Format1 Format2
0x42 0x34
0x42 0x35
0x42 0x36
0x42 0x37
0x42 0x0
0x42 0x54
0x49 0x0
0x45 0x31
0x45 0x32
0x45 0x35
0x45 0x36
0x65 0x31
0x65 0x32
0x65 0x35
0x65 0x36
0x47 0x35
0x4E 0x0
0x58 0x0
0x32 0x0
IRIG Control Function (CF) Bits In the following tables, tq1 through tq4 are time quality bits. For time
quality and unlock bits, "1" means active.
For IRIG output codes A, B, E or G with CF bits, the following CF bits are encoded:
Index Bit
count name
----- -----
70 (0)
71 (0)
72 (0)
73 unlock (1 = unit not locked to reference)
74 (0)
75 tq1 (1 = timing error estimate > 1us)
76 tq2 (1 = timing error estimate > 10us)
77 tq3 (1 = timing error estimate > 100us)
78 tq4 (1 = timing error estimate > 1ms)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
ASCII AM Time Code
'B4' B124 BCD, YR, CF, SBS
'B5' B125 BCD, YR, CF
'B6' B126 BCD, YR
'B7' B127 BCD, YR, SBS
'B' B122 BCD
'BT' AM Legacy TrueTime
'I' AM IEEE 1344
'E1' E121 BCD, CF
'E2' E122 BCD
'E5' E125 BCD, YR, CF
'E6' E126 BCD, YR
'e1' E111 BCD, CF
'e2' E112 BCD
'e5' E115 BCD, YR, CF
'e6' E116 BCD, YR
'G5' G145 BCD, YR, CF
'N' AM Nasa 36
'X' AM XR3
'2' AM 2137
- 47 -
1.5. Dual-Port RAM Interface
DCLS
B004
B005
B006
B007
B002
DCLS
DCLS
E001
E002
E005
E006
E001
E002
E005
E006
G005
DCLS
DCLS
DCLS
