Summary of Contents for Drija DOLCETTO 33
- Page 1 User Manual DOLCETTO 33 33 Bottles Voltage 110v-120V / 60 HZ...
-
Page 2: Table Of Contents
User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 1. INTRODUCTION ......................2 2. PARTS & FEATURES ..................... 4 3. SPECIFICATIONS OF YOUR WINE CABINET ............... 4 4. INSTALLATION INSTRUCCIONS ................... 5 5. OPERATING YOUR WINE COOLER ................9... -
Page 3: Introduction
User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 1. INTRODUCTION The packaging materials that manufacturer uses are environmentally friendly and can be recycled. Please discard all packaging material with due regard for the environment. IMPORTANT SAFETY INFORMATION ... - Page 4 User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 CHILD SAFETY Packaging material should be kept away from children. Children should not be allowed to touch the controls or play with the appliance. GENERAL SAFETY Do not pull on the power supply cable to remove the plug from your mains supply socket.
-
Page 5: Parts & Features
User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 2. PARTS & FEATURES 1.Door Handle 2.Stainless Steel Door 3.Bottom Grille 4.Wooden shelf 5.Control Panel 6.Leveling Legs(4) 3. SPECIFICATIONS OF YOUR WINE CABINET Gross capacity: 85 litres Bottle capacity: 33 x 0.75 litre Bordeaux style wine bottles... -
Page 6: Installation Instruccions
User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 Adjustable feet Tempered glass door Stainless steel door frame and handle SS 304 Designed to store wine at its optimum temperature between 5°C and 18°C. Compressor cooling ... - Page 7 User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 o 7 Wine Bottle Shelves Before connecting the wine cooler to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation.
- Page 8 User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 CABINET OPENING DIMENSIONS(minimum) DOLCETTO 33 Width 380mm Depth 625mm Height 875mm And the air vent at the front of the appliance must never be covered or blacked in any way.
- Page 9 User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 from overheated. Never unplug the appliance by pulling the power cord. Always grip the plug firmly and pull straight out from the receptacle. Repair or replace immediately all power cords that have become frayed or otherwise damaged.
-
Page 10: Operating Your Wine Cooler
User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 the instruction manual and insert them into the side of the door from the inside to the outside. 3. Align the holes in the handle with the screws, tighten the screws using the screwdriver until the base of the handle is at the level of the door and that the handle is tight but not too tight to damage the assembly. - Page 11 User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 extreme cold or hot conditions may cause interior temperatures to fluctuate. The range of 5- 18°C (40-65°F) may not be reached. RECOMMENDED TEMPERATURE SETTINGS Wine conservation: 12°C-14ºC (53°F-57ºF) Rose and sparkling wines: 5°C-8ºC (41°F-46ºF) Dry/white wines: 9°C-12ºC (48°F-53ºF)
- Page 12 User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 SETTING THE TEMPERATURE The Unit is between 40°F and 65°F(5°C and 18°C). When the unit is plugged in for the first time, the unit will power up automatically to the preset defaults.
- Page 13 User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 removing the shelf out of the inner rail, make sure to remove all items first. Then move the shelf to the position where the notch of the shelf is exactly under the plastic post and lift the shelf.
-
Page 14: Troubleshooting Guide
User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 Tape the door shut. Be sure the appliance stays secure in the upright position during transportation. If you absolutely need to transport the wine cooler horizontally, transport the wine cooler on its back (doors on top). - Page 15 User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 The temperature control is not set correctly. The door gasket does not seal properly. Not plugged in. The light does not The circuit breaker tripped or a blown Plug the unit.
- Page 16 User manual WINE COOLER WITH COMPRESSOR BUILT-IN | DOLCETTO 33 ENVIRONMENTAL NOTE Note: Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse.
