TECHNICAL INFORMATION

AWNING SIZES

The following are the ground to ground dimensions through the awning channel. These dimensions are issued as a guideline only, please
refer to your dealer for the correct awning size to suit your particular caravan.
RANGER 380/2 .......................... 814 cms
460/4 .......................... 914 cms
500/5 .......................... 953 cms
520/4 .......................... 995 cms
540/6 .......................... 998 cms
620/6 .......................... 1072 cms
RANGER GT60 380/2 .......................... 814 cms
460/2 .......................... 892 cms
460/4 .......................... 914 cms
500/5 .......................... 953 cms
510/4 .......................... 958 cms
520/4 .......................... 995 cms
540/6 .......................... 998 cms
620/6 .......................... 1072 cms
PAGEANT Monarch ................... 930 cms
Bordeaux ................. 930 cms
Champagne ............. 991 cms
Burgundy ................. 1008 cms
Sancerre .................. 1008 cms
Provence ................. 1008 cms
Bretagne .................. 1008 cms
Loire ......................... 1072 cms
Limousin .................. 1072 cms
Ardennes ................. 1072 cms
SENATOR Vermont ................... 940 cms
Arizona .................... 1009 cms
Indiana ..................... 1009 cms
Virginia ..................... 1009 cms
California ................. 1009 cms
Wyoming .................. 1088 cms
Louisiana ................. 1088 cms
Carolina ................... 1088 cms
25
