Thermon TO-712F Manual

TO-712F
Ver.01
TEMPERATURE AND TIME
CONTROLLER FOR OVENS
Heating Steam Lighting Buzzer
IP 65
FRONT
Timer Functions Serial Protection
lock programming
BEFORE INSTALLING THE CONTROLLER, WE RECOMMEND READING THE INSTRUCTION MANUAL IN FULL TO PREVENT
POSSIBLE DAMAGE TO THE PRODUCT.
THROUGH CONTINUOUS DEVELOPMENT, FULL GAUGE CONTROLS RESERVES THE RIGHT TO CHANGE THIS MANUAL
INFORMATION AT ANY TIME, WITHOUT PRIOR NOTICE.
1. DESCRIPTION
Thermostat and timer for the automation of forced convection ovens. This model provides control over gas, electric, or wood
powered ovens, configured through the setup menu. TO-712F controls steam injection and lighting in the oven, and has an
internal audible alarm (buzzer) that signals, for example, the end of the roasting process. It also allows for the use of an
external audible alarm and the language selection of your main messages, improving the user experience. The ThermON
line is developed and produced with high-quality raw materials and stands out for its unique and differentiated design and
intuitive, user-friendly interface to facilitate operation and configuration. It offers a functions lock feature to prevent third
parties from changing the parameters, air-tight front panel that provides high protection against the entry of dirt and moisture,
and more.
2. MAIN APPLICATIONS
Baking ovens, stoves;
3. TECHNICAL SPECIFICATIONS
Electric power supply 85~265Vca (50-60Hz)
Operating temperature 0 to 60ºC
Control temperature -10 to 500ºC / 14 to 932ºF
Operating humidity 10 to 90% UR (without condensation)
Temperature sensor Type J thermocouple (sold separately)
Resolution 1ºC / 1ºF
Digital Input E1: door micro switch input
Flame sensor E2: flame sensor input
Relay outputs 4 relay outputs: 5 (3)A / 250Vac 1/8HP
12Vcc/30mA (max)
External audible alarm (buzzer) output
Product dimensions (mm) 75 x 75 x 100 (WxHxD)
Opening dimensions (mm) 67,2 x 67,2
4. INTRODUCTION
Lower display: Indicates the cooking time
or parameter configuration;
Heating on indication led;
Ignition output switched on;
TO-712F
T i m e r a c t i v a t e d
indication led;
Steam output on
indication led;
SET
Quick touch: Temperature
and cooking time adjustment;
SET
Long touch: Access to the
advanced configuration;
Quick touch: On /off lamp output.
Quick touch: Steam activation;
Long touch: Steam activation time adjustment; SET
LED
KEY
5. INSTALLATION CONFIGURATION
Access the menu setting by pressing the
displayed press the
press
Use the < or > keys to select the desired function. The value can be edited with a quick touch on the
keys to change the value and press the
functions menu. To leave the configuration menu and return to the normal operating mode (temperature indication), press
SET (long touch) until [----] is displayed.
level
5.1Installation setup table
FUN
[CoD] Access code (231)
[i01] Oven type selection
Temperature sensor type
[i02]
[i03] Temperature units selection
[i04] Language selection
Approximate consumption 10VA
Enable external audible alarm
[i05]
Internal audible alarm (buzzer)
[i06]
[i07] Door digital input signal type
6. OPERATION
6.1 Oven: Electric
In this operating mode the controller keeps the heating output on until the oven reaches the oven temperature setpoint (SP). The
output will be activated again when the temperature drops below the setpoint minus the hysteresis (F04).
Upper display: Indicates the
6.2 Oven: Gas
temperature measured by the sensor or
parameter configuration;
In this operating mode the controller automates / monitors the flame ignition and thus the heating of the oven through the
activation of the gas output, ignition module, and flame sensor input. The controller keeps the heating output on until the oven
reaches the oven temperature setpoint (SP). Heating will be activated again when the temperature drops below the setpoint
Temperature units indicator
minus the Hysteresis (F04). The controller permanently monitors the flame sensor to ensure the safe operation of the gas-fired
led;
oven. In this way, if there are any abnormalities, errors Er4 - Flame Sensor shorted with the burner and Er5 - Lack of Flame are
indicated. For more information check item 9 (Signaling).
Functions lock indication led;
6.3 Oven: Wood
Led lamp output indicator
In this operating mode the heating output works as an upper threshold alarm, indicating when the temperature exceeds the value
led;
adjusted in Oven Temperature setpoint (SP). The audible alarm is also activated to warn the user about the overheating. The
output and audible alarm are switched off when the temperature drops below the Oven Temperature setpoint (SP) minus the
Quick touch: Decreases
Hysteresis (F05) or when a
parameter value when in
programming mode;
6.4 Default Mode (standard)
In this operating mode the controller performs the gas type control, however the flame sensor is ignored and the controller will not
Quick touch: Increases
monitor flame presence. The controller will not detect errors Er4 - shorted flame sensor and Er5 - out of gas, resulting in an
parameter value when in
operation with less safety.
programming mode;
NOTE: The Default Mode (standard) of operation is available only when the type of oven is adjusted as gas. To execute this
operating mode, check item 5.5 Enable Default (standard) Mode of operation.
Quick touch: Timer activation;
KEY FUNCTIONS
IN THIS OPERATING MODE THE FLAME SENSOR IS IGNORED AND THE CONTROLLER WILL NOT DETECT
Each key has a led to indicate its function. When the
THE PRESENCE/LACK OF FLAME, BEING ESSENTIAL FOR THE OPERATOR TO PAY SPECIAL ATTENTION
led is on, it indicates that the key is active and can be
TO CONTROL THE OVEN IN ORDER TO PREVENT GAS ACCIDENTS.
pressed.
