ExiPrep™96 Lite
Automated NA Purification System
35℃
15℃
A-5250
MT Promedt Consulting GmbH Altenhofstr. 80
D-66386 St. Ingbert. Germany. Tel +49 6894-58 10 20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Exiprep 96 Lite and is the answer not in the manual?

Questions and answers

Summary of Contents for Bioneer Exiprep 96 Lite

  • Page 1 ExiPrep™96 Lite Automated NA Purification System 35℃ 15℃ A-5250 MT Promedt Consulting GmbH Altenhofstr. 80 D-66386 St. Ingbert. Germany. Tel +49 6894-58 10 20...
  • Page 2 ExiPrep ™96 Lite ExiPrep™96 Lite Automated NA Purification System User’s Guide Bioneer Corporation 8-11, Munpyeongseo-ro, Daedeok-gu, Daejeon 34302, Republic of Korea Tel: +82-42-930-8777 Fax: +82-42-930-8688 Email: order@bioneer.com www.bioneer.com...
  • Page 3 It is the responsibility of the purchaser to determine the suitability of the product for its particular use. Liability is conditional upon the customer providing full details of the problem to Bioneer within 30 days. Trademark ExiPrep ™...
  • Page 4 Part 2-010: Particular Requirements for Laboratory Instrument for the Heating of Materials CAN/CSA-C22.2 NO. 61010-2-010-04 ▪ Part 2: Particular requirements for in vitro diagnostic (IVD) medical instrument, CAN/CSA-C22. 2 No. 61010-2-101:04 MANUFACTURER : Bioneer Corporation 8-11, Munpyeongseo-ro, Daedeok-gu, Daejeon, 34302 Republic of Korea EUROPEAN : MT Promedt Consulting GmbH REPRESENTATIVE Altenhofstr.
  • Page 5: Table Of Contents

    Troubleshooting ......................31 XI. User Maintenance ......................33 Cleaning of the main body .................... 33 Replacing the Fuse ..................... 33 Storage Method ......................35 Shipping the Instrument for Service ................. 35 XII. Warranty ........................36 BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 6: Overview

    ™96 Lite comes with a contamination shield designed to protect the assay from cross-contamination during operation. During the cartridges are in motion, the contamination shield will automatically slide upper the cartridges. This will eliminate the possibility of intra-assay cross-contamination, which is critical when working with multiple samples. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 7: Symbols Description

    Be cautions when moving the door, You will get hurt when it opens and shuts. Please note that there is a risk of infection if you contact the waste liquid inside a instrument. Electrical Symbols BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 8 Displays the ground terminal for the main protective ground of the instrument. Indicates a terminal that receives or supplies alternating current or voltage. Indicates a terminal that receives or supplies direct current or voltage. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 9 Follow local municipal waste ordinances for proper disposal provisions to reduce the environmental impact of waste electrical and electronic instrument. European Union customers: Call your local Europe office for Bioneer instruments pick-up and recycling. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 10: Safety Warnings And Cautions

    5) Do not install the instrument in a dusty area. It may cause malfunction. 6) Install the instrument away from electric heating devices. It may cause fire. 7) Install the instrument avoiding areas of splashing water or humidity. It may cause electric shock, fire or malfunction. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 11 3) Do not modify or delete the information of the built-in instruments. 4) Do not touch the LCD touch screen with sharp objects. Using sharp drills, nails, picks, etc. may cause damage the product. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 12 Ultraviolet rays of the sterilization lamp may cause severe damage to eyes and skin and therefore not advisable to see directly or indirectly. Be sure to take safety precautions such as ultraviolet shielding instrument so as to not to see directly or indirectly or irradiate skin. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 13: Precautions On Waste Liquid

    4. Waste Treatment 1) Waste liquid and consumables used must be disposed of properly according to the waste disposal regulations. 2) Wear appropriate eyewear, clothing, and gloves when handling reagent and waste liquid. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 14: Product Configuration And Description

    1. Product configuration Part Name Cat. No. Qty. ExiPrep ™96 Lite A-5250 1 ea 32 well Magnetic Rods 3 ea User’s Guide 1 ea Power cord 1 ea (Options) 8 well Magnetic Rods 3 ea BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 15: Specifications

    4-90℃ (39.2 ~ 194 ℉) Operating temperature 15 – 35°C (59.0 – 95.0℉) Operating humidity 20 - 80%, no condensation Operating system Built-in Communication TCP/IP User interface Display 7 inch Touch Data Storage USB 2.0 (x2) BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 16: Instrument Structure And Name

    ExiPrep ™96 Lite 3. Instrument structure and name (1) Outside <Outside> (2) Inside <Inside 1> BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 17 ExiPrep ™96 Lite <Inside 2> <Inside 3> BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 18 ExiPrep ™96 Lite (3) Buffer Cartridges <Buffer Cartridges Layer 1> <Buffer Cartridges Layer 2> BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 19 ExiPrep ™96 Lite <Buffer Cartridges Layer 3> BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 20: Product Installation Requirement

    The power outlet with the power rating of 550VA or above should be located within 1.5m (4.92ft.). Must be isolated from any form of moisture. ▪ Materials needed Box cutter, scissors, knifes, gloves ▪ Unpack Unpack ExiPrep ™96 Lite: BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 21 Bend you knees and use your legs to lift the instrument. ▪ Do not twist your body while holding the instrument and two or more people must work together. ▪ ExiPrep Check the accessories of ™96 Lite. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 22: Removing The Shipping Bracket And Approving Power Source

