OSCILLOSCOPE
INSTRUCTION MANUAL
For Series Models:
20MHz
Oscilloscope
25MHz
Oscilloscope
30
MHz
Oscilloscope
40MHz
Oscilloscope
5
0MHz
Oscilloscope
60MHz
Oscilloscope
100MHz
Oscilloscope

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS-XX0 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Pintek PS-XX0 Series

Summary of Contents for Pintek PS-XX0 Series

  • Page 1 OSCILLOSCOPE INSTRUCTION MANUAL For Series Models: 20MHz Oscilloscope 25MHz Oscilloscope Oscilloscope 40MHz Oscilloscope 0MHz Oscilloscope 60MHz Oscilloscope 100MHz Oscilloscope...

  • Page 3: Table Of Contents

    Table Of Contents: Test Instrument Safety General Description Features 20MHz Specifications 25MHz Specifications 30MHz Specifications 40MHz Specifications 50MHz Specifications 60MHz Specifications 100MHz Specifications Notice Before Operation Controls and Indicators Operating Instructions Safety precautions Equipment protection precautions Operating tips Initial starting procedure Single trace display Dual trace display Triggering...

  • Page 4: Test Instrument Safety

    Test Instru ment Safety OSCILLOSCOPE INSTRUCTION MANUAL WARNIN G Normal use of test equipment exposes you to a certain amount of danger from electrical shock because testing must often be performed where exposed high voltage is present. An electrical shock causing 10 milliamps of current to pass through the heart will stop most human heartbeats.
  • Page 5 TEST INSTRUMENT SAFETY 7. Some equipment with a two-wire ac power cord, including some with polarized power plugs, is the "hot chassis" type. This includes most recent television receivers and audio equipment. A plastic or wooden cabinet insulates the chassis to protect the customer.

  • Page 6: General

    General OSCILLOSCOPE INSTRUCTION MANUAL DESCRIPTION The model PS-XX0/XX1/XX5 oscilloscope is a dual-channel oscilloscope with frequency bandwidth 20~100 MHz at -3dB; maximum sweep 10 nS/DIV; maximum sensitivity 1 mV/DIV and 150 mm rectangular CRT with internal graticule. The oscilloscope is rugged, easy to operate and highly reliable. It also provide many convenient feature and special functions which make itself be an special for research, production , education, and development in electronic device or circuitry.
  • Page 7 GENERAL (9) Z Modulation (XX5 only) Input terminal is used for external intensity modulation signal. (10) Component Test (XX1/XX5) Capacitor, indicator, diode, transistor and zener can be also viewed on screen. (11) Beam Finder (XX1/XX5) Trace can be returned to CRT viewing area regardless of setting horizontal, vertical or intensity controls when press beam finder button.

  • Page 8: 20Mhz Specifications

    OSCILLOSCOPE INSTRUCTION MANUAL 20MHz Specifications CATHODE RAY TUBE 6 inch diagonal, rectangular screen with internal graticule 8 x 10 DIV (1 DIV=1cm), P31 phosphor, 2kV accel voltage. VERTICAL DEFLECTION Bandwidth: DC~20 MHz(-3dB) Sensitivity: 1mV/DIV~1V/DIV(5MHz, -3dB), x5 gain selected. 5mV/DIV~5V/DIV Attenuator: 1-2-5 sequence, 10 step with variable control. Input Impedance 1MΩ...
  • Page 9 20MHZ SPECIFICATIONS MAIN TIME BASE Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps. Accuracy: ±3% Variable time Control: 5:1, un-calibrated, continuously variable between steps. Sweep Magnification: ± X10, 10%, extend sweep speed up to 10nS /DIV. DELAY TIME BASE( XX5 only) Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps.
  • Page 10 20MHZ SPECIFICATIONS COMPONENT TEST(XX1, XX5 only) Test Voltage: Max. 8.6Vrms (open circuit) Test Current: Max. 11mA (shorted) Test Frequency: Line Frequency. Components: Capacitor, Inductor, Diode, Transistor, Zener etc. CH2 OUTPUT(XX5 only) Output Level: 100mV / DIV(no load); 50mV / DIV(with 50Ω load). Bandwidth: 20Hz~20MHz(-3dB) Graticule Illumination: Adj ust a b le( XX1, XX5 on ly) Calibrator: Square wave about 1 KHz, 2Vp-p±3%...

