User Manual and Installation Guide
EN 16475-2:2017
bluechimney.dk
Version 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BlueChimney and is the answer not in the manual?

Questions and answers

Related Manuals for BlueChimney BlueChimney

Summary of Contents for BlueChimney BlueChimney

  • Page 1 User Manual and Installation Guide EN 16475-2:2017 bluechimney.dk Version 3...

  • Page 2: Table Of Contents

    1.6 Specifications and dimensions ...................... 2 1.7 Installation ............................3 1.8 Electrical connection ........................3 1.9 BlueChimney with remote control ....................3 1.10 BlueChimney with manual speed controller ................5 1.11 Maintenance and Troubleshooting ....................6 1.12 EU Declaration of Conformity ...................... 8...

  • Page 3: Product Information

    BlueChimney dilutes the smoke up to 25 times and then spreads the diluted smoke in the shape of a fan. This produces a unique dilution and spreading effect that reduces the smell of smoke as well as the consequent nuisance in neighbouring areas.

  • Page 4: Chimney Sweeping

    When the chimney is cleaned from the top down, BlueChimney’s opening is operated with one hand. Turn the fastener to one side, and BlueChimney will tilt slightly back until the chain tightens. There will now be easy and unrestricted access to cleaning the chimney.

  • Page 5: Installation

    1.7 Installation Place BlueChimney in the middle of the outlet at the top of the chimney. Remove the chimney cowl, if any, since the smoke exhauster itself acts as a rain hood. Follow the national safety rules for roof- walking.
  • Page 6 . The BlueChimney switches off automatically 4 hours after you last pushed a button. Extended program functions BlueChimney can run the entire time – 15 seconds after the most recent keystroke – if you push the  “off” button and press the “more draught” 2 to 8 seconds later .

  • Page 7: Bluechimney With Manual Speed Controller

    Up to 70 m. 1.10 BlueChimney with manual speed controller NOTE: Do NOT connect a cabled speed controller and a remote control to your BlueChimney at the same time. Fit the white control cable to the speed controller by removing the back of the speed controller and fitting the wires in the manner, as described below: Red wire to screw terminal no.

  • Page 8: Maintenance And Troubleshooting

    1.11 Maintenance and Troubleshooting Assuming normal use, BlueChimney requires maintenance intervals that correspond to the periodic visits of the chimney sweep. However, BlueChimney should be cleaned thoroughly by a professional at least once a year. IMPORTANT: Disconnect the device from the power source before commencing cleaning.
  • Page 9 I don’t know device? Are there any foreign items (birds, branches) causing a jam? Contact the dealer BlueChimney runs but does not The exhaust system is not Are the flue ducts, connections, vacuum in enough smoke. airtight chimney and clean-out doors...

  • Page 10: Eu Declaration Of Conformity

    1.12 EU Declaration of Conformity The following producer/manufacturer Manufacturer: BlueChimney ApS Address: Snerlevej 14, DK-4180 Sorø Hereby declares that the following product(s) Product name: BlueChimney Product type: BC1GL01 Is also in accordance with the following EU directive(s) Directive reference Directive...
