Operating Instructions & Parts List for the
Manual# 107334
Issued: June 22, 2018
TMC# 818
For Assistance:
e-mail: service@bettcher.com
BETTCHER INDUSTRIES INC.
6801 State Route 60
Birmingham, OH 44889
U.S.A.
Phone: 440/965-4422
Phone: 800/321-8763
Fax: (440) 328-4535
www.bettcher.com/quantumflex

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quantum Flex X360 and is the answer not in the manual?

Questions and answers

Related Manuals for BETTCHER INDUSTRIES Quantum Flex X360

Summary of Contents for BETTCHER INDUSTRIES Quantum Flex X360

  • Page 1 Operating Instructions & Parts List for the Manual# 107334 Issued: June 22, 2018 TMC# 818 For Assistance: e-mail: service@bettcher.com BETTCHER INDUSTRIES INC. 6801 State Route 60 Birmingham, OH 44889 U.S.A. Phone: 440/965-4422 Phone: 800/321-8763 Fax: (440) 328-4535 www.bettcher.com/quantumflex...
  • Page 2 No part of this document may be reproduced or transmitted in any form or any means, electronic or mechanical, for any purpose, without the express written permission of Bettcher Industries Inc. Written permission to reproduce in whole or part is herewith granted to the legal owners of the ®...
  • Page 3 Table of Contents Section 1 ....Safety Section 2 ....Designated Use Section 3 ....Installation Section 4 ....Instructions for Operation Section 5 ....Maintenance Section 6 ....Cleaning Section 7 ....Service Parts Section 8 ....Contact and Document Information...

  • Page 5: Table Of Contents

    Safety Section 1 Safety CONTENTS OF THIS SECTION Signal Words & Signal Word Panels ..................1-2 Safety Symbols ........................1-3 Safety Recommendations and Warnings ................1-4 Safety Features ........................1-6 Ergonomic Features ........................1-6 Noise and Vibration Levels ......................1-6 The information provided in these operating instructions is important to WARNING your health, comfort and safety.

  • Page 6: Signal Words & Signal Word Panels

    Safety SIGNAL WORDS & SIGNAL WORD PANELS Indicates a hazardous situation that, if not avoided, will result in death or DANGER serious injury. (The signal word Danger is in white letters on a safety red background) Indicates a hazardous situation that, if not avoided, could result in death WARNING or serious injury.

  • Page 7: Safety Symbols

    Safety SAFETY SYMBOLS The safety alert symbol indicates a potential personal injury hazard. It is not used for messages related to property damage. The safety alert symbol may be used alone or in conjunction with a signal word in a signal word panel Danger of electrical shock Blade hazard, keep hands clear...

  • Page 8: Safety Recommendations And Warnings

    Bettcher Industries, Inc. Use only replacement parts manufactured by Bettcher Industries, Inc. Use of substitute parts will void the warranty and may cause injury to operators and damage to equipment.
  • Page 9 Safety SAFETY RECOMMENDATIONS AND WARNINGS (CONTINUED) If at any time this machine does not appear to operate normally or WARNING exhibits a marked change in performance, it should be immediately shut down, unplugged, and tagged as “UNSAFE” until such time as proper repairs are made and the machine again operates normally.

  • Page 10: Safety Features

    Safety SAFETY FEATURES ® All Quantum Flex tools have been designed for use with an optional disconnect which will stop blade rotation when the trigger/lever is released. This trigger/lever has been designed in such a way that minimal grip force is required for operation, using three fingers. ERGONOMIC FEATURES Small, Medium, and Large Handle sizes are available to help improve the operator's grip and comfort.
  • Page 11 Bettcher Industries, Inc. Use only replacement parts manufactured by Bettcher Industries, Inc. Use of substitute parts will void the warranty and may cause injury to operators and damage to equipment.

  • Page 12: Designated Use

    Designated Use DESIGNATED USE ® ® The Quantum Flex Trimmers are specifically designed for use with the Whizard Quantum Drive Unit, ® ® Whizard Ultra Drive Unit and the Whizard UN-84 Drive Unit. They are used for removal of fat and tissue, the recovery of lean meat from fat and as a universal cutting tool in the meat industry.

  • Page 13: Recommended Operation

    Designated Use RECOMMENDED OPERATION ® Quantum Flex Trimmers are made for several recommended operations. Ensure that you are using the correct tool for your specific application. The following recommendation list is not intended to be a total and comprehensive listing, but is offered as a guide. Additional applications are possible. Model X350 / X360 BEEF KILL / OFFAL POULTRY...
  • Page 14 Designated Use RECOMMENDED OPERATION (CONTINUED) Model X564 PORK KILL Remove Tenderloin Mark Tenderloin Model X620 / X620A BEEF KILL / OFFAL POULTRY PORK KILL / OFFAL Removing lean from heads Removing lean from turkey Removing eyelids carcasses De-veining livers Cleaning stick wounds Removing lean from turkey Removing eardrums necks...
  • Page 15 Designated Use RECOMMENDED OPERATION (CONTINUED) Model X625 BEEF POULTRY PORK Upgrading Retrim Fat trimming of turkey thighs Fat trimming of pork loins Trimming of turkey skins Model X750 FOAM INDUSTRY PORK KILL PORK CUT Remove defects Remove cheek meat Remove diaphragm lean Flash trimming Remove blood clots from jowls Removal of picnic hearts...
  • Page 16 Designated Use RECOMMENDED OPERATION (CONTINUED) Model X880-S / X1880 with adjustable depth gauge TOP ROUNDS / BOTTOM HOG KILL / HOT CUT / HAM ROUNDS / BRISKETS / TURKEY PROCESSING CUBE STEAK MATERIAL Remove skin or hair patches Removing membranes and light Defatting turkey thighs fat covering Trimming pork loins and...
  • Page 17 Designated Use RECOMMENDED OPERATION (CONTINUED) Model X1400 with adjustable depth gauge PORK PROCESSING BEEF PROCESSING Defatting: Carcass hair & dirt removal - Whole hams Defatting: - Shoulders - New York strips & sirloin butts - Canadian Backs - Rounds and ribeyes Removing beater marks Scraping leaf lard Model X1500 with adjustable depth gauge...