  • Page 11: 25Mhz Specifications

    OSCILLOSCOPE INSTRUCTION MANUAL 25MHz Specifications CATHODE RAY TUBE 6 inch diagonal, rectangular screen with internal graticule 8 x 10 DIV (1 DIV=1cm), P31 phosphor , 2kV accel voltage. VERTICAL DEFLECTION Bandwidth: DC~25 MHz(-3dB) Sensitivity: 1mV/DIV~1V/DIV(10MHz, -3dB), x5 gain selected. 5mV/DIV~5V/DIV Attenuator: 1-2-5 sequence, 10 step with variable control.
  • Page 12 25MHZ SPECIFICATIONS MAIN TIME BASE Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps. Accuracy: ±3% Variable time Control: 5:1, un-calibrated, continuously variable between steps. Sweep Magnification: ± X10, 10%, extend sweep speed up to 10nS /DIV. DELAY TIME BASE( XX5 only) Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps.
  • Page 13 25MHZ SPECIFICATIONS COMPONENT TEST(XX1,XX5 only) Test Voltage: Max. 8.6Vrms (open circuit) Test Current: Max. 11mA (shorted) Test Frequency: Line Frequency. Components: Capacitor, Inductor, Diode, Transistor, Zener etc. CH2 OUTPUT(XX0, XX5 only) Output Level: 100mV / DIV(no load); 50mV / DIV(with 50Ω load). Bandwidth: 20Hz~20MHz(-3dB) Graticule Illumination: Adj ust a b le( XX1, XX5 on ly) Calibrator: Square wave about 1 KHz, 2Vp-p±3%...

  • Page 14: 30Mhz Specifications

    OSCILLOSCOPE INSTRUCTION MANUAL 30MHz Specifications CATHODE RAY TUBE 6 inch diagonal, rectangular screen with internal graticule 8 x 10 DIV (1 DIV=1cm), P31 phosphor. VERTICAL DEFLECTION Bandwidth: DC~30 MHz(-3dB) Sensitivity: 1mV/DIV~1V/DIV(10MHz, -3dB), x5 gain selected. 5mV/DIV~5V/DIV Attenuator: 1-2-5 sequence, 10 step with variable control. Input Impedance 1MΩ...
  • Page 15 30MHZ SPECIFICATIONS MAIN TIME BASE Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps. Accuracy: ±3% Variable time Control: 5:1, un-calibrated, continuously variable between steps. Sweep Magnification: ± X10, 10%, extend sweep speed up to 10nS /DIV. DELAY TIME BASE( XX5 only) Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps.
  • Page 16 30MHZ SPECIFICATIONS COMPONENT TEST(XX5 only) Test Voltage: Max. 8.6Vrms (open circuit) Test Current: Max. 11mA (shorted) Test Frequency: Line Frequency. Components: Capacitor, Inductor, Diode, Transistor, Zener etc. CH2 OUTPUT(XX5 only) Output Level: 100mV / DIV(no load); 50mV / DIV(with 50Ω load). Bandwidth: 20Hz~20MHz(-3dB) Graticule Illumination: Adj ust a b le( XX5 on ly) Calibrator: Square wave about 1 KHz, 2Vp-p±3%...

  • Page 17: 40Mhz Specifications

    OSCILLOSCOPE INSTRUCTION MANUAL 40MHz Specifications CATHODE RAY TUBE 6 inch diagonal, rectangular screen with internal graticule 8 x 10 DIV (1 DIV=1cm), P31 phosphor. VERTICAL DEFLECTION Bandwidth: DC~40 MHz(-3dB) Sensitivity: 1mV/DIV~1V/DIV(10MHz, -3dB), x5 gain selected. 5mV/DIV~5V/DIV Attenuator: 1-2-5 sequence, 10 step with variable control. Input Impedance 1MΩ...
  • Page 18 40MHZ SPECIFICATIONS MAIN TIME BASE Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps. Accuracy: ±3% Variable time Control: 5:1, un-calibrated, continuously variable between steps. Sweep Magnification: ± X10, 10%, extend sweep speed up to 10nS /DIV. DELAY TIME BASE( XX5 only) Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps.
  • Page 19 40MHZ SPECIFICATIONS COMPONENT TEST( XX1, XX5 only) Test Voltage: Max. 8.6Vrms (open circuit) Test Current: Max. 11mA (shorted) Test Frequency: Line Frequency. Components: Capacitor, Inductor, Diode, Transistor, Zener etc. CH2 OUTPUT(XX5 only) Output Level: 100mV / DIV(no load); 50mV / DIV(with 50Ω load). Bandwidth: 20Hz~20MHz(-3dB) Graticule Illumination: Adj ust a b le( XX1, XX5 on ly) Calibrator: Square wave about 1 KHz, 2Vp-p±3%...

