Advantech-DLoG TREK-753 User Manual

7" all-in-one mobile data terminal
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
TREK-753
7" All-in-one Mobile Data
Terminal

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TREK-753 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech-DLoG TREK-753

Summary of Contents for Advantech-DLoG TREK-753

  • Page 1 User Manual TREK-753 7" All-in-one Mobile Data Terminal...
  • Page 2 A product returned without proof of the purchase date is not eligible for warranty service. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. Part No. Edition 1 Printed in Taiwan April 2012 TREK-753 User Manual...
  • Page 3 Product name and serial number – Description of your peripheral attachments – Description of your software (operating system, version, application software, etc.) – A complete description of the problem – The exact wording of any error messages TREK-753 User Manual...
  • Page 4 TREK-753 series Mobile Data Terminal USB/LAN cable clip Warranty card Power cord: DC power inlet cable (200 cm - for TREK-753 only) WWAN or WLAN Antennas (by options) “Drivers, Utilities and User Manual" CD-ROM End User License Agreement (WES and WinCE model), please download driver and related document from http://support.advantech.com...
  • Page 5 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that TREK-753 User Manual...
  • Page 6 Transport: carry the unit with both hands and handle with care. Maintenance: to properly maintain and clean the surfaces, use only approved products or clean with a dry applicator. CF/SD/SIM card: Turn off the power before inserting or removing CompactFlash storage cards. TREK-753 User Manual...

  • Page 7: Table Of Contents

    Figure 1.1 TREK-753 Dimensions ..........5 Chapter System Setup ........7 A Quick Tour of the TREK-753 Mobile Data Terminal ......8 Figure 2.1 Front View of TREK-753..........8 Figure 2.2 Rear View of TREK-753 ..........8 Figure 2.3 Side View of TREK-753..........9 Figure 2.4 Bottom View of TREK-753..........
  • Page 8 Power Management Utility Program........... 42 5.4.3 Power Management Parameter Settings........43 Figure 5.10Power Management Test Utility ....... 43 5.4.4 TREK-753 Power Consumption..........43 Execute CAN Demo Utility..............44 Figure 5.11CAN Test..............44 GPIO Test....................45 Figure 5.12DI/O Test..............45 Figure 5.13Digital In ..............45 Figure 5.14Digital Out..............

  • Page 9: Chapter 1 General Information

    Chapter General Information This chapter gives background information on the TREK-753 Mobile Data Terminal. Sections include: Introduction General Specifications Dimensions...

  • Page 10: Introduction

    GbE LAN, and a rich complement of I/O ports (additional COM ports, audio, CAN bus, and J1708). TREK-753 has also been re-engineered to optimize internal space, gained by its full-flat panel touch- screen;...

  • Page 11: General Specifications

    1 x USB 2.0 port from front panel; 1 x USB 2.0 port from rear I/O; 1x USB 2.0 with high density connector – 1 x 100/1000-T Gb LAN by RJ-45 connector – 1 x CAN 2.0B with J1939 protocol with high density connector – 1 x J1708 with high density connector TREK-753 User Manual...
  • Page 12 Operating Temperature : -30° C ~ 50° C – Relative Humidity 95% @ 40° C (No condensing) – Vibration & Shock: MIL-STD-810G (US highway truck), Method 516.5, – SAE J1455, Class 5M3 according DIN EN 60721-3-5 (Lv.2 100G, 6ms, shock) TREK-753 User Manual...

  • Page 13: Dimensions

    1.3 Dimensions Figure 1.1 TREK-753 Dimensions TREK-753 User Manual...
  • Page 14 TREK-753 User Manual...

  • Page 15: Chapter 2 System Setup

    Chapter System Setup This chapter details system setup for TREK-753. Sections include: A Quick Tour of the Mobile Data Terminal Installation Procedures Running the BIOS Setup Pro- gram Installing the Drivers for Win XP...

  • Page 16: A Quick Tour Of The Trek-753 Mobile Data Terminal

    2.1 A Quick Tour of the TREK-753 Mobile Data Terminal Before starting to set up the Mobile Data Terminal, take a moment to become familiar with the locations and functions of the controls, drives, connectors and ports, which are illustrated in the figures below. When the Mobile Data Terminal is placed inside truck glove cabinet or under the passenger’s seat next to the driver, its front appears...
  • Page 17 Figure 2.3 Side View of TREK-753 Figure 2.4 Bottom View of TREK-753 TREK-753 User Manual...

  • Page 18: Installation Procedures

    2.2 Installation Procedures When you install TREK-753, the first step is to connect the power and ignition cor- rectly. TREK-753’s power cable is designed to connect to the battery directly. TREK- 753 can be switched ON/OFF both by the ignition signal or its power button.

