Introduction

The HD Cam is a full HD IP camera which can be connected directly onto a helmet Picatinny rail
mount, making it suitable for use in tactical situations.
The camera integrates directly with the Visual Engineering Body Worn Mesh Radio. When coupled
with the BWM it provides a complete end to end surveillance system.
The camera has exceptional performance in low light conditions and is supplemented with built in
Infrared or white light LED Illumination.
The HD Cam supports variable video resolutions, which ranges from 1920x1080 down to 320x240.
Variable frame rate and bitrate adjustments are also possible. All of these parameters can be
configured via a web browser interface.
The outer casing is CNC machined aluminium, this rugged build together with its IP67
environmental rating produces a camera that is fit for deployment into tactical field operations.
The camera is designed to have efficient use of power, all connections including power and IP video
are combined into one Fisher connector on the rear of the housing.
A button mounted on the top of the camera controls the activation state of the LED Illuminator. At
initial power on the LED will switch on in low light levels determined by the integrated ambient light
sensor. Following power on if the button is pressed it will disable the LED regardless of light level.
Further presses of the button will cycle the LED to first switch back to auto state and then off and so
on.
Custom cable assemblies interface with body worn radios from Silvus and TrellisWare.