  • Page 20: 50Mhz Specifications

    OSCILLOSCOPE INSTRUCTION MANUAL 50MHz Specifications CATHODE RAY TUBE 6 inch diagonal, rectangular screen with internal graticule 8 x 10 DIV (1 DIV=1cm), P31 phosphor. VERTICAL DEFLECTION Bandwidth: DC~50 MHz(-3dB) Sensitivity: 1mV/DIV~1V/DIV(10MHz, -3dB), x5 gain selected. 5mV/DIV~5V/DIV Attenuator: 1-2-5 sequence, 10 step with variable control. Input Impedance 1MΩ...
  • Page 21 50MHZ SPECIFICATIONS MAIN TIME BASE Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps. Accuracy: ±3% Variable time Control: 5:1, un-calibrated, continuously variable between steps. Sweep Magnification: ± X10, 10%, extend sweep speed up to 10nS /DIV. DELAY TIME BASE( XX5 only) Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps.
  • Page 22 50MHZ SPECIFICATIONS COMPONENT TEST( XX1, XX5 only) Test Voltage: Max. 8.6Vrms (open circuit) Test Current: Max. 11mA (shorted) Test Frequency: Line Frequency. Components: Capacitor, Inductor, Diode, Transistor, Zener etc. CH2 OUTPUT(XX5 only) Output Level: 100mV / DIV(no load); 50mV / DIV(with 50Ω load). Bandwidth: 20Hz~20MHz(-3dB) Graticule Illumination: Adj ust a b le( XX1, XX5 on ly) Calibrator: Square wave about 1 KHz, 2Vp-p±3%...

  • Page 23: 60Mhz Specifications

    60MHZ SPECIFICATIONS 60MHz Specifications CATHODE RAY TUBE 6 inch diagonal, rectangular screen with internal graticule 8 x 10 DIV (1 DIV=1cm), P31 phosphor, 12kV accel voltage. VERTICAL DEFLECTION Bandwidth: DC~60 MHz(-3dB) Sensitivity: 1mV/DIV~1V/DIV(10MHz, -3dB), x5 gain selected. 5mV/DIV~5V/DIV Attenuator: 1-2-5 sequence, 10 step with variable control. Input Impedance 1MΩ...
  • Page 24 60MHZ SPECIFICATIONS MAIN TIME BASE Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps. Accuracy: ±3% Variable time Control: 5:1, un-calibrated, continuously variable between steps. Sweep Magnification: ± X10, 10%, extend sweep speed up to 10nS /DIV. DELAY TIME BASE( XX5 only) Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps.
  • Page 25 60MHZ SPECIFICATIONS COMPONENT TEST( XX1, XX5 only) Test Voltage: Max. 8.6Vrms (open circuit) Test Current: Max. 11mA (shorted) Test Frequency: Line Frequency. Components: Capacitor, Inductor, Diode, Transistor, Zener etc. CH2 OUTPUT(XX5 only) Output Level: 100mV / DIV(no load); 50mV / DIV(with 50Ω load). Bandwidth: 20Hz~20MHz(-3dB) Graticule Illumination: Adj ust a b le( XX1, XX5 on ly) Calibrator: Square wave about 1 KHz, 2Vp-p±3%...

  • Page 26: 100Mhz Specifications

    OSCILLOSCOPE INSTRUCTION MANUAL 100MHz Specifications CATHODE RAY TUBE 6 inch diagonal, rectangular screen with internal graticule 8 x 10 DIV (1 DIV=1cm), P31 phosphor, 14kV accel voltage. VERTICAL DEFLECTION Bandwidth: DC~100 MHz(-3dB) Sensitivity: 1mV/DIV~1V/DIV(20MHz, -3dB), x5 gain selected. 5mV/DIV~5V/DIV Attenuator: 1-2-5 sequence, 10 step with variable control. Input Impedance 1MΩ...
  • Page 27 100MHZ SPECIFICATIONS MAIN TIME BASE Sweep Speed: 0.1μS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps. Accuracy: ±3% Variable time Control: 5:1, un-calibrated, continuously variable between steps. Sweep Magnification: ± X10, 10%, extend sweep speed up to 10nS /DIV. DELAY TIME BASE( XX5 only) Sweep Speed: 20nS/DIV~2.0S/DIV in 1-2-5 sequence, 23 steps.
  • Page 28 100MHZ SPECIFICATIONS COMPONENT TEST( XX1, XX5 only) Test Voltage: Max. 8.6Vrms (open circuit) Test Current: Max. 11mA (shorted) Test Frequency: Line Frequency. Components: Capacitor, Inductor, Diode, Transistor, Zener etc. CH2 OUTPUT(XX5 only) Output Level: 100mV / DIV(no load); 50mV / DIV(with 50Ω load). Bandwidth: 20Hz~20MHz(-3dB) Graticule Illumination: Adj ust a b le( XX1, XX5 on ly) Calibrator: Square wave about 1 KHz, 2Vp-p±3%...