  • Page 18: Function

    Designated Use FUNCTION ® Quantum Flex Trimmers are durable and efficient, promoting higher yields for meat and poultry ® trimming. Quantum Flex Trimmers are superbly designed for ease of handling while reducing operator fatigue. A vertically hung motor drives a flexible shaft. The flexible shaft drives a rotating blade in the handpiece via a gear and pinion.
  • Page 19 Unpacking and Installation Section 3 Unpacking and Installation CONTENTS OF THIS SECTION Contents ..........................3-2 Work Station ..........................3-3 Optional Thumb Support and Handle Adjustment ..............3-4 ® Optional Whizard Micro-Break Hand Strap and Adjustment ..........3-7 Optional Disc Gauge or Depth Gauge Installation ..............3-8 Optional Post Handle Kit ......................3-9 ®...

  • Page 20: Contents

    CONTENTS ® The following parts are included with each Quantum Flex Trimmer. Please check when unpacking and advise your local Bettcher Industries representative if the delivery is incomplete. Models: X350, X360, X440, X500, X500A, X505, X564, X620, X620A, X625 PART...

  • Page 21: Work Station

    Unpacking and Installation WORK STATION Correct installation is extremely important to achieve maximum efficiency ® for both the Quantum Flex Trimmer unit being used and the operator. Incorrect installation may possibly hamper the operator's movements and cause undue wear or damage to the driveline and parts of the unit. The work station for each operator should be designed so that the operator's movements in ®...

  • Page 22: Optional Thumb Support And Handle Adjustment

    Unpacking and Installation OPTIONAL THUMB SUPPORT AND HANDLE ADJUSTMENT ® Your Quantum Flex Trimmer has been supplied with a spacer ring or optional thumb support. If using the optional thumb support, the operator's thumb should be fully supported and rest comfortably in the support.
  • Page 23 Unpacking and Installation OPTIONAL THUMB SUPPORT AND HANDLE ADJUSTMENT (CONTINUED) ® The Quantum Flex Trimmers have been designed to allow the head of the tool and the thumb support to be rotated relative to the handle. In this way, the tool can be adjusted to position the blade properly to the product while the handle can be set to allow the operator to have a comfortable position for the wrist.
  • Page 24 Unpacking and Installation OPTIONAL THUMB SUPPORT AND HANDLE ADJUSTMENT (CONTINUED) NOTE: It may be necessary to rotate the grease cup to a new position to adjust the thumb support to the desired position. • Rotate the handle to a new position and push it forward to engage the frame splines. NOTE: The handle can be adjusted to suit the operator and the work station by pulling the handle back away from the frame and re-locating it on another set of notches on the frame tube.

  • Page 25: Optional Whizard ® Micro-Break Hand Strap And Adjustment

    Unpacking and Installation ® OPTIONAL WHIZARD MICRO-BREAK HAND STRAP AND ADJUSTMENT ® The Whizard Micro-Break Hand Strap has been designed to allow the user to relax the *5200(7 fingers of the hand between work cycles while maintaining control of the trimmer, which can be beneficial and may reduce risks associated with stress.

  • Page 26: Optional Disc Gauge Or Depth Gauge Installation

    Unpacking and Installation OPTIONAL DISC GAUGE OR DEPTH GAUGE INSTALLATION Optional Disc Gauges for Models: X850, X1850, X1000 and $'-8670(17 X1300 .12% Optional adjustable disc gauges are available for the X1000 and X1300 trimmers. Refer to Section 7, Service Parts to order. •...

  • Page 27: Optional Post Handle Kit

    Unpacking and Installation OPTIONAL POST HANDLE KIT To reduce the possibility of cumulative trauma to the wrist caused by the excessive bending (Ulnar Deviation) necessary to perform certain trimming or defatting operations, a post handle ® option is available for all Quantum Flex Trimmers.

  • Page 28: The Disconnect Casing

    Unpacking and Installation ® ATTACHING QUANTUM FLEX TRIMMER TO THE WHIZARD ® ® QUANTUM DRIVELINE OR WHIZARD FLEXSHAFT AND CASING ASSEMBLY The Disconnect Casing • Hold the trimmer in the hand you will use in operation, and with the other hand, grasp the ®...

  • Page 29: Non-Disconnect Models

    Unpacking and Installation ® ATTACHING QUANTUM FLEX TRIMMER TO THE WHIZARD ® ® QUANTUM DRIVELINE OR WHIZARD FLEXSHAFT AND CASING ASSEMBLY (CONTINUED) Non-Disconnect Models • ® Hold Quantum Flex Trimmer in the hand you will use in operation. • ® ®...

  • Page 30: Drive Unit

    Unpacking and Installation ® ATTACHING WHIZARD QUANTUM DRIVELINE TO THE WHIZARD ® QUANTUM DRIVE UNIT ® Install Whizard Quantum Driveline to Disconnect Body Insert proper end of the driveline into disconnect body. The driveline will latch in place when fully CASING RETAINER DISCONNECT BODY LATCH...

  • Page 31: Preparation For Operation

    Unpacking and Installation PREPARATION FOR OPERATION Sharp blades may cause cut injury! WARNING For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades. Metal mesh gloves are recommended for the free hand. ALWAYS check to ensure that the blade is free to rotate in the machine prior to starting.
  • Page 32 Unpacking and Installation THIS PAGE INTENTIONALLY LEFT BLANK 3-14 Unpacking and Installation Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 33 Instructions for Operation Section 4 Instructions for Operation CONTENTS OF THIS SECTION Operating Instructions ......................4-2 Optional Disc Gauges for Models: X850, X1850, X1000 and X1300 ........4-3 Adjustable Depth Gauge for Models: X880 (S&B), X1880, X1400 and X1500 Only ....4-3 Steeling the Blade ........................4-4 Blade Changing - Small Tools ....................4-6 Blade Changing - Large Tools ....................4-8 Manual No.

  • Page 34: Operating Instructions

    Instructions for Operation OPERATING INSTRUCTIONS ® Always hold the handpiece of the Quantum Flex Trimmer with your thumb extended. Let the handpiece rest naturally in the palm of the hand in a relaxed manner. Each person should be allowed to hold the handpiece in a position that is most comfortable to them. The most-used motion is a long sweeping or gliding stroke across the trimming surface.

