Swiss Bionic Solutions OMNIUM 1 Quick Reference Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

intelligent Lifestyle
2.0
Quick Reference Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OMNIUM 1 and is the answer not in the manual?

Questions and answers

Related Manuals for Swiss Bionic Solutions OMNIUM 1

Summary of Contents for Swiss Bionic Solutions OMNIUM 1

  • Page 1 intelligent Lifestyle Quick Reference Guide...
  • Page 2 Swiss Bionic Solutions Holding GmbH. This excludes any documen- tation retained by the purchaser for back-up purposes. This provision shall not apply for software subject to the General Public License (GPL) or other free open source licenses.

  • Page 3: Table Of Contents

    Table of Contents 1. Scope of Delivery .....................4 2. Housing and Buttons ..................5 3. Charging the Battery ..................6 4. Switching On and Off ..................7 5. Inserting and Removing the Micro SD Card ..........8 6. Working with the Screen .................9 7. Using the Operating Buttons ................10 8.

  • Page 4: Scope Of Delivery

    1. Scope of Delivery Omnium1 Tablet Charging Equipment Charging Equipment Earphones 20 Pin cable 20 Pin cable Quick Reference Guide Quick Reference Guide If any of the parts is damaged or missing, please contact your partner at Swiss Bionic Solutions.

  • Page 5: Housing And Buttons

    2. Housing and Buttons 1. 3.5 mm headphone jack 7. Home button 2. Microphone 8. Touchscreen 3. Micro SD/SDHC (TF) card slot 9. Volume control 4. DC charging cable 10. On/off and lock button 5. Front camera 11. Rear Camera & LED fl ash 6.

  • Page 6: Charging The Battery

    3. Charging the Battery Before you use your Omnium1 for the fi rst time, the battery will need to be charged. 1. Plug the power supply into the tablet’s power connection. 2. Plug the power supply into the wall socket. The Omnium1 display will show a picture indicating that the device is being charged.

  • Page 7: Switching On And Off

    4. Switching On and Off How to switch your Omnium1 on: • Press the on/off button on the top for several seconds. • As soon as the device has booted, the lock screen will appear. Use your fin- ger to drag the lock symbol to one side in order to unlock the screen. Your Omnium1 will now display the home screen.

  • Page 8: Inserting And Removing The Micro Sd Card

    5. Inserting and Removing the Micro SD Card Insert a micro SD memory card (max. 32 GB) in the card slot as shown in the picture of the device. Do not push hard or use any force. The card only needs to overcome a light spring resistance.

  • Page 9: Working With The Screen

    6. Working with the Screen Your Omnium1 has been equipped with a touch-sensitive (capacitive) mul- ti-touch touchscreen, so a simple touch (without any pressure) is sufficient for running your commands. There are a number of options for controlling the tablet: Tap on an item once The tapped item will be opened,...

  • Page 10: Using The Operating Buttons

    7. Using the Operating Buttons App Menu Button Opens the app menu. There, you will find a number of pre-instal- led apps. In addition, all downloaded apps will be stored there Back Button Allows you to go back one step in all apps. Home Button Briefly tapping the button will return you to the home screen (also possible with Home...

  • Page 11: Viewing In Portrait And Landscape Modes

    8. Viewing in Portrait and Landscape Modes Turning the Omnium1 from horizontal to vertical or vice versa will change the screen orientation. Most apps will automatically adjust their screen content. If automatic orientation is not possible, check if the function has been activa- ted.

  • Page 12: Connecting To The Internet

    10. Connecting to the Internet To surf the Internet or send email messages with your Omnium1, you must be able to connect to a wireless LAN network that you can access. To do so, open the Settings and then click on Network & Internet => WI-FI. Enable the WI-FI option by setting the switch to ON.

  • Page 13: Identification, Technical Data

    12. Identifi cation, Technical data 12.1. Identifi cation Identifi cation plate iMRS one: 0483 CE-Sign law for used electric devices DC-Symbol (direct current) The conformity according to EC directives is explained for the equipment de- scribed in this Operators Guide. 12.2 Technical data Size (W x H x D) 213 mm x 134 mm x 30 mm (8,39 x 5,28 x 1,18...
  • Page 14 Display-Type capacitive 5-Dot Multitouch-Display Display-Size 8.0“ (20,32 cm) Display-Ratio 16:10 Resolution 1280 x 800, 217 DPI External Connectors 20 Pin Adapter, Audio Out, Microphone, Came- ra, Card Reader, WIFI. External Memory microSD, microSDHC (max. 32 GB) Camera 5.0MP Front Cam, 8.0MP Rear Cam with LED Flash Operating System Android™...
  • Page 16 Swiss Bionic Solutions Schweiz GmbH Schulhausstrasse 17 | 8834 Schindellegi, Schweiz Phone: +41 (62) 295 5951 | Fax: +41 (62) 295 5952 Email: ch@swissbionic.com Swiss Bionic Solutions Deutschland GmbH Biberacher Str. 87 | 88339 Bad Waldsee, Deutschland Phone: +49 (7524) 996 950 | Fax: +49 (7524) 996 9518 Email: de@swissbionic.com...