  • Page 19: Power Connector

    Orange 2.2.2 Power Connector TREK-753 can be powered on/off from the power button or directly from the vehicle ignition. There is a 5 second delay when using ignition on/off. This avoids impact from fluctuating power supply which might impact or damage system operation. For more power management details, please see Power management in Chapter 5.

  • Page 20: Running The Bios Setup Program

    These files are a very useful supplement to the information in this manual. For more updated driver please refer to the Advantech website, www.advantech.com/support The drivers for TREK-753 are listed below; run the executable to install the drivers. Device Version Intel SCH INF Update 8.8.0.1011...

  • Page 21: Chapter 3 Hardware & Peripheral Installation

    Chapter Hardware & Peripheral Installation This chapter details the installa- tion of hardware for TREK-753. Sections include: Overview of Hardware Installa- tion and Upgrading Installing the Storage Device and SIM Card Installing System Memory Installing the Drivers for Win XP...

  • Page 22: Overview Of Hardware Installation & Upgrading

    3.2 Installing the Storage Device and SIM Card TREK-753 has a side door and a user can easily install a SIM card or storage (CF or SD) card. The CF card is the main bootable storage card which has the operating system pre-installed from Advantech.

  • Page 23: Installing System Memory

    3.3 Installing System Memory TREK-753 supports 200-pin SODIMM type DDRII DRAM. There's a door which can be opened for RAM installation. It is very easy to open to install memory. However, we suggest this change performed by our service center to avoid any possible dam- age (like electrostatic discharge or memory inserted in the wrong position.

  • Page 24: Installing The I/O Cover

    3.5 Installing the I/O Cover To ensure TREK-753’s entire system is protected with an IP54 rating, assemble the IP54 I/O cover kit to mask all the connectors on the bottom side. From left to right: plastic I/O cover, rubber seal, and plastic I/O box. Remove tape...
  • Page 25 Connect all cables to system and secure before the cover is installed. There are 6 screws holes designed for the extra mechanical part installation. The mounting frame needs to be secured by these holes. Install the cover attaching it in place with the 6 screws. TREK-753 User Manual...
  • Page 26 Screw the plastic I/O cover onto the plastic I/O box. Installation complete. TREK-753 User Manual...

  • Page 27: Installing Wireless Options

    See the exploded drawing for clear assembly illustration. 3.6 Installing Wireless Options TREK-753 is a highly integrated all-in-one terminal, all wireless options are able to installed at once and work by independent connection. In the standard OS that comes with TREK-753, all wireless connections have been setup in advance and users will not need to set them up again.

  • Page 28: Wlan

    3.6.1 WLAN Driver Installation Make sure the Wi-Fi module has been installed in the TREK-753. Figure 3.1 Top View of TREK-753 Make sure there is a wireless router and access point working available for TREK-753 to connect to. Turn on the TREK-753, and boot into the OS.
  • Page 29 Some APs devices will have different SSIDs; choose an available one and con- nect (entering user ID & password if prompted). Click Connect after entering key (if prompted) to connect to the wireless AP. Open the web browser and TREK-753 will connect to the internet. TREK-753 User Manual...

  • Page 30: Gprs

    3.6.2 GPRS Driver Installation Make sure the GPRS module has been installed in the TREK-753 Figure 3.2 Top View of TREK-753 TREK-753 User Manual...
  • Page 31 Insert the user’s SIM card in the TREK-753 slot; make sure the SIM card has already applied to a GSM network in advance and can transmit/receive data. Turn on the TREK-753, and boot up the OS. GPRS (MC55i) connects to the system on the COM port interface; it doesn't need a separate driver.
  • Page 32 In completing the new connection wizard textbox, select "Add a shortcut to this connection to my desktop." Press “Finish.” In the “Network Connections” panel, click right mouse button, select “Properties” In the "Phone number” textbox, input: *99***1#. Press, “Configure.” TREK-753 User Manual...
  • Page 33 Change "Maximum speed (bps)” to 115200. Press “OK.” Once the previous steps are complete, the new connection will be created. Double Click on the new connection and Click “Dial.” TREK-753 will connect to the internet. TREK-753 User Manual...

  • Page 34: Hsdpa (3.5G)

    3.6.3 HSDPA (3.5G) Driver Installation Make sure the HSDPA module has been installed in the TREK-753. Figure 3.3 Top View of TREK-753 Insert the user's SIM card in the slot; make sure the SIM card has already applied to a GSM network in advance and can transmit/receive data.
  • Page 35 Turn on the TREK-753, then boot into the OS. Install the HSDPA USB module driver/AP "Watcher_Generic Build 2258.msi" from driver CD on the Windows Embedded OS. Setup Connection Check the device manager to make sure there are no entries with question marks.
  • Page 36 Double Click the "Sierra Wireless Watcher" and Click Button "Connect." The TREK-753 will connect to the internet. TREK-753 User Manual...

