- Page 1 NOMINAL SIZE (mm) 4ft extension 1240 6ft extension 1860 8ft extension 2480 10ft extension 3100 12ft extension 3720...
- Page 2 WD40 or similar can be applied to the door wheels and lower door guides. Guarantee Your new Robinsons greenhouse is guaranteed for 10 years against faulty manufacture of the framework. This does not include glazing, mov- ing parts, accidental damage or wind damage.
- Page 3 THE FOLLOWING DIMENSIONS ARE THE EXACT EXTERNAL BASE DIMENSIONS FOR THE ROBINSONS RANGE. We cannot emphasis how important it is to have a proper base for your Robinsons Greenhouse to be erected upon. It is essential that the BASE IS FLAT, LEVEL AND SQUARE AS WELL AS BEING SUBSTANTIAL enough to take the weight of the greenhouse including its 4mm glass.
- Page 4 VICTORIAN ROBINSONS EXTENSIONS VERY IMPORTANT INFORMATION: If you have been supplied with an extension (i.e. your building is longer than 12’), your main building will differ in that the roof end and corner glazing bars (on the end to which the extension will be fitted) are replaced with side and roof glazing bars from the extension module kit. These should be fitted using 15mm bolts.
- Page 5 12’ Part Section Size 4’ 6’ 8’ 10’ (mm) VICTORIAN RIDGE EXTENSION VARIABLES DV240 1240 DV205 1860 DV206 2480 DV207 3100 DV208 3720 D114 DV101 12’ Part Section Size 4’ 6’ 8’ 10’ 12’ Part Section Size 4’ 6’ 8’ 10’...
- Page 6 DV240 D114 DV205 DV206 DV207 DV208 D138 D136 DV222 DV222 DV223 DV223 DV227 DV227 DV241L DV217L DV214L DV215L DV241R DV216L DV217R DV214R DV215R DV216R DV153 DV153 D136 D136 D075R D029R D024R D025R D026R D131 D114 D075L D673 D029L D131 D114 D024L D673 D025L...
- Page 7 DV240 DV205 DV222 DV206 DV223 DV207 DV208 15mm D114 D136 D138 D136 D136 FS6504 FS6006 DV222 DV223 D131 D673 DV222 DV223 FLIP VIEW DV153 D131 10mm 15mm DV227 D673 D131 D673 15mm D114...
- Page 8 D170 (FOIL COVERED TAPE) DV220 D201 D119 D214...
- Page 9 900mm up from bottom of base rail. Fitting Robinsons slatted shelving and staging using the instructions is usually quite straight forward. However if you have chosen a greenhouse which includes A-frames or a partition then fitting the staging becomes more complicated.
- Page 12 I will make the necessary amendments. Whilst the information contained in this booklet is accurate at the time of publication, changes in the course of Robinsons policy of improvement through development and design might not be indicated. We point out this fact to avoid any infringements of the Trade Descriptions Act and also to advise that Robinsons Greenhouses reserve the right to change specifications and materials without prior notice.
