- Page 1 MANUAL ENGLISH DLD-84 8.4” LCD Display Order code: 101206 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
DLD-84 8.4” LCD Display Table of contents Warning ....................................2 Safety Instructions ..............................2 Operating Determinations ............................3 Connection with the mains ............................. 4 Return Procedure ..............................4 Claims ..................................4 Description of the device ..............................5 Front ..................................... 5 Back ..................................... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● DMT DLD-84 8.4 LCD Display ● 12 V DC power adapter (1,3 m) ●... -
Page 4: Operating Determinations
● If your DMT device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your DMT dealer for service. -
Page 5: Connection With The Mains
DLD-84 8.4” LCD Display Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER... -
Page 6: Description Of The Device
Description of the device Features The DMT DLD-84 is a table-mount monitor system. It can be used for VJ monitoring, surveillance systems and any other multimedia setup where monitoring is necessary. Optional 19-inch mounting bracket, for installation of 2 x DLD-84s, is available. -
Page 7: Back
02) Cooling fan 03) 12 V DC power adapter connector IN 04) DVI+VGA connector LOOP Connect the DLD-84 to another device, e.g. a video processor. 05) DVI+VGA connector IN Connect the video output of a media device. 06) USB A connector IN Connect a USB flash drive. -
Page 8: Table Stand Installation
Table Stand Installation 01) Insert the T-type nylon gaskets (A) into the mounting holes (B). 02) Mount the DLD-84 to the table stand. 03) Insert the gaskets (C) and tighten the inclination screws (D), in order to secure the table stand and the DLD-84 in position. -
Page 9: 19-Inch Bracket Installation (101207)
02) Connect 2 DLD-84s by means of the attachment brackets (J) on the top and the bottom. Use the M4x8 screws (G/K) and the M3x5 screws (H). 03) Use the remaining 4 M3x5 screws (H) to connect the handles (I) to the DLD-84. Fig. 05... -
Page 10: Setup And Operation
02) Power the DLD-84 up, using the power adapter. Maintenance The DMT DLD-84 8.4” LCD Display requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. -
Page 11: Dimensions
DLD-84 8.4” LCD Display Dimensions Order code: 101206... - Page 12 ©2019 D.M.T.