  • Page 29: Notice Before Operation

    Notic e Before Operatio n OSCILLOSCOPE INSTRUCTION MANUAL 1. Unpack the oscilloscope: After receipt of the instrument, immediately unpack and inspect it for any shipping damage or missing accessories. If any sign of damage or missing accessories are found, immediately notify the dealer.
  • Page 30 OSCILLOSCOPE INSTRUCTION MANUAL 4. Suggestions for successful instrument operation: Never place heavy objects on the instrument. Never place a hot soldering iron on or near the instrument. Never insert wires, pins, or other metal objects into the ventilation fan. Never move or pull the instrument with the power cord or a probe cord. Never move instrument when the power cord or a signal probe is connected to a circuit.

  • Page 31: Controls And Indicators

    OSCILLOSCOPE INSTRUCTION MANUAL Controls and Indicators...
  • Page 32 CONTROLS AND INDICATORS...
  • Page 33 CONTROLS AND INDICATORS...
  • Page 34 CONTROLS AND INDICATORS...
  • Page 35 CONTROLS AND INDICATORS...
  • Page 36 CONTROLS AND INDICATORS...
  • Page 37 CONTROLS AND INDICATORS 1. Symbol Indicators: Power OFF Earth Ground Warning! Risk of Danger Power ON VR With Switch Vertical Up Conforms to IEC 1010. EN 61010 Vertical Down Complies With U.S. & Canadian Horizontal Left Standard In Spected & Incensed by TUV Horizontal Right Product Servies 2.
  • Page 38 CONTROLS AND INDICATORS CAL Terminal(9): Terminal provides 2V p-p, 1 KHz(nominal) square wave signal. This signal is useful for checking probe compensation adjustment, as well as providing a rough check of vertical calibration. BEAN FIND Pushbutton(12): Momentary-contact pushbutton speeds setup of trace position by bringing the beam into graticule area;...
  • Page 39 CONTROLS AND INDICATORS CH 1 (X) VOLTS/DIV Control(4): Vertical attenuator for channel 1. Provides step adjustment of vertical sensitivity. When channel 1 VARIABLE control is set to CAL, vertical sensitivity is calibrated in 10 steps from 5 mV/DIV TO 5 V/DIV in a 1-2-5 sequence. When the X-Y mode of operation is selected, this control provides step adjustment of X-axis sensitivity.
  • Page 40 CONTROLS AND INDICATORS PULL X5 MAG: When pulled out, increases vertical sensitivity by a factor of five. Effectively provides two extra sensitivity settings: 2 mV/DIV and 1 mV/DIV. In X-Y mode, increases Y-sensitivity by a factor of five. CH 2 (Y) Input Jack(13): Vertical input for channel 2. Y-axis input for X-Y operation.
  • Page 41 CONTROLS AND INDICATORS MIX: The main and delayed sweep share a single trace; main sweep occupies the left portion of the display; delayed sweep occupies the right portion of the display. The DELAY TIME POSITION control determines the percentage of display that is main sweep and the percentage of display that is delayed sweep (main sweep is usually brighter than the delayed sweep).
  • Page 42 CONTROLS AND INDICATORS EXT: Signal from EXTERNAL TRIGGER jack becomes sweep trigger. Trigger COUPLING Switch(24): Selects trigger coupling. Four-position level switch with the following positions: AC: Trigger signal is capacitively coupled. TV-V: Used for triggering from television vertical sync pulses. Also serves as lo- pass/dc (high frequency reject) trigger coupling.