  • Page 35: Optional Disc Gauges For Models: X850, X1850, X1000 And X1300

    Instructions for Operation OPERATING INSTRUCTIONS (CONTINUED) Optional Disc Gauges for Models: X850, X1850, X1000 and X1300 $'-8670(17 .12% Optional adjustable disc gauges are available for the X1000 and X1300 trimmers. Refer to Section 7, Service Parts to order. To adjust depth: •...

  • Page 36: Steeling The Blade

    Instructions for Operation STEELING THE BLADE Use the Whizard Special Steel anytime you feel the edge of the blade needs to be raised for better cutting action. Steeling For Models: X360, X505, X850, X880, X1850, X1880, X1000, X1300, X1400 and X1500 ®...
  • Page 37 Whizard Edge Master Steels. For more information contact your Sales Representative at Bettcher Industries. Refer to Section 7, Blade Sharpening and Steeling Equipment. Replace or sharpen the blade if this procedure does not improve the cutting action. Blade running ®...

  • Page 38: Blade Changing - Small Tools

    Instructions for Operation BLADE CHANGING - SMALL TOOLS Sharp blades may cause cut injury! WARNING For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades. Metal mesh gloves are recommended for the free hand. Keep hands away from moving blade.
  • Page 39 Instructions for Operation BLADE CHANGING - SMALL TOOLS (CONTINUED) Blade Installation - Small Tools Models: X350, X360, X440, X500, X505, X500A, X564, X620, X625, X620A WARNING Sharp blades may cause cut injury! For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades.

  • Page 40: Blade Changing - Large Tools

    Instructions for Operation BLADE CHANGING - LARGE TOOLS Sharp blades may cause cut injury! WARNING For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades. Metal mesh gloves are recommended for the free hand. Keep hands away from moving blade.
  • Page 41 Instructions for Operation BLADE CHANGING - LARGE TOOLS (CONTINUED) Blade Installation - Large Tools (Models: X750, X850, X1000, X1300, X1400, X1500, X1850, X1880) Turn the tool over so the blade side is up. Spread open the blade housing with a screwdriver. NOTE: A slight tension on the left cover screw will allow the blade housing to stay open on its own.
  • Page 42 Instructions for Operation BLADE CHANGING - LARGE TOOLS (CONTINUED) Blade is too loose • If the blade is too loose in the housing, adjustments can be made by slightly loosening the left cover retaining screw and squeezing the housing lightly. Check the housing for proper running clearance and retighten the left cover screw to 35 in-lb.
  • Page 43 Maintenance Section 5 Maintenance CONTENTS OF THIS SECTION ® ® Removing Whizard Quantum Driveline from the Whizard Quantum Drive Unit ....5-2 ® ® ® Removing Whizard Flexshaft and Casing Assembly from the Whizard UN-84 OR Whizard Ultra Drive Unit ..........................5-2 ®...

  • Page 44: Removing Whizard ® Flexshaft And Casing Assembly From The Whizard

    Maintenance ® REMOVING WHIZARD QUANTUM DRIVELINE FROM THE ® WHIZARD QUANTUM DRIVE UNIT ® Remove Whizard Quantum Driveline from Disconnect Body Hold driveline assembly around the top exposed portion, just below the disconnect CASING RETAINER DISCONNECT BODY LATCH body. Push casing retainer latch inward and pull driveline down and out of disconnect body.

  • Page 45: Removing Quantum Flex ® Trimmer From The Whizard Quantum ® Driveline Or Whizard ® Flexshaft And Casing Assembly

    Maintenance ® REMOVING QUANTUM FLEX TRIMMER FROM THE WHIZARD ® ® QUANTUM DRIVELINE OR WHIZARD FLEXSHAFT AND CASING ASSEMBLY Non-Disconnect Models • ® Hold Quantum Flex Trimmer in the hand you will use in operation. • With opposite hand, press the latch button in the handle retaining knob.
  • Page 46 Maintenance DISASSEMBLY OF HANDPIECE Sharp blades may cause cut injury! WARNING For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades. Metal mesh gloves are recommended for the free hand. Keep hands away from moving blade.

  • Page 47: Disassembly Of Handpiece (Continued)

    Maintenance DISASSEMBLY OF HANDPIECE (CONTINUED) Sharp blades may cause cut injury! WARNING For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades. Metal mesh gloves are recommended for the free hand. Keep hands away from moving blade.
  • Page 48 Maintenance DISASSEMBLY OF HANDPIECE (CONTINUED) ® Remove the Optional Whizard *5200(7 Micro-Break Hand Straps • Remove the grease cup and retaining knob to remove primary and secondary hand straps. 6(&21'$5< 675$3 35,0$5< 675$3 675$3 5,1* Maintenance Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 49 Maintenance DISASSEMBLY OF HANDPIECE (CONTINUED) Remove the Handle Retaining Knob • Turn retaining knob counterclockwise. +$1'/( 5(7$,1,1* .12% Remove the Handle from the Tool • +$1'/( Pull the handle off the tube. • Remove the handle spacer ring or optional thumb support.
  • Page 50 Maintenance DISASSEMBLY OF HANDPIECE (CONTINUED) Cam Removal from the Cam Plate Assembly - Small Tools Only Models: X350, X360, X440, X500, X505, X500A, X564, X620, X625, X620A • Position the cam and cam plate assembly so that 60$// 7$%6 the small tabs located on the cam are facing upward.
  • Page 51 Maintenance DISASSEMBLY OF HANDPIECE (CONTINUED) Remove the Blade Housing and Cover Plate - Large Tools Only • Loosen cover retaining screws until the cover is free. &29(5 5(7$,1,1* 6&5(:6  )5$0( NOTE: The screws will stay in the frame. • Remove the blade housing.
  • Page 52 Maintenance DISASSEMBLY OF HANDPIECE (CONTINUED) Remove the Bearing from the Frame • The bearing is pulled out from the front of the tool. • Use a screwdriver to reach into the bearing and catch the bearing grease groove. NOTE: The bearing in the small tool does not have grease grooves.