    3) When the bolts (A, B) are removed, the shipping bracket(C) can be separated. Store the shipping bracket and bolts removed separately so that you can use it again when relocating the instrument. <Front View> <Rear View> BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 23: Approving Power Source

     Green light: The instrument is ready for operation.  Yellow light: self test.  Cyan light: The instrument is in operation.  Purple light: Door is open.  White light: Pause during operation. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 24: Changes Of Magnetic Rods

    3) Remove the bracket at the top of the magnetic rods plate by turning it to the left. 4) Pulling the magnetic rods toward the front of the instrument will remove the magnetic rods. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 25 You can’t mix 32 well magnetic rods and 8 well magnetic rods. If you use 32 well and 8 well the magnetic rods at once, it may seriously affect the experiment and product damage. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 26: Magnetic Rod Covers And Cartridges Preparation

    1 comes forward to insert the cartridges. 3) Color of plate is displayed to yellow. 4) Insert magnetic rod covers into magnetic rod cover plate. 5) insert the cartridge 1, 2 into the buffer cartridge layer 1. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 27 2 put back to insert the cartridges and buffer cartridge layer 3 comes forward to insert the cartridges. 12) Color of plate is displayed to yellow. 13) insert the cartridge 5, 6 into the buffer cartridge layer 2. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 28 14) Magnetic rod covers and each cartridge finish setting, plate icon color is disappears. 15) Insert elution cartridge into elution heating block. If click on the bottom of the ‘Plate’ button, buffer cartridge layer works in reverse. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 29: Software Operation

    Control Cover and plate for experiment Setup Go to setup menu Displays remaining Time progress Time Label time, and finish time Step Label Display current step Start experiment Pause Pause experiment Stop Stop experiment BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 30 OK button to add them to the list. If you want to delete the selected protocol, press ‘DEL’ button. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 31 Release the alarm, open the door, insert ethanol, close the door and press OK to continue the experiment. If you want to pause the experiment, press the ‘Pause’ button. If you want to stop the experiment, press ‘Stop’ BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 32 Information about Log can be found in Setup-Log and information about experiment time, protocol, and SampleID is recorded. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 33: Uv Lamp

    W folder saved in USB and press Update button. The existing software will be backed up and automatically restarted after the new software is installed. b) Display the device name, S / W version information, F / W version information, and contact information. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 34: Setup - Log

    Double-click the date and order number to view the details. Experiment time, protocol, specimen. b) Copy the log file to USB memory. Log in to the administrator account. Administrators do not require software maintenance. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 35: Setup - Device

    First Cap in / out. Plate1 In / Plate1 Out First Plate in / out. TopHeat Off / TopHeat Turns the TopHeater on / off. Set the time by popping the Date Time setting popup. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 36: Troubleshooting

    2. Check if there are foreign objects and accessories and rack, etc at their locations. 3. Check if retainer pins are damaged or bent. 4. Contact your local dealer for repair. Stops while operating 1. Check if the power source is connected. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 37 POWER button is not working 2. The button does not work when the instrument is performing self- diagnosis. After the self-diagnosis is completed, check if the status of LED flashes green and operate the button. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 38: User Maintenance

    To prevent the electric shock, disconnect the power cord at least one minute before use and disconnect the power supply from the external power source. 2) If you insert a flat-head screwdriver into the upper part of power inlet, the fuse cover can be opened. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 39 5) Return the fuse slot to its original position under the power cord inlet and close the fuse cover. 6) Push the fuse cover firmly until it gets to the original position. 7) Connect the power cord of the instrument. BQ-042-101-12 Revision : 0 (2018-07-05) www.bioneer.com...
  • Page 40: Storage Method

    If the bath block is contaminated by radioactive material, remove the source of the contamination with a commercial decontamination agent. If contaminated material cannot be removed with a decontamination agent, Bioneer Corp. will not receive the instrument for services. 3) Check whether the source of contamination is completely removed.
  • Page 41: Warranty

    This instrument is warranted by Bioneer against manufacturing defects in materials and workmanship for a limited warranty period of one (1) year from the date you received your product. Bioneer will either (1) repair the product at no charge if a hardware defect is found or (2) exchange the product if the same hardware defect arises more than three times during the limited warranty period.
  • Page 42 8-11, Munpyeongseo-ro, Daedeok-gu, Daejeon, 34302, Republic of Korea Tel: (international)+82-42-930-8777, (Korea)1588-9788, Fax:+82-042-930-8688 ExiPrep™96 Lite Maintenance Sheet Operator: Month/Year: S/N: EP96L- Days Description Daily Worktable Cleaning Check Touch Screen operation Elution Rack Cleaning Layer cartridge rack cleaning Contamination Shield Cleaning...
  • Page 43 8-11 Munpyeongseo-ro, Daedeok-gu, Daejeon, 34302, Republic of Korea +82-42-930-8777 (Korea: 1588-9788) +82-42-930-8688 sales@bioneer.com www.bioneer.com 155 Filbert St. Suite 216 Oakland, CA 94607, USA +1-877-264-4300 (Toll-free) +1-510-865-0350 order.usa@bioneer.com us.bioneer.com Korea Bio Park BLDG #B-702, 700 Daewangpangyo-ro, Bundang-gu, Seongnam-si Gyeonggi-do, 13488, Republic of Korea...