  • Page 43: Operating Instructions

    Operating Instru ctions OSCILLOSCOPE INSTRUCTION MANUAL SAFETY PRECAUTIONS WARNIN G! The following precautions must be observed to help prevent electric shock: 1. When he oscilloscope is used to make measurements in equipment that contains high voltage, there is always a certain amount of danger from electrical shock. The person using the oscilloscope in such conditions should be a qualified electronics technician or otherwise trained and qualified to work in such circumstances.
  • Page 44 OPERATING INSTRUCTIONS 2. Do not obstruct the ventilating holes in the case, as this will increase the scope's internal temperature. 3. Excessive voltage applied to the input jacks may damage the oscilloscope. The maximum ratings of the inputs are as follows: Input Terminal Maximum Allowable Input Voltage CH1, CH2 Input...

  • Page 45: Operating Tips

    OPERATING INSTRUCTIONS OPERATING TIPS The following recommendations will help obtain the best performance from the oscilloscope. 1. Always use the probe ground clips for best results, attached to a circuit ground point near the point of measurement. Do not rely solely on an external ground wire in lieu of the probe ground clips as undesired signals may be introduced.

  • Page 46: Single Trace Display

    OPERATING INSTRUCTIONS All POSITION controls and INTENSITY control centered(pointers facing up). Main Time Base CONTROL TO 1 mS/DIV. Sweep Mode switch to MAIN. 2. Press the red POWER pushbutton. 3. A trace should appear on the CRT. Adjust the trace brightness with the INTENSITY control, and the trace sharpness with the FOCUS control.
  • Page 47 OPERATING INSTRUCTIONS 1. Connect probes to both the CH 1(X) and CH 2(Y) input jacks. 2. Connect the ground clips of the probes to the chassis or common of the equipment under test. Connect the tips of the probed to the two points in the circuit where waveforms are to be measured.

  • Page 48: Triggering

    OPERATING INSTRUCTIONS TRIGGERING The oscilloscope provides versatility in sync triggering for ability to obtain a stable, jitter-free display in single-trace, or dual-trace operation. The proper settings depend upon the type of waveforms being observed and the type of measurement desired. An explanation is given to help you select the proper setting over a wide range of conditions.
  • Page 49 OPERATING INSTRUCTIONS Trigger SOURCE Switch The trigger SOURCE switch (CH 1, CH 2, etc.) selects the signal to be used as the sync trigger. 1. If the SOURCE switch is set to CH 1 (CH 2) the channel 1 (or channel 2) signal becomes the trigger source regardless of the VERTICAL MODE selection.

  • Page 50: Time Base Control

    OPERATING INSTRUCTIONS HOLD OFF Control Controls hold-off time between sweep signals to obtain stable display when triggering a periodic signal. The control hold time ranges from 1 to 5 times time base. A complex waveform Heavy parts are display (Digital signal) Cycle Sweep Waveform...
  • Page 51 OPERATING INSTRUCTIONS 2. Sweep Magnification When a certain position of the displayed waveform is needed to be expanded time wise, a faster sweep speed may be used. However, if the required portion is far from the starting point of the sweep, the required portion may run off the CRT screen. In such a case, pull out (set in the x10 MAG state) the POSITION switch KNOB.

  • Page 52: X-Y Operation

    OPERATING INSTRUCTIONS The portion of A is main sweep which is set by the MAIN TIMEBASE. The portion of B is delay sweep witch is set by the DELAY TIME BASE. The mixed point C is continuously variable by means of the DELAY TIME POSITION switch. When turn the switch to DELAY position.
  • Page 53 OPERATING INSTRUCTIONS WAVEFORM CHART Fig.6 Ω Ω Ω 0 (short) resistor resistor μ μ μ F ceramic capacitor F electrolytic capacitor F electrolytic capacitor μ F electrolytic capacitor Silicon diode 4.7V zener diode 1000 Ω...

  • Page 54: Application

    Application OSCILLOSCOPE INSTRUCTION MANUAL DC VOLTAGE MEASUREMENTS (Refer to Fig.7) The following technique may be used to measure the instantaneous de level at any portion of a waveform, or to measure a dc voltage where no waveform is present. 1. Connect the signal to be measured to the input jack and set the CH 1/ CH 2 switch to the channel to be used.

  • Page 55: Measurement Of Voltage Between Two Point On A Waveform

    APPLICATION Adjust to the center vertical scale with Points to be measured POSITION Measuring point adjusted to the center vertical scale by position Ground potential Adjust to the horizontal adjusted by POSITION scale with POSITION (reference line) Fig.7 DC Voltage Measurement Fig.8 Voltage Measurement MEASUREMENT OF VOLTAGE BETWEEN TWO POINT ON A WAVEFORM...