  • Page 53: Daily Inspections & Maintenance

    Maintenance DAILY INSPECTIONS & MAINTENANCE WARNING Inspection of all parts for excessive wear is critical to ensure proper and safe operation. Vibration or lock-up may occur as a result of the use of excessively worn parts. Sharp blades may cause cut injury! Always disconnect power and remove the tool from the driveline or flexshaft and casing assembly prior to servicing.
  • Page 54 Maintenance DAILY INSPECTIONS & MAINTENANCE (CONTINUED) Blade Housing Wear Small Tool Models: X350, X360, X440, X500, X505, X500A, X564, X620, X625, X620A • Inspect the inner diameter of the housing for wear • With a new blade installed in the housing on the tool carefully check for movement of the blade in the housing from side to side and up and down.
  • Page 55 Maintenance DAILY INSPECTIONS & MAINTENANCE (CONTINUED) Cover Plate • Look for signs of corrosion or wear on the cover. • Pay special attention to the area covering the gear teeth. • If the edge of the cover is worn, exposing the pinion and blade teeth, the cover should be replaced.
  • Page 56 Maintenance DAILY INSPECTIONS & MAINTENANCE (CONTINUED) ® Whizard Quantum Driveline Inspection • ® The Whizard Quantum Driveline includes a casing and flexible shaft that is factory FLEXSHAFT DRIVER lubricated and does not require ongoing maintenance lubrication. • NOTE: The flexible shaft is not removable from the casing.
  • Page 57 Maintenance DAILY INSPECTIONS & MAINTENANCE (CONTINUED) ® Whizard Quantum Driveline Replacement • When the driveline needs to be replaced, the driver assembly may be retained and reused. • Hold the driveline (#1) in a vise. • Unscrew the driver assembly (#4) by turning counterclockwise using the wrench flats on the drive end assembly.

  • Page 58: Driver Assembly Inspection And Replacement

    Maintenance DRIVER ASSEMBLY INSPECTION AND REPLACEMENT ® Whizard Quantum Driver Assembly Inspection • Make certain the driver shaft and tip rotate freely and also that they can slide back and forth freely. • Check for wear on the bearing at the end of the tube assembly. If the bearing flange is excessively worn, replace the tube assembly.
  • Page 59 Maintenance DRIVER ASSEMBLY INSPECTION AND REPLACEMENT (CONTINUED) ® Assembly of the Whizard Quantum Driver Assembly Do not overtighten the driver tip. Doing so could break the driver shaft. • Apply Max-Z-lube grease to the 2 bearing areas of the driver shaft. Refer to Section 7, Lubrication and Lubrication Equipment.
  • Page 60 Maintenance ® DAILY INSPECTION AND MAINTENANCE - WHIZARD FLEXSHAFT AND CASING ASSEMBLY • Inspect the casing for any cracks, tears, or other wear. If any damage is found, replace the casing. • Remove the flexshaft from the casing and check for any flexshaft damage, such as broken wires or kinking.
  • Page 61 Maintenance ® MAINTENANCE - WHIZARD FLEXSHAFT AND CASING ASSEMBLY Casing Replacement • When the casing needs to be replaced, the drive end assembly may be retained and reused. • Hold the casing (#1) in a vise. • Unscrew the drive end assembly (#4) by turning counterclockwise using the wrench flats on the drive end assembly.
  • Page 62 Maintenance DAILY INSPECTION AND MAINTENANCE - WHIZARD ® FLEXSHAFT AND CASING ASSEMBLY (CONTINUED) Reassemble the Drive End Assembly to a New Casing • If using the casing disconnect, place the disconnect lever (#6) onto the lever mounting collar (#5). • Slip the casing latch collar (#2) or lever mounting collar (#5) with disconnect lever (#6) onto the new casing.
  • Page 63 Maintenance MAINTENANCE - WHIZARD FLEXSHAFT AND CASING ® ASSEMBLY (CONTINUED) Inspection of the Driver Assembly • Wipe off excess grease. • Inspect the split bearing (#5) for wear or damage. Replace if required. • Slide the knurled cap (#6) forward against the driver tip (#7).
  • Page 64 Maintenance MAINTENANCE - WHIZARD FLEXSHAFT AND CASING ® ASSEMBLY (CONTINUED) Replacement of Split Bearing (#3) • Rmove the driver assembly. Refer to Section 5, Removal of the driver assembly • Insert a small screwdriver into the split in the bearing. •...

  • Page 65: Blade Sharpening

    Maintenance BLADE SHARPENING Sharp blades may cause cut injury! WARNING For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades. After sharpening, all abrasive dust must be completely removed from the handpiece.

