Padded Multi-Guitar Stand
PLMS3, PLMS5, PLMS7
Assembly Instructions
Congratulations on purchasing a Proline
guitar multi-stand.
With proper assembly and sufficient care,
your multi-stand will stand up to years of use.
To see our full line of Proline products,
visit us at www.prolinestands.com.
Box Contents:
A
B
C
D
E
F
G
H
I
J
K
Closed wrench
Allen wrench
Guitar tree
Bottom braces (2x)
Side arms (2x)
Feet (2x)
Socket screw M6x15 (2x)
Socket screw M6x30 (8x)
Socket screw M6x35 (2x)
Cap nut (4x)
Washers (2x)
©2011 Proline - All trademarks and registered trademarks mentioned herein are recognized as the property of their respective holders. 1101-9540
PLMS3
PLMS5
PLMS7
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Proline PLMS3
Summary of Contents for Proline PLMS3
- Page 1 Side arms (2x) Feet (2x) Socket screw M6x15 (2x) Socket screw M6x30 (8x) Socket screw M6x35 (2x) Cap nut (4x) Washers (2x) ©2011 Proline - All trademarks and registered trademarks mentioned herein are recognized as the property of their respective holders. 1101-9540...
- Page 2 ASSEMBLY Step 1 Bottom Braces Locate the foot with the four holes on the bottom. Attach this foot to the bottom braces as shown. For each brace use two M6 x 30 socket screws Fasten the other foot to the braces on the opposite side.
