Summary of Contents for Goldair Select GSPF40R
- Page 1 Operating Instructions 40cm Pedestal Fan Item: GSPF40R...
- Page 2 General Care and Safety Guide Thank you for choosing this Goldair Select product. This Goldair Select appliance has been designed and manufactured to high standards of engineering and with proper use and care, as described in this leaflet, will give you years of useful service. Please read these instructions carefully and keep them for future reference.
- Page 3 Components 1.Front guard 10.Switch box 2.Clip 11.Set screw 3.Spinner 12.Height adjustment collar 4.Fan blade 13.Outer tube 5.Guard locking nut 14.Base decorative cover 6.Rear guard 15.Screws 7.Motor shaft 16.Cross bars 8.Oscillation pin 17.Remote control 9.Motor housing...
- Page 4 Components 1.Sleep mode indicator 2.Normal mode indicator 3.Natural mode indicator 4.High speed indicator 5.Medium speed indicator 6.Low speed indicator 7.Swing button 8.Mode button 9.Timer button 10.On/Speed button 11.Off button 12.Timer indicators 13. Swing button 14. Timer button 15. On/Speed button 16.
- Page 5 Assembly First, loosen and remove the four screws from Position the rear grill against the front of the motor housing with the handle at the top, the cross bars. Then interlock cross bars A and B. Be sure to align the four holes in the bars with ensure that the locating pins on the motor housing are engaged correctly in the holes of those on the flange of the outer tube.
- Page 6 Operating your Fan Always choose a safe location for the fan, keeping in mind the safety precautions outlined. Ensure all packaging has been removed from the unit before use. This appliance requires no permanent installation, it should be used solely as a portable appliance. Timer WARNING Keep all objects at least...
- Page 7 PROOF OF PURCHASE To receive warranty retain receipt as proof of purchase. (Refer to back of booklet). SUPPORT AND TECHNICAL ADVICE Goldair – New Zealand Goldair – Australia Monday – Friday 8am-5pm Monday – Friday 8am-5pm...
- Page 8 In non-domestic use Goldair limits the voluntary warranty to three months. Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the warranty period.