  • Page 66: Assembly Of Handpiece

    Maintenance ASSEMBLY OF HANDPIECE Sharp blades may cause cut injury! WARNING For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades. Metal mesh gloves are recommended for the free hand. Keep hands away from moving blade.
  • Page 67 Maintenance ASSEMBLY OF HANDPIECE (CONTINUED) Sharp blades may cause cut injury! WARNING For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades. Metal mesh gloves are recommended for the free hand. Keep hands away from moving blade.
  • Page 68 Maintenance ASSEMBLY OF HANDPIECE (CONTINUED) Blade Housing, Finger Guard, Cam Plate Assembly, and Cover Plate Installation - Small Tools Only Models: X350, X360, X440, X500, X505, X500A, X564, X620, X625, X620A • Place the cover on the frame and tighten the cover retaining ),1*(5 *8$5' screws.
  • Page 69 Maintenance ASSEMBLY OF HANDPIECE (CONTINUED) Cam Installation into the Cam Plate Assembly - Small Tools Only Models: X350, X360, X440, X500, X505, &859( X500A, X564, X620, X625, X620A • Position the cam plate assembly so that the two spring wires are visible and the curve is facing away from you.
  • Page 70 Maintenance ASSEMBLY OF HANDPIECE (CONTINUED) Pinion Installation • The pinion should fit freely into the bearing. Blade Housing and Cover Plate Installation - Large Tools Models: X750, X850, X1000, X1300, X1400, X1500, X1850, X1880 • Set the blade housing on the frame and put the cover plate on. •...
  • Page 71 Maintenance ASSEMBLY OF HANDPIECE (CONTINUED) Grease Cup and Ring • ® Pick up the Quantum Flex Trimmer. GREASE CUP • Pick up the grease cup and ring. Apply a small ® amount of Whizard Quantum High Performance Grease to the frame o-rings. GREASE RING •...
  • Page 72 Maintenance ASSEMBLY OF HANDPIECE (CONTINUED) Thumb Support Angle Adjustment • Lift up on the front of the thumb support until the lug comes out of the notch underneath the thumb support. • Rotate the thumb rest to a new position. •...
  • Page 73 Maintenance ASSEMBLY OF HANDPIECE (CONTINUED) Handle • While holding the trimmer, pick up a handle. +$1'/( • Firmly push the handle towards the bottom of the spacer ring or optional thumb support. Align the handle spline with the splines on the front of the tube. •...
  • Page 74 Maintenance ASSEMBLY OF HANDPIECE (CONTINUED) Blade Installation - Small Tools Models: X350, X360, X440, X500, X505, X500A, X564, X620, X625, X620A WARNING Sharp blades may cause cut injury! For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades.
  • Page 75 Maintenance ASSEMBLY OF HANDPIECE (CONTINUED) Blade Installation - Large Tools Models: X750, X850, X1000, X1300, X1400, X1500, X1850, X1880 WARNING Sharp blades may cause cut injury! For proper protection of hands, a protective glove should be used when operating this equipment and during the handling of blades. Metal mesh gloves are recommended for the free hand.
  • Page 76 Maintenance ASSEMBLY OF HANDPIECE (CONTINUED) Blade Installation (Continued) • Adjust the housing for proper running clearance. The blade should turn freely with a slight side-to-side motion. This leaves room for the grease WARNING! Make certain that the blade is free to rotate in the housing. If the blade does not turn freely, it may cause the tool to rotate in the hand.

  • Page 77: Optional Disc Gauge Or Depth Gauge Installation And Adjustment

    Maintenance OPTIONAL DISC GAUGE OR DEPTH GAUGE INSTALLATION AND ADJUSTMENT Optional Disc Gauges for Models: X850, X1850, X1000 and X1300 $'-8670(17 .12% Optional adjustable disc gauges are available for the X850, X1850, X1000 and X1300 trimmers. Refer to Section 7, Service Parts to order. •...
  • Page 78 Maintenance OPTIONAL DISC GAUGE OR DEPTH GAUGE INSTALLATION AND ADJUSTMENT (CONTINUED) Adjustable Depth Gauge for Models: X880 (B&S), X1880, X1400 and X1500 Only These tools come equipped with an adjustable depth gauge for setting a controlled product trim thickness. The depth gauge can be adjusted for cuts up to ¼” thick. $77$&+0(17 A depth gauge setting device is also available.

  • Page 79: Optional Whizard ® Micro-Break Hand Strap And Adjustment

    Maintenance ® OPTIONAL WHIZARD MICRO-BREAK HAND STRAP AND ADJUSTMENT ® The Whizard Micro-Break Hand Strap has *5200(7 been designed to allow the user to relax the fingers of the hand between work cycles while maintaining control of the trimmer, which can be beneficial and may reduce risks associated 6(&21'$5<...

  • Page 80: Optional Post Handle Kit And Adjustment

    Maintenance OPTIONAL POST HANDLE KIT AND ADJUSTMENT To reduce the possibility of cumulative trauma to the wrist caused by the excessive bending (Ulnar Deviation) necessary to perform certain trimming or defatting operations, a post handle ® option is available for all Quantum Flex Trimmers.

  • Page 81: Fault Detection And Correction

    Maintenance FAULT DETECTION AND CORRECTION PROBLEM PROBABLE CAUSE REMEDY Inside bore of handpiece Replace frame. frame worn out. Worn handpiece bearing. Replace. Worn pinion gear. Replace. Worn teeth on blade or pin- Replace. ion gear. Large Tools Only - Adjust blade Handpiece Vibration Blade too loose in blade housing.
  • Page 82 Maintenance FAULT DETECTION AND CORRECTION (CONTINUED) PROBLEM PROBABLE CAUSE REMEDY Sharpening can best be accomplished by use of a Improperly sharpened blades ® will cause loss of production, Whizard Model 210 Universal increase wear of parts, and ® Blade Sharpener, or Bettcher Dull Blade operator fatigue.
  • Page 83 The recommended cleaning solution for the Quantum Flex Trimmer is eXtra© Heavy Duty Cleaner. eXtra© Heavy Duty Cleaner, (PN: 184332), is a concentrated cleaner and degreaser for food processing equipment. Contact Bettcher Industries, Inc. for details. Manual No. 107334 Cleaning ®...
  • Page 84 Cleaning CLEANING SOLUTIONS Avoid the use of aggressive cleaning products as they will damage the aluminum handle assembly. Do not use hydrocarbon solvents on the driveline or casing. This will cause driveline or casing to shrink in length and become brittle. CLEANING PRIOR TO ASSEMBLY Prior to assembly, be sure all parts are clean and have been inspected for wear.
  • Page 85 Bettcher Industries, Inc. Use only replacement parts manufactured by Bettcher Industries, Inc. Use of substitute parts will void the warranty and may cause injury to operators and damage to equipment.
  • Page 86 Service Parts Section 7 Service Parts CONTENTS OF THIS SECTION (CONTINUED) ® Whizard Quantum Driveline Assembly - Small Tools Only ..........7-52 ® Whizard Quantum Driveline Assembly - Large Tools Only ..........7-54 ® Whizard 3/16” Flexshaft and Casing Assembly - Small Tools Only ........7-56 ®...
  • Page 87 Service Parts THIS PAGE INTENTIONALLY LEFT BLANK Manual No. 107334 Service Parts ® June 22, 2018 Operating Instructions and Parts List for the Quantum Flex Trimmer...