  • Page 37: Gps

    Make sure the GPS module & antenna has already been installed in the TREK- 753. Figure 3.4 Bottom View of TREK-753 Turn on the TREK-753, boot up the OS. Double click "ublox_A4_U5_USB_drv3264_install_UI.exe" application program on the driver CD to install.
  • Page 38 Install "u-Center" to setup and test. Start test in "u-Center," setting COM port (COM7) and baud rate (9600bps) used for GPS module. After starting test, NMEA output messages are display in the Development Data View setup connection. TREK-753 User Manual...
  • Page 39 TREK-753 User Manual...

  • Page 40: Chapter 4 Pin Assignments

    Chapter Pin Assignments This chapter explains pin assign- ments on the TREK-753.

  • Page 41: Rear Side Connectors

    Power input Acc Ignition Input Note! TREK-753 has 2 power options for different applications: Input Voltage 12 V/24 V options support 6~36 V power design with ISO7637-2 & SAE J1113 compliance (default) 48 V option supports 18~58 V input for specific applications...

  • Page 42: High Density Connector

    Isolated Relay Driver Output 3# Isolated Relay Driver Output 2# Isolated Relay Driver Output 1# Isolated Dry Contact Input 4 Isolated Dry Contact Input 3 Isolated Dry Contact Input 2 Isolated Dry Contact Input 1 Isolation DIO Ground TREK-753 User Manual...

  • Page 43: Rs-232 Connector (Com8)

    4.5 LED Indicator This system power indicator is an orange LED, controlled by hardware. This LED will be lit on when the system is in NORMAL mode. When system is off, this LED will not be lit. TREK-753 User Manual...

  • Page 44: Software Demo Utility Setup

    Chapter Software Demo Utility Setup This chapter explains the software demo utility for TREK-753. Sections include: Introduction How to Set up Demo Utility Installing the Drivers for Win XP...

  • Page 45: Introduction

    5.1 Introduction To make the hardware easier to access for programmers, Advantech has developed a demo utility in order to let customers test the functions on TREK-753. This docu- ment describes detailed information for each Advantech demo utility so that applica- tion developers can become more familiar with using them.

  • Page 46: Hot Key Test

    5.2 Hot Key Test Click "Hot Key test" program in IMC demo main menu. If "Auto Brightness" is checked TREK-753 will adjust the panel brightness automati- cally using a built-in light sensor input. Or the brightness of panel and hot keys can be set manually.

  • Page 47: Rtc Test

    Key Function Definition: Set the parameters to connect to the application program function of the hot key. 5.3 RTC Test Execute “RTC test” For RTC Time Setting: You can set year, month, date, and time as shown below. Figure 5.4 RTC Test - 1 & 2 TREK-753 User Manual...
  • Page 48 Figure 5.5 RTC Test - 3 & 4 RTC Alarm Setting: You can also set Alarm time; you can wake up the system at the time you have set. Please refer to the figure below. Figure 5.9 RTC Test - 5 TREK-753 User Manual...

  • Page 49: Power Management

    1 ~ 18000 seconds LOW_THRESHOLD (12V mode) 11.42 V 10.09 ~ 12.25 V LOW_THRESHOLD (24V mode) 22.44 V 21.11 ~ 23.28 V LOW_DELAY 30 seconds 1 ~ 3600 seconds LOW_ HARD_DELAY 60 seconds 1 ~ 3600 seconds TREK-753 User Manual...

  • Page 50: Power Management Utility Program

    5.4.2 Power Management Utility Program Execute IMCDemo.exe file, see the icon below. TREK-753 User Manual...

  • Page 51: Power Management Parameter Settings

    5.4.3 Power Management Parameter Settings The parameters for power management on TREK-753 can be read or modified by the Demo utility (see the image below) or SDK/API. Figure 5.10 Power Management Test Utility 5.4.4 TREK-753 Power Consumption OS: Windows Embedded Standard Burn-in test V6.0...

  • Page 52: Execute Can Demo Utility

    5.5 Execute CAN Demo Utility Figure 5.11 CAN Test Reset the module Transmit CAN message Set the polling rate of CAN message reception Received CAN message. Set up the filter of CAN message (only show the message ID) TREK-753 User Manual...

  • Page 53: Gpio Test

    Digital Output box to execute the same procedure. See Figure 6. Figure 5.12 DI/O Test a. Digital Output ==> isolated relay driver output b. Digital Input ==> isolated dry contact input Figure 5.13 Digital In TREK-753 User Manual...

  • Page 54: Video In Test

    There is one video input. Connect camera to the port, CAM1. Choose Channel 1 on “Switch to.” The panel will show the image which Camera1 has taken, and it will fall- back to original status after 10 sec. Figure 5.15 Video Test Utility TREK-753 User Manual...