SET key for 4 seconds until [Func] is displayed. When [CoD] is
SET key again (quick touch). Use the < or > keys to enter the access code 231 and
SET (quick touch) again when ready.
SET key with a quick touch when ready to save the configured value and return to the
FUNCTION DESCRIPTION
Required when you want to change installation
setup parameters.
Selects the control type of the oven:
[ELE,]= Electric oven
[GAS,]= Gas-fired oven
[LEN,]= Wood-fired oven
Defines the type of temperature sensor to be
used with the controller.
IMPORTANT: This function is not available
for this model.
Selects the temperature units the controller will
use for its operation.
Selects the language the controller will use to
display messages:
[Port]= Portuguese
[,EnG]= English
[,ESP]= Spanish
Enables or disables the external audible alarm
(buzzer). If enabled, the internal audible alarm
(buzzer)
(buzzer) will be disabled.
Selects the sound intensity of the internal
audible alarm (buzzer).
[Min,]= low volume
volume
[Med,]= medium volume
[HiGh]= high volume
[,NO,]- normally open contact (NO)
[,NC,]- normally closed contact (NC)
SET key in the controller's front panel is pressed.
7. OPERATIONS - BASIC LEVEL
The controller has easy access to resources that are relevant to the user of the oven.
7.1 Adjustment of oven temperature and timer
To adjust oven temperature and timer, perform a quick touch on the
the parameter. To advance and/or terminate the adjustment, perform another quick touch on the
SET key. Use the < or >
ADJUSTMENT OF THE DESIRED TEMPERATURE (SETPOINT) OF THE OVEN:
Defines the working temperature of the oven. This parameter can be adjusted between the values
defined in F02 - Minimum value allowed to configure the oven temperature setpoint and F03 - Maximum
value allowed to configure the oven temperature setpoint.
TIMER SETTINGS:
Defines the cooking time. When the time expires, the audible alarm output is switched on intermittently
until any key on the controller's front panel is pressed. The timer can be adjusted between 00:01 and
MIN MAX UNIT DEF.
99:59. The time scale is adjusted in parameter F14 - Time base of the timer.
-
0 9999 0
7.2 Steam activation
The steam operating mode is defined in parameter F18 - Steam Operating Mode. Steam activation depends on
parameters F20 - Time interval between steam activations and F21 - Minimum temperature to activate the steam,
-
ELE LEN GAS
available in the advanced configuration menu. These conditions must be met for the injection of steam in the oven to occur.
7.2.1 Steam activation times
%
Press the key and hold for 4 seconds to adjust. Use the < or > keys to adjust the value. To confirm, perform a quick
%
- touch on the key.
J J J
- STEAM OUTPUT ON TIME:
ºC ºF °C
This parameter can be adjusted between 1 and 30 seconds, and the factory default is 5 seconds.
STEAM OUTPUT OFF TIME:
-
PORT ESP PORT
This parameter can be adjusted between 1 and 600 minutes, and the factory default is 3 minutes.
NOTE: This parameter is available for adjustment when the steam control mode selected is cyclic,
[F18]=[CYC,].
-
OFF ON OFF
7.3 Functions lock
To enable / disable the functions lock, press the < and > keys and hold for the time configured in
parameter F26 - Time for functions lock.
-
MIN HIGH MED
When this configuration is active, the parameters cannot be changed, but they can be viewed. When the
lock is active, the parameters available for adjustment are defined in parameter F25 - Functions Lock.
&
Icon indicates the status of the lock. Icon lit indicates the functions lock is active.
-
NO NC NO
7.4 Enable Default (standard) operating mode
To enable the Default (standard) operating mode of the oven, the controller must be powered up with the
$ %
and keys pressed until the message appears on the display. This mode is available when the
type of oven selected is GAS. For more details about this operating mode check item 6.4 Default Mode
(standard).
IN THIS OPERATING MODE THE FLAME SENSOR IS IGNORED AND THE CONTROLLER WILL NOT
DETECT THE PRESENCE/LACK OF FLAME, BEING ESSENTIAL FOR THE OPERATOR TO PAY SPECIAL
ATTENTION TO CONTROL THE OVEN IN ORDER TO PREVENT GAS ACCIDENTS.
8. OPERATIONS - ADVANCED LEVEL
8.1 Changing the controller parameters
Access the advanced configuration menu by pressing the
displayed. When [CoD] is displayed press the
enter the access code 123 and press
Use the < or > keys to select the desired function. The value can be edited with a quick touch on the
or > keys to change the value and press the
return to the functions menu.
To leave the configuration menu and return to the normal operating mode (temperature and time indication), press
(long touch) until [----]is displayed.
8.2 Tabela de parâmetros
FUNCTION
FUN
[CoD] Access code (123)
Temperature sensor
[F01]
indication offset
SET key. Use the < or > keys to adjust the value of
SET key.
SET key for 4 seconds until [FuNc]is
SET key again (quick touch). Use the < or > keys to
SET (quick touch) again when ready.
SET key. Use the <
SET key with a quick touch when ready to save the configured value and
SET
DESCRIPTION MIN MAX UNIT DEF.
Required when you want to change the
-
0 9999
advanced configuration parameters.
Allows compensating deviations in the sensor -20 20 °C
(-4) (36) (°F)
temperature reading.
.
0
0
(0)