  • Page 88: Quantum Flex ® X350 Assembly

    Service Parts ® QUANTUM FLEX X350 ASSEMBLY Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 89 Service Parts ® QUANTUM FLEX X350 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 101090 Parts for Grease Cup Washer 123523 Retainer Ring Only 101576 Bulb 163265 Base and Fitting 101089 Frame Assembly 107168 Frame o-rings (2 required)

  • Page 90: Quantum Flex ® X360 Assembly

    Service Parts ® QUANTUM FLEX X360 ASSEMBLY Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 91 Service Parts ® QUANTUM FLEX X360 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 101090 Parts for Grease Cup Washer 123523 Retainer Ring Only 101576 Bulb 163265 Base and Fitting 101089 Frame Assembly 107168 Frame o-rings (2 required)

  • Page 92: Quantum Flex ® X440 Assembly

    Service Parts ® QUANTUM FLEX X440 ASSEMBLY Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 93 Service Parts ® QUANTUM FLEX X440 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 101090 Parts for Grease Cup Washer 123523 Retainer Ring Only 101576 Bulb 163265 Base and Fitting 101089 Frame Assembly 107168 Frame o-rings (2 required)

  • Page 94: Quantum Flex ® X500 Assembly

    Service Parts ® QUANTUM FLEX X500 ASSEMBLY 7-10 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 95 Service Parts ® QUANTUM FLEX X500 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 101090 Parts for Grease Cup Washer 123523 Retainer Ring Only 101576 Bulb 163265 Base and Fitting 101089 Frame Assembly 107168 Frame o-rings (2 required)

  • Page 96: Quantum Flex ® X505 Assembly

    Service Parts ® QUANTUM FLEX X505 ASSEMBLY 7-12 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 97 Service Parts ® QUANTUM FLEX X505 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 101090 Parts for Grease Cup Washer 123523 Retainer Ring Only 101576 Bulb 163265 Base and Fitting 101089 Frame Assembly 107168 Frame o-rings (2 required)

  • Page 98: Quantum Flex ® X500A Assembly

    Service Parts ® QUANTUM FLEX X500A ASSEMBLY 7-14 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 99 Service Parts ® QUANTUM FLEX X500A ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 101090 Parts for Grease Cup Washer 123523 Retainer Ring Only 101576 Bulb 163265 Base and Fitting 101089 Frame Assembly 107168 Frame o-rings (2 required)

  • Page 100: Quantum Flex ® X564 Assembly

    Service Parts ® QUANTUM FLEX X564 ASSEMBLY 7-16 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 101 Service Parts ® QUANTUM FLEX X564 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 101090 Parts for Grease Cup Washer 123523 Retainer Ring Only 101576 Bulb 163265 Base and Fitting 101089 Frame Assembly 107168 Frame o-rings (2 required)

  • Page 102: Quantum Flex ® X620 Assembly

    Service Parts ® QUANTUM FLEX X620 ASSEMBLY 7-18 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 103 Service Parts ® QUANTUM FLEX X620 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 101090 Parts for Grease Cup Washer 123523 Retainer Ring Only 101576 Bulb 163265 Base and Fitting 101089 Frame Assembly 107168 Frame o-rings (2 required)

  • Page 104: Quantum Flex ® X625 Assembly

    Service Parts ® QUANTUM FLEX X625 ASSEMBLY 7-20 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 105 Service Parts ® QUANTUM FLEX X625 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 101090 Parts for Grease Cup Washer 123523 Retainer Ring Only 101576 Bulb 163265 Base and Fitting 101089 Frame Assembly 107168 Frame o-rings (2 required)

  • Page 106: Quantum Flex ® X620A Assembly

    Service Parts ® QUANTUM FLEX X620A ASSEMBLY 7-22 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 107 Service Parts ® QUANTUM FLEX X620A ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 101090 Parts for Grease Cup Washer 123523 Retainer Ring Only 101576 Bulb 163265 Base and Fitting 101089 Frame Assembly 107168 Frame o-rings (2 required)

  • Page 108: Quantum Flex ® X750 Assembly

    Service Parts ® QUANTUM FLEX X750 ASSEMBLY 7-24 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 109 Service Parts ® QUANTUM FLEX X750 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 100998 Parts for Grease Cup Bulb and Washer 173208 Retainer Ring Only 101577 Base and Fitting 100999 Frame Assembly 105456 Frame o-rings (2 required)

  • Page 110: Quantum Flex ® X850 Assembly

    Service Parts ® QUANTUM FLEX X850 ASSEMBLY 7-26 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 111 Service Parts ® QUANTUM FLEX X850 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 100998 Parts for Grease Cup Retainer Ring Only 101577 Bulb and Washer 173208 Base and Fitting 100999 Frame Assembly 105456 Frame o-rings (2 required)
  • Page 112 Service Parts ® QUANTUM FLEX X850 ASSEMBLY (CONTINUED) 7-28 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 113 Service Parts ® QUANTUM FLEX X850 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Spacer Ring (Small Handle) 101030 Handle Spacer Ring (Medium and Large Handles) 101130 Thumb Support Assembly 101021 Disc gauge Kit (Optional) X850-S (Skinner) 183801 Parts for Disc Gauge Knob 183791 Frame Assembly...

  • Page 114: Quantum Flex ® X880-B Assembly

    Service Parts ® QUANTUM FLEX X880-B ASSEMBLY 7-30 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 115 Service Parts ® QUANTUM FLEX X880-B ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 100998 Parts for Grease Cup Retainer Ring Only 101577 Bulb and Washer 173208 Base and Fitting 100999 Frame Assembly 105456 Frame o-rings (2 required)

  • Page 116: Quantum Flex ® X880-S Assembly

    Service Parts ® QUANTUM FLEX X880-S ASSEMBLY 7-32 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 117 Service Parts ® QUANTUM FLEX X880-S ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 100998 Parts for Grease Cup Retainer Ring Only 101577 Bulb and Washer 173208 Base and Fitting 100999 Frame Assembly 105456 Frame o-rings (2 required)

  • Page 118: Quantum Flex ® X1850 Assembly

    Service Parts ® QUANTUM FLEX X1850 ASSEMBLY 7-34 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 119 Service Parts ® QUANTUM FLEX 1850 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 100998 Parts for Grease Cup Retainer Ring Only 101577 Bulb and Washer 173208 Base and Fitting 100999 Frame Assembly 105456 Frame o-rings (2 required)
  • Page 120 Service Parts ® QUANTUM FLEX X1850 ASSEMBLY (CONTINUED) 7-36 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 121 Service Parts ® QUANTUM FLEX X1850 (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Spacer Ring (Small Handle) 101030 Handle Spacer Ring (Medium and Large Handles) 101130 Thumb Support Assembly 101021 Disc gauge Kit (Optional) X1850-K 184479 Parts for Disc Gauge Knob 183791 Frame Assembly 183798...