  • Page 55: Audio Test

    5.8 Audio Test TREK-753 has a built-in microphone on the front panel. Audio functions (Line out and Line-in & Mic-in) can be extended to remote site using a high density cable. Both Line out & Line in functions work when a high density cable is connected. Mic-in is able to work either from the front panel or from a high density cable.
  • Page 56 Appendix High Density Cable Pin Assignment...

  • Page 57: Standard Usb A Type Female Connector

    The high density connected for TREK-753 includes 48 wires in a 2-meter cable. It extends functionality of many of the I/O port with standard type connectors. At the host side, a 3M 10150-3000 PE series 50-pin connector can be connected with TREK-753.

  • Page 58: Rs-232 Connector (Db9 Male) (Com9)

    RS232_CTS RS232_RI A.4 4DI /4DO & RS-485 (DB15 Type Male) (COM5) Table A.4: 4DI /4DO & RS-485 (DB15 Type Male) (COM5) Pin Number Definition ISO_DI1 ISO_DI2 ISO_DI3 ISO_DI4 GND_ISO ISO_DO1 ISO_DO2 ISO_DO3 ISO_DO4 RS485+ RS485- GND(Drain wire) TREK-753 User Manual...

  • Page 59: Can Bus & J1708 (Terminal Block 6P, 5.08Mm Pitch)

    CAN_H (H) CAN_L (L) GND (G) J1708+ (J+) J1708- (J-) GND (G) A.6 Power Extension Connector (Terminal Block 3P, 5.08mm pitch) Table A.6: Power Extension Connector (Terminal Block 3P, 5.08mm Pitch) Pin Number Definition +V12(26AWG) GND(26AWG) +V5(26AWG) TREK-753 User Manual...

  • Page 60: High Density & Connector Pin List

    DIO & RS-485 RS485- DB15 female RS485+ GND(Drain wire) J1708- J1708+ CAN Bus & J1708 GND(Drain wire) Terminal Block 6P, 5.08mm pitch connector CAN_L CAN_H +V12(26AWG) +V12(26AWG) Extended Power +V12(26AWG) Terminal Block 3P, 5.08mm GND(26AWG) pitch GND(26AWG) GND(26AWG) TREK-753 User Manual...
  • Page 61 RS232_RI RS232_CTS RS232_RTS RS232_DSR GND(Drain wire) RS-232 male connector RS232_DTR RS232_TXD# RS232_RXD# RS232_DCD ISO_DO4 ISO_DO3 ISO_DO2 ISO_DO1 DIO & RS-485 ISO_DI4 DB15 female connector ISO_DI3 ISO_DI2 ISO_DI1 GND_ISO (26AWG) TREK-753 User Manual...

  • Page 62: Ewf (Enhanced Write Filter) Manager Sop54

    Appendix EWF (Enhanced Write Filter) Manager SOP...

  • Page 63: Ewf (Enhanced Write Filter) Manager Sop

    A. EWF function: If you want to protect your operating system you can use the func- tion to recover your OS after a restart.. Note! Please check "C" volume is not protected. EWF Enable Method: Click Enable and a reboot the system when prompted. TREK-753 User Manual...
  • Page 64 HORM (Hibernate Once and Resume Many): The function can always resume your OS after hibernation, even after a shutdown or crash. Before using HORM you should set EWF to the state "disable" Check "Enable hibernate" Right-Click on desktop and click "Properties" TREK-753 User Manual...
  • Page 65 Choose "Screen Saver" panel and click "Power.” Check "Enable hibernate." TREK-753 User Manual...
  • Page 66 Activate HORM Open Start -> All Programs -> Advantech -> Advantech EWF Manager. Click "Activate HORM." Chick "OK" to reboot OS. Check "Use the Welcome screen." Open Start -> Control Panel. TREK-753 User Manual...
  • Page 67 Click "Network and Internet Connections." Click "Network Connection." TREK-753 User Manual...
  • Page 68 Right-Click on "Local Area Connection" and click properties. Uninstall "Client Service for NetWare." Click "Yes" to remove "Client Service for NetWare" and reboot OS. Open Start -> Control Panel. TREK-753 User Manual...
  • Page 69 Click "User Accounts" Click "Cancel." Check "Use the Welcome screen" and Click "Apply Options" TREK-753 User Manual...
  • Page 70 Open Start -> All Programs -> Advantech -> Advantech EWF Manager. Click "Enable." Click "OK" to reboot OS. Run "Hibernate" Open Start -> Shut Down When you press "Shift" the Standby icon will be replaced with a Hibernate icon. TREK-753 User Manual...
  • Page 71 Enable HORM is finished. VIII If you unplug power cord after resuming system, you will discover the OS will continue its resume state. TREK-753 User Manual...
  • Page 72 TREK-753 User Manual...
  • Page 73 www.advantech.com Please verify specifications before quoting. This guide is intended for reference purposes only. All product specifications are subject to change without notice. No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher.
