FRONT PANEL
FRONT PANEL
1. GAIN KNOB (Range: 44 dB)
2. GANE LEVEL MONITOR
Shows if signals are transferred into right channel.
3. PEAK INPUT LEVEL
LED turns on 3 dB lower than OUTPUT clipping and shows excessive OUTPUT.
4. FADER
Adjusts mixing level of signals into each channel.
It is recommended to slide down when not in use.
5. AUX1, AUX2
Adjusts signal into AUX jacks.
PP-9620.3
