- Page 1 PASTA COOKER CUISEUR À PÂTE COCEDOR DE PASTA INSTALLATION,OPERATING AND MAINTENANCE INSTRUCTIONS MANUEL D'INSTALLATION D'UTILISATION ET D'ENTRETIEN MANUAL DE INSTALACIÓN, USO Y MANTENIMIENTO...
- Page 2 The manufacturer reserves the right to modify the appliances presented in this publication without notice. Le fabricant se réserve le droit de modifier sans préavis les caractéristiques des appareil présentés dans cette publication. El fabricante se reserva el derecho de modificar sin previo aviso las características de los equipos presentados en esta publicación.
-
Page 3: Table Of Contents
ENGLISH INDEX INDEX ..............................1 ANALYTICAL INDEX .......................... 1 SAFETY .............................. 2 REGULATIONS AND GENERAL INSTRUCTIONS ................3 4.1. General Information ........................3 4.2. Warranty ........................... 3 ... -
Page 4: Safety
ENGLISH SAFETY Leave in front view the labels containing the It is recommended to carefully following warnings: read the instructions and warnings contained in this manual before using WARNING: improper installation, appliance. information contained in the manual is for the adjustment, alteration, service... -
Page 5: Regulations And General Instructions
Warranty MVP Group Corporation (AXIS) hereby warrants following the date of original installation (unless all new pasta cookers bearing the name "AXIS" otherwise specified) but in no event can exceed and installed within Canada or the United States eighteen (18) months from the date of shipment of America to be free from defects in material or from the factory. -
Page 6: Description Of The Appliance
ENGLISH 4.3. Description of the Appliance The appliance defined as a pasta cooker has been designed and manufactured for cooking pasta in water for professional use in the catering industry. On the basis of requirements, one or two tanks are available 1) Cooking tanks. -
Page 7: Replacement Of Parts
ENGLISH 4.6. Replacement of Parts When worn components must be replaced, only use original spare parts. Before carrying replacement intervention, activate envisioned safety devices. In particular, close the gas supply valve and All responsibility is declined for injury to prevent access to all the devices which, if persons or damage to components deriving from activated, could lead to unexpected dangerous... -
Page 8: Burner Ignition
ENGLISH 5.2. Burner Ignition SWITCH-ON A) Press and turn the knob in an anti- clockwise direction (position 1); at the same time, press the button (B) to switch on the pilot light. The ignition of the pilot light can also be carried out manually through the cover positioned on the bottom (C). -
Page 9: Recommendations For Use
ENGLISH Before filling the tank, check that the drain valve (A) is closed. ID 05 Cock CLOSED Cock OPEN 5.5. Recommendations for Use Check that the drain valve is closed before If the appliance remains inactive for a long period, proceed as follows: filling the cooking tank;... -
Page 10: Faults
ENGLISH FAULTS The information shown below aims to help with user. For the other, precise competency is the identification and correction of any anomalies required and they must therefore only be carried and malfunctions which could occur during use. out by qualified personnel. Some of these problems can be resolved by the Problem Causes... -
Page 11: Installation
Power Model (BTU/hr) The installation area must be equipped with all 45000 AX-GPC-1 power supply and production residue drainage connections and must be suitably lit and respect AX-GPC-2 90000 current laws regarding hygiene and sanitary Table 1.1 Minimum change of air in relation to the... -
Page 12: Water Connection
ENGLISH 8.3. Water Connection 1. Clear the pipe of any ferrous waste by letting The unit should be connected to your water a certain amount of water flow through. supply by way of a water faucet. The water 2. Place the cooker in the desired position and pressure should fall between 14.5 and 72.5 PSI. -
Page 13: Inspection
ENGLISH 8.5. Inspection Before commissioning, the system must be tested 2. Check that burner ignition in order to evaluate the operating conditions of combustion is regular; each individual component and identify any 3. Check and, if necessary, regulate the gas anomalies. -
Page 14: Adjustments
ENGLISH ADJUSTMENTS ID 09 Before carrying out any adjustments, activate all the safety devices envisaged. In particular, close the gas supply valve and prevent access to all the devices which, if activated, could lead to unexpected dangerous situations putting personal safety and health at risk. -
Page 15: Adjusting Burner Valve Minimum
ENGLISH 9.1. Adjusting Burner Valve Minimum This regulation must only be carried out if the type 8. Turn burner following of gas to be connected is different from the testing instructions, close the gas interception valve, gas, after having carried out power supply disconnect the pressure gauge, screw the transformation. -
Page 16: Replacing Burner Nozzle
ENGLISH 9.2. Replacing Burner Nozzle For this operation, proceed as follows. Close the gas supply cock Open the hatch (A). Replace the nozzle (B) with one which is suitable for the type of gas used (see attachments) ...
