Summary of Contents for LG 32BK50Q
- Page 1 OWNER’S MANUAL LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32QK500 32BK50Q www.lg.com Copyright © 2018 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered ASSEMBLING AND PREPARING ....3 trademarks of HDMI Licensing Administrator, Inc. -
Page 3: Assembling And Preparing
• It is recommended to use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Supported Drivers and Software • Illustrations in this document represent typical procedures, so they may look different from the actual product. - Page 4 Product and Button Description How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ down with your finger. Power LED Power LED Joystick Button...
- Page 5 Moving and Lifting the Monitor Basic Functions When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. Press the joystick button once with your finger to turn on the monitor.
- Page 6 Installing on a Table Adjusting the Angle • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm (3.9 inches) Place the monitor mounted on the stand base in an upright position. away from the wall to ensure sufficient ventilation.
- Page 7 Installing the Wall Mount Plate Remove the screws from the stand and separate the stand from the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. CAUTION • Place the monitor’ s screen face down. To protect the screen from scratches, cover the surface with a soft cloth. Remove the stand base by unscrewing it as shown in the illustration below.
- Page 8 (3.9 inches) NOTE • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non-standard screws. • The wall mount kit includes the installation guide and all necessary parts.
- Page 9 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. • To prevent injury, this apparatus must be securely attached to the wall in accordance with the installation instructions.
-
Page 10: Using The Monitor
USING THE MONITOR DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • Illustrations in this manual may differ from the actual product. NOTE Press the button, go to [Input], and then select the input option. •... - Page 11 Connecting Headphones Connect peripherals to the monitor via the headphones port. NOTE • Peripheral devices are sold separately. • Depending on the audio settings of the PC and external device, headphones and speaker functions may be limited. • If you use angled earphones, it may cause a problem with connecting another external device to the monitor. Therefore, it is recommended to use straight earphones.
-
Page 12: User Settings
USER SETTINGS NOTE Button Menu Status Description • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. Main menu disabled Enables the main menu. Activating the Main Menu Exits the main menu. (Holding down the button more than 5 seconds to turn Main menu enabled off the monitor. - Page 13 Main Menu Features Main Menu Description [Input] Sets input mode. Power Off [Power Off] Turns off the monitor. [Settings] You can adjust the various settings. Input Exit Settings [Picture Mode] You can select the various picture mode. [Exit] Exits the main menu. Picture Mode Customizing settings [Quick Settings]...
- Page 14 [Input] [Settings] > [Input] Description [Input List] Selects the input mode. Adjusts the aspect ratio of the screen. [Aspect Ratio] [Full Wide] Displays the video in widescreen, regardless of the video signal input. [Original] Displays video according to the aspect ratio of the video signal input. [Picture] [Settings] >...
- Page 15 [Settings] > [Picture] Description Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use [Fast]. For a fast-moving picture, it is recommended that you use [Faster]. Setting to [Faster] may cause image sticking.
- Page 16 [Settings] > [Picture] Description [Mode 1], The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image [Mode 2], becomes. [Gamma] [Mode 3] [Mode 4] If you do not need to adjust the gamma settings, select [Mode 4]. [Custom] The user can adjust it to red, green, or blue by customization.
- Page 17 [General] [Settings] > [General] Description [Language] Sets the menu screen to the desired language. Conserve energy by using luminance compensation algorithm. [High] Saves energy using the high-efficiency [SMART ENERGY SAVING] feature. [Low] Saves energy using the low-efficiency [SMART ENERGY SAVING] feature. [SMART ENERGY SAVING] [Off] Disables the feature.
- Page 18 [Settings] > [General] Description This feature disables the configuration and adjustment of menus. [On] Enables [OSD Lock]. [Off] Disables [OSD Lock]. [OSD Lock] NOTE • The menus except the menus below are disabled. - [Quick Settings] [Brightness], [Contrast], [Volume] - [Input] - [General] [OSD Lock], [Information] [Information]...
-
Page 19: Troubleshooting
TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. • Is the monitor's adapter plugged in? Make sure to use the adapter that is provided in the product package. •... - Page 20 Have you installed the display driver? Be sure to install the display driver from the display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our website: http:// www.lg.com. • Make sure to check if the graphics card supports Plug and Play function.
-
Page 21: Product Specification
PRODUCT SPECIFICATION Color Depth 10-bit color is supported. Max Resolution 2560 x 1440 @ 75 Hz HDMI1, HDMI2 Recommended Resolution 2560 x 1440 @ 60 Hz Resolution Max Resolution 2560 x 1440 @ 75 Hz DP, mDP Recommended Resolution 2560 x 1440 @ 60 Hz Power Rating 19 V 2.5 A... - Page 22 Factory Support Mode (Preset Mode, HDMI/ DisplayPort PC) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 31.469 59.94 HDMI/ DisplayPort 640 x 480 37.5 HDMI/ DisplayPort 37.879 60.317 HDMI/ DisplayPort 800 x 600 46.875 75.0 HDMI/ DisplayPort 48.363 60.0 HDMI/ DisplayPort...
- Page 23 HDMI Timing (Video) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) 480P 31.5 576P 31.25 720P 37.5 720P 1080P 56.25 1080P 67.5...
- Page 24 Supplier's Declaration of Conformity Trade Name Responsible Party LG Electronics USA, Inc. Address 1000 Sylvan Ave Englewood Cliffs, NJ 07632 Telephone (201)266-2215 This device can be used in all regions. Read the owner's manual (CD) carefully and keep it at hand.