  • Page 56: Time Measurements

    APPLICATION Fir the example shown in Fig.8, the two points are separated by 4.4 divisions vertically. If the VOLTS/DIV setting is 20 mV and a 10:1 probe is used, the voltage is calculated as follows: Voltage = 4.4 (div) x 20 (mV/DIV) x 10 = 880 mV TIME MEASUREMENTS (Refer to Fig.9) This is the procedure for Making time (period) measurements between two points on...

  • Page 57: Frequency Measurements

    APPLICATION For the example shown in Fig.9, the horizontal distance between the two points is 5.4 divisions. If the TIME/DIV is 0.2 ms and X10 magnification is not used, the time period is calculated as follows: Time = 5.4 (div) x 0.2 (ms/div) = 1.08 ms FREQUENCY MEASUREMENTS Method No.1 (Refer to Fig.10)
  • Page 58 APPLICATION Method No.2 (Refer to Fig.11) While the previously described method relies upon direct period measurement of one cycle, the frequency may also be measured by counting the number of cycles present in a given time period. 1. Set the oscilloscope to display several cycles of the waveform. The VAR SWEEP control must be set to CAL.

  • Page 59: Pulse Width Measurements

    APPLICATION PULSE WIDTH MEASUREMENTS (Refer to Fig.12) 1. Apply the pulse signal to the input jack and set the CH 1/CH 2 switch to the channel to be used. 2. Use the VOLTS/DIV and VARIABLE controls to adjust the display so the waveform is easily observed.

  • Page 60: Pulse Rise Time And Fall Time Measurements

    APPLICATION PULSE RISE TIME AND FALL TIME MEASUREMENTS (Refer to Fig.13) For rise time and fall time measurements, the 10% and 90% amplitude point are used as starting and ending reference points. 1. Apply a signal to the input jack and set the CH 1/CH 2 switch to the channel to be used.

  • Page 61: Time Difference Measurement

    APPLICATION TIME DIFFERENCE MEASUREMENT (Refer to Fig.14) This procedure is useful in measurement of time difference between signals that are synchronized to one another but skewed in time. 1. Apply the two signals to the CH1 and CH 2 input jacks and select the dual-trace display mode (either the CHOP or ALT mode).

  • Page 62: Phase Difference Measurements

    APPLICATION PHASE DIFFERENCE MEASUREMENTS Method No.1 (Refer to Fig.15) This procedure is useful in measuring the phase difference of signals of the same frequency. 1. Apply the two signals to the CH 1 and CH 2 input jacks, selecting the dual-trace display mode (either ALT or CHOP).
  • Page 63 APPLICATION Method No.2 (Refer to Fig.16) The above procedure allows 45 per division, which may not give the desired ° accuracy for small phase differences. If greater accuracy is required, the sweep TIME/DIV setting may be changed to expand the display as shown in Fig. ۱٦...

  • Page 64: X-Y Mode Applications

    APPLICATION X-Y MODE APPLICATIONS (Refer to Fig.17) A dual-trace method of phase measurement was previously described. A second method of phases measurement requires calculations based on the Lissajous patterns obtained using X-Y operation. Distortion due to non-linear amplification can also be displayed. A sine wave is applied to the audio circuit being tested.

  • Page 65: Frequency Response Measurements

    APPLICATION FREQUENCY RESPONSE MEASUREMENTS (Refer to Fig.19) 3.58 MHz 3.08 MHz 4.08 MHz 90%±10% +15%, -20% VALLEY 15% MAX TILT 10% MAX 4.50MHz Fig.19 Frequency Response Measurement A sweep generator and the X-Y mode of this oscilloscope may be used to measure the audio or RF frequency response of an active or passive device up to 20 MHz, such as an amplifier, band pass filter, coupling network, etc.

  • Page 66: Maintenance

    Maintenance OSCILLOSCOPE INSTRUCTION MANUAL WARNIN G! A following instruction are for use by qualified service personnel only. To avoid electrical shock, do not perform any servicing other contained in the operation instructions unless you are qualified to do so. High voltage up to 1,250 volts is present when cover is removed and the unit is operating.
  • Page 67 MAINTENANCE 2. Set the probe to X10 (compensation adjustment is not possible in the X1 position). 3. Touch tip of probe to CAL terminal. 4. Adjust oscilloscope controls to display 3 or 4 cycles of CAL square wave at 5 or 6 divisions amplitude.

  • Page 68: Block Diagram

    Block Diagram OSCILLOSCOPE INSTRUCTION MANUAL...
  • Page 71 TINSE0050S4 Ver.01.1...