  • Page 122: Quantum Flex ® X1880 Assembly

    Service Parts ® QUANTUM FLEX X1880 ASSEMBLY 7-38 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 123 Service Parts ® QUANTUM FLEX X1880 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 100998 Parts for Grease Cup Retainer Ring Only 101577 Bulb and Washer 173208 Base and Fitting 100999 Frame Assembly 105456 Frame o-rings (2 required)

  • Page 124: Quantum Flex ® X1000 Assembly

    Service Parts ® QUANTUM FLEX X1000 ASSEMBLY 7-40 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 125 Service Parts ® QUANTUM FLEX X1000 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 100998 Parts for Grease Cup Retainer Ring Only 101577 Bulb and Washer 173208 Base and Fitting 100999 Frame Assembly 105514 Frame o-rings (2 required)
  • Page 126 Service Parts ® QUANTUM FLEX X1000 ASSEMBLY (CONTINUED) 7-42 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 127 Service Parts ® QUANTUM FLEX X1000 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Spacer Ring (Small Handle) 101030 Handle Spacer Ring (Medium and Large Handles) 101130 Thumb Support Assembly 101021 Disc gauge Kit (Optional) X1000-S (Skinner) 183792 X1000-F (Fat) 183793 X1000-N (Special) 184365 Parts for Disc Gauge...

  • Page 128: Quantum Flex ® X1300 Assembly

    Service Parts ® QUANTUM FLEX X1300 ASSEMBLY 7-44 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 129 Service Parts ® QUANTUM FLEX X1300 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 100998 Parts for Grease Cup Retainer Ring Only 101577 Bulb and Washer 173208 Base and Fitting 100999 Frame Assembly 105514 Frame o-rings (2 required)
  • Page 130 Service Parts ® QUANTUM FLEX X1300 ASSEMBLY (CONTINUED) 7-46 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 131 Service Parts QUANTUM FLEX X1300 ASSEMBLY (CONTINUED) ® ITEM DESCRIPTION PART NUMBER Handle Spacer Ring (Small Handle) 101030 Handle Spacer Ring (Medium and Large Handles) 101130 Thumb Support Assembly 101021 Disc gauge Kit (Optional) X1300-S (Skinner) 183794 X1300-F (Fat) 183795 X1300-K (Kebab) 184993 Parts for Disc Gauge...

  • Page 132: Quantum Flex ® X1400 Assembly

    Service Parts ® QUANTUM FLEX X1400 ASSEMBLY 7-48 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 133 Service Parts ® QUANTUM FLEX X1400 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 100998 Parts for Grease Cup Retainer Ring Only 101577 Bulb and Washer 173208 Base and Fitting 100999 Frame Assembly 105514 Frame o-rings (2 required)

  • Page 134: Quantum Flex ® X1500 Assembly

    Service Parts ® QUANTUM FLEX X1500 ASSEMBLY 7-50 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 135 Service Parts ® QUANTUM FLEX X1500 ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Handle Retaining Knob 100649 ® 103060 Whizard Strap Assembly Grease Cup 100998 Parts for Grease Cup Retainer Ring Only 101577 Bulb and Washer 173208 Base and Fitting 100999 Frame Assembly 105514 Frame o-rings (2 required)
  • Page 136 Service Parts ® WHIZARD QUANTUM DRIVELINE ASSEMBLY - SMALL TOOLS ONLY ® FOR USE WITH WHIZARD QUANTUM DRIVE   60$// 722/ '5,9(5 7,3   /$5*( 722/ '5,9(5 7,3 7-52 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...

  • Page 137: Whizard Quantum ® Driveline Assembly - Small Tools Only

    Service Parts ® WHIZARD QUANTUM DRIVELINE ASSEMBLY - SMALL TOOLS ONLY (CONTINUED) ® FOR USE WITH WHIZARD QUANTUM DRIVE ITEM DESCRIPTION WITHOUT DISCONNECT WITH DISCONNECT 48” 60” 84” 48” 60” 84” Driveline Assembly Complete Large 107129 107130 107131 Diameter (Includes 1,2,5,6) Driveline Assembly Complete Large 107132 107133...
  • Page 138 Service Parts ® WHIZARD QUANTUM DRIVELINE ASSEMBLY - LARGE TOOLS ONLY ® FOR USE WITH WHIZARD QUANTUM DRIVE   60$// 722/ '5,9(5 7,3   /$5*( 722/ '5,9(5 7,3 7-54 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...

  • Page 139: Whizard Quantum ® Driveline Assembly - Large Tools Only

    Service Parts ® WHIZARD QUANTUM DRIVELINE ASSEMBLY - LARGE TOOLS ONLY (CONTINUED) ® FOR USE WITH WHIZARD QUANTUM DRIVE ITEM DESCRIPTION WITHOUT DISCONNECT WITH DISCONNECT 48” 60” 84” 48” 60” 84” Driveline Assembly Complete Large 101051 101054 102671 Diameter (Includes 1,2,5,6) Driveline Assembly Complete Large 101055 101056...

  • Page 140: Whizard ® 3/16" Flexshaft And Casing Assembly - Small Tools Only

    Service Parts ® WHIZARD 3/16” FLEXSHAFT AND CASING ASSEMBLY - SMALL TOOLS ONLY FOR USE WITH UN-84 AND ULTRA DRIVE MOTORS   60$// 722/ '5,9(5 $66(0%/<  6 ,1',&$7(6 60$//  )/(;6+$)7   /$5*( 722/   60$// 722/ '5,9(5 '5,9(5 $66(0%/<...
  • Page 141 Service Parts ® WHIZARD 3/16” FLEXSHAFT AND CASING ASSEMBLY - SMALL TOOLS ONLY (CONTINUED) FOR USE WITH UN-84 AND ULTRA DRIVE MOTORS ITEM DESCRIPTION WITHOUT DISCONNECT WITH DISCONNECT 48” 60” 84” 48” 60” 84” Casing Assembly Complete 107150 107151 107152 ------ ------ ------...

