Objective Power Adapter Information
2
ATTENTION: Improper AC adapters and/or tips can result in battery or capacitor explosion
hazards and device damage. The O2 strictly requires an AC‐to‐AC adapter, as specified below.
• Required power adapter characteristics for the Objective
Type:
Voltage:
Current:
Connector:
PLEASE NOTE: AC/DC adapters are very different from AC/AC adapters. Manufacturers commonly abbreviate
and refer to all types simply as "AC Adapters", which gives no indication of their actual output. Be aware that
most adapters are in fact AC/DC type, which supply DC current. These power adapters are used with laptops,
game consoles, computer peripherals, etc., and are not compatible with the Objective2.
The O2 strictly requires an AC‐to‐AC transformer, with minimum 14VAC output.
Charging Instructions
1. Connect an AC power adapter to the 14‐20 VAC Jack, then connect AC adapter to wall. Amplifier can
be used simultaneously.
2. Charge time for included NiMH batteries is 8‐24 hours.
3. O2 charges indefinitely at a low current (no charge status!). Remove power adapter as desired.
Recommended Power Adapters ‐ North America
1. Triad WAU12‐200, 120VAC to 12VAC, 200mA
Notes: Recommended by NwAvGuy. Actual output: 13.5VAC, suitable for most users.
2. Triad WAU16‐400, 120VAC to 16VAC, 400mA
Notes: Recommended by NwAvGuy. **Not verified by JDS Labs**
3. Xicon 120VAC to 18VAC, 500mA
Notes: Recommended by NwAvGuy. **Not verified by JDS Labs**
4. Triad WAU20‐200, 120VAC to 20VAC, 200mA
Notes: Recommended by NwAvGuy. **Not verified by JDS Labs**
Recommended Power Adapters ‐ United Kingdom
1. Maplin N58AT, AC/AC Multi‐Voltage 1000mA Power Supply
Notes: Use 15V output. **Not verified by JDS Labs**
International Objective
because power standards differ greatly around the world. Be sure to use an AC‐to‐AC
transformer.
AC‐to‐AC Transformer (AC/AC)
14‐20V AC output
Minimum 200mA
2.1x5.5mm (ID x OD)
owners: We cannot offer brand or model recommendations
2
Supplier
Mouser.com
Mouser.com
Mouser.com
Mouser.com
Supplier
Maplin
:
2
Part #
553‐WAU12‐200
553‐WAU16‐400
412‐218054
553‐WAU20‐200
Part #
N58AT
Price
$5.55
$10.76
$10.65
$6.70
Price
£19.99
