent valves, close them and go on filling up to the system set pressure value. Check the connections for tightness. -
Page 31: Preparation For First Commissioning
PREPARATION FOR FIRST COMMISSIONING The appliance first commissioning must be performed by the – The hydraulic system has been filled and vented manufacturer’s Technical Support Service. – The hydraulic circuit shut-off valves are open Before commissioning the unit, make sure that: –... -
Page 32: Switching The Equipment On And Off
BY-PASS CALIBRATION OPERATIONS FOR 5-6-7-8 TYPES AND 13-14-15-16 TYPES - - Switch on the appliance. - Wait for the unit operation to get stabilized - Check the heat rise between system delivery and return which must be between 4°C and 6°C - If it is not so, operate the calibration by-pass, opening it to increase the heat rise or closing it to decrease the heat rise - After adjusting the by-pass, bring the unit back to steady state and check if the heat rise between system delivery and return is between 4°C and 6°C. - Page 33 Switching on To select the operating mode, press and hold the key until “HEAT”, “COOL” or “STBY” is displayed, depending on the controller’s current operation status. Select HEAT mode with the UP or DOWN keys and confirm with the key. Heating (WINTER CYCLE) Selecting HEAT the .
- Page 34 Switching off Turn OFF the “SO” ON-OFF remote switch The “OFF” indication starts flashing on the CONTROL PANEL Switching on the heating mode Switching on - Turn ON the “SEI” SUMMER-WINTER remote switch - Turn ON the “SO” ON-OFF remote switch The indicator LED lights up on the control panel.
-
Page 35: Defrosting Control
DEFROSTING CONTROL To prevent ice from forming on the finned coil, during the winter symbol flashes on the control panel during defrosting, heating phase, each machine is equipped with an automatic indicating this status. defrosting device, controlled by the microprocessor through pressure probes and timer. -
Page 36: Extraordinary Maintenance
EXTRAORDINARY MAINTENANCE REFRIGERANT GAS CHARGING Units are pre-charged with refrigerant gas R410a and adequately Operating conditions other than the rated ones mat generate tested in factory. significantly different values Therefore, under normal conditions, they do not require any interventions by the manufacturer’s Support Technical Service as to checking the refrigerant gas. - Page 37 ACCESSING AND CHANGING PARAMETERS (USER-LEVEL)) The equipment must be powered and the system return water temperature or the “OFF” indication must appear on the display. To access and, if necessary, change the parameters, do the following:: Access to the various parameter menus. –...
-
Page 38: Troubleshooting
TROUBLESHOOTING In case of abnormal operation of the equipment, alphanumeric codes (ex. Er01) are displayed on the control panel, alternating with the system return water temperature. Some alarms are automatically reset, whereas others can only be manually reset by pressing the UP and DOWN keys (see pages 15 and 36). - Page 39 FAULT CAUSE SOLUTION Noise and vibration Contacts between metal bodies. Check Weak foundations. Restore Loosened screws Tighten the screws Low exhaust pressure Low condensation air/water temperature. Abnormal fan regulation operation. Check Low refrigerant charge. Compressor drain valve leakage. Replace the component High suction pressure High inlet water temperature.
- Page 40 TECNOCLIMA S.p.A. - 38057 PERGINE VALSUGANA (TRENTO) - Italy - Viale dell’Industria, 19 Tel. +39 0461/531676 r.a. - Fax +39 0461/512432 www.tecnoclimaspa.com e-mail: tecnoclima@tecnoclimaspa.com Since the Company is constantly committed to continuously improving all its production, the aesthetic and dimensional characteristics, the technical data, the equipment and the accessories may be subject to alteration 07/08 Ind.rev.