  • Page 142: Whizard ® 1/4" Flexshaft And Casing Assembly - Small Tools Only

    Service Parts ® WHIZARD 1/4” FLEXSHAFT AND CASING ASSEMBLY - SMALL TOOLS ONLY FOR USE WITH UN-84 AND ULTRA DRIVE MOTORS   60$// 722/ '5,9(5 $66(0%/<  6 ,1',&$7(6 60$//  )/(;6+$)7   /$5*( 722/   60$// 722/ '5,9(5 '5,9(5 $66(0%/<...
  • Page 143 Service Parts ® WHIZARD 1/4” FLEXSHAFT AND CASING ASSEMBLY - SMALL TOOLS ONLY (CONTINUED) FOR USE WITH UN-84 AND ULTRA DRIVE MOTORS ITEM DESCRIPTION WITHOUT DISCONNECT WITH DISCONNECT 48” 60” 73” 84” 48” 60” 73” 84” Casing Assembly Complete 107156 107157 107158 107159...

  • Page 144: Whizard ® Flexshaft And Casing Assembly - Large Tools Only

    Service Parts ® WHIZARD FLEXSHAFT AND CASING ASSEMBLY - LARGE TOOLS ONLY FOR USE WITH UN-84 AND ULTRA DRIVE MOTORS   60$// 722/ '5,9(5 $66(0%/<  6 ,1',&$7(6 60$//  )/(;6+$)7   /$5*( 722/   60$// 722/ '5,9(5 '5,9(5 $66(0%/<...
  • Page 145 Service Parts ® WHIZARD FLEXSHAFT AND CASING ASSEMBLY - LARGE TOOLS ONLY (CONTINUED) FOR USE WITH UN-84 AND ULTRA DRIVE MOTORS ITEM DESCRIPTION WITHOUT DISCONNECT WITH DISCONNECT 48” 60” 84” 48” 60” 84” Casing Assembly Complete 106949 106950 106955 ------ ------ ------ (Includes 1,2,4,5)

  • Page 146: Optional Post Handle

    Service Parts OPTIONAL POST HANDLE 7-62 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 147 Service Parts OPTIONAL POST HANDLE (CONTINUED) ITEM DESCRIPTION PART NUMBER Post Handle Kit (Includes items 1-8) 107280 Clamp Ring 101131 Post 183622 Hex Washer Head Bolt 183623 Hex flange Nut 183633 Post Handle (Small) 183042 Arm Rest Assembly 183624 Arm Rest Strap Assembly 183630 Knob Assembly 183626...

  • Page 148: Cleaning Solution

    Service Parts ALSO AVAILABLE Cleaning Solution PART DESCRIPTION NUMBER 184331 EXTRA© HEAVY DUTY CLEANER (CASE - Four 1 Gallon Jugs) 184332 EXTRA© HEAVY DUTY CLEANER (1 GALLON) Cleaning Equipment PART DESCRIPTION NUMBER 184334 Handpiece Cleaning Kit (Contains the following) 184335 Handpiece Cleaning Pick 184336 Stainless Steel Hand Brush...

  • Page 149: Lubrication And Lubrication Equipment

    Service Parts ALSO AVAILABLE (CONTINUED) Lubrication and Lubrication Equipment PART DESCRIPTION NUMBER 173519 ® Duralite Casing Maintenance Kit (WhizLube Spray) 102609 ® 13.5 oz. Cartridge of Whizard Quantum High Performance Grease 103271 ® 30 pack - 13.5 oz. Cartridge of Whizard Quantum High Performance Grease 184282 4 oz.

  • Page 150: Blade Sharpening And Steeling Equipment

    Service Parts ALSO AVAILABLE (CONTINUED) Blade Sharpening and Steeling Equipment PART DESCRIPTION NUMBER 100655 Special Stone (Small) 100660 Special Stone (Large) 100641 ® Whizard Special Steel (Small Tools) 100642 ® Whizard Special Steel (Large Tools) 100650 Ceramic Sharpener 107237 ® ™...

  • Page 151: Covers And Depth Gauges

    Service Parts ALSO AVAILABLE (CONTINUED) Blade Sharpening and Steeling Equipment (Continued) PART DESCRIPTION NUMBER 107254 ® X350 Bettcher EZ Edge 183928 ® X360 Bettcher EZ Edge 107255 ® X440 Bettcher EZ Edge 183907 ® X500 Bettcher EZ Edge 183927 ® X505 Bettcher EZ Edge 183892...

  • Page 152: Tools

    Service Parts ALSO AVAILABLE (CONTINUED) Tools PART DESCRIPTION NUMBER 183900 Torque Wrench Kit 107330 Bearing Removal Tool (Small Tool) 184983 Bearing Removal Tool (Large Tool) 7-68 Service Parts Manual No. 107334 ® Operating Instructions and Parts List for the Quantum Flex Trimmer June 22, 2018...
  • Page 153 Contact and Document Information Section 8 Contact and Document Information CONTENTS OF THIS SECTION Contact Address and Phone ....................8-2 Document Identification ......................8-2 Manual No. 107334 Contact and Document Information ® June 22, 2018 Operating Instructions and Parts List for the Quantum Flex Trimmer...
  • Page 154 Contact and Document Information CONTACT ADDRESS AND PHONE For additional information, technical support and spare parts, contact your Regional Manager, Distributor, or Bettcher Representative: Bettcher Industries, Inc. BETTCHER GmbH P.O. Box 336 Pilatusstrasse 4 Vermilion, Ohio 44089 CH-6036 Dierikon SWITZERLAND...

This manual is also suitable for:

Quantum flex x500Quantum flex x440Quantum flex x505Quantum flex x564Quantum flex x350Quantum flex x500a ... Show all

Table of Contents
