Main Features; Technical Specification - Vortex PURE PRO Specification & User Manual

Main Features:

1. Removable
2. 60% keyboard with QWERTY layout (67 Key)
3. Cherry MX key switch (Black, Blue, Brown, Red)
4. Dual layer PCB
5. Key cap material: ABS(UV coating- Backlit version only)、PBT
6. LED backlight (Backlit version only)
7. USB Interface
Package Material
1. Keyboard x 1
2. User Manual x 1
3. USB Cable x 1

Technical Specification

Number of keys:
US ASCII (67 keys) = US Layout
Dimension:
29.5 x 10.2 x 3.8cm (Keyboard)
Cable:
1.5 meters (mini USB B type)
Key switch life time:
Cherry: >5000 actuations
Programming Instruction
1. Press PMode(FN + Right CTRL) to enter the programming mode (PN LED flashing)
2. Press the key you want to program (PN LED on)
3. Key in the programming content and then press PN (PN LED flashing again)
4. Repeat step 2 and step 3 to program other keys
5. Press PMode(FN + Right CTRL) to exit programming mode (PN LED off)
Note:
• Support FN layer programming, you can select the FN combination key (e.g., FN + A) to program it
• Under SELECT state (step 1), you can press PN + any key to view its content in a word processing
software (e.g., Notepad)
• Support time delay, press 15ms key(FN + F) each time to delay 15ms, press 0.1s key(FN + G) each time
to delay 0.1s, press 0.5s key(FN + H) each time to delay 0.5s. Consecutive delay will add up but will only
be counted as 1 key stroke
• Every key can program up to 14 key strokes
• If there is no key pressed for 15 sec in programming, it will exit to normal mode
Interface:
USB (DC5V ----100mA)
Available layout:
US USA
JP JAPAN
Package:
20 keyboards / 1 outer box
