Clearing Last Fault

The last fault stored can be cleared on the MotorSaver.
This procedure is outline as follows:
1. Rotate the Mode Select Switch to '4LFT'.
2. Press and hold the Reset/Program Button. Adjust the Display/Program adjustment until cLr appears
on the display. Release the Reset/Program Button.
To verify the last fault was cleared, place the Mode Select switch in the Run position. Then press and
hold the Reset/Program Button, cLr should be on the display.

Tamper Guard

The PumpSaver can be protected from unauthorized program changes by locking in the setpoints.
This procedure is outlines as follows:
1. Rotate the Mode Select switch to '4LFT'.
2. Rotate Display/Program adjustment fully clockwise.
3.Press and hold the Reset Button. Adjust the Display/Program adjustment until 'Loc' appears in the display.
4. Release the Reset Button.
5. Turn Mode Select switch to 'run'.
The program is now locked, but all settings can be viewed. The unit can be unlocked by following the
procedure above except step three. This step should say: Press and hold the Reset Button. Adjust the
Display/Program adjustment until 'unL' appears in the display.
