- Page 1 SEO CANblu IMMOBILIZER USER MANUAL...
- Page 2 SEO CANblu IMMOBILIZER – USER MANUAL Disarming – automatic when the ID transmitter is within the range of the main unit. Arming – automatic, 10 sec after losing connection between the ID transmitter and the main unit. ID transmitter has a button in its right-hand hole, by which a user can operate it (use a paper clip). LED is located in the left-hand hole of the ID transmitter.
- Page 3 Disarming – automatic while the ID transmitter is within the range of the main unit. If a PIN code is defined and you do not have your ID transmitter with you, the immobilizer may be disarmed by entering the previously set buttons combination.
- Page 4 – the car owner, after picking the vehicle up from servicing, should immediately switch the service mode OFF. During normal operation, the SEO CANblu immobilizer indicates (by the dashboard indicator light) whether it has been armed or disarmed.
- Page 5 Checking current power of the ID transmitter Press the ID transmitter button 8 times to have the LED show the current power setting of the ID transmitter. The number of LED blinks indicates one of nine transmitter power levels: a) one flash –...
- Page 6 (b) Encryption keys removal from the ID transmitter In order to remove encryption keys from the ID transmitter, it must be switched OFF. Programming the ID transmitter into the main unit assigns unique encryption keys which encrypt the communication between main unit and ID. After programming the ID transmitter, it can establish a connection with only one main unit –...
- Page 7 Programming (pairing) another ID transmitter into the main unit (max 8 ID transmitters and smartphones) Only a switched ON ID transmitter can be programmed into the main unit. To enter into the programming mode, switch the ignition ON (so that the dashboard lights up) and disarm the immobilizer (using the ID transmitter, PIN code or smartphone), then press the gas (acceleration) pedal 10 times.
- Page 8 Switching the service mode ON/OFF using the PIN code To turn on the service mode using only the PIN code, turn the ignition ON, disarm the immobilizer by entering the previously set PIN code holding the last programmed button for 10 seconds. If you successfully managed to enable the service mode, the indicator on the dashboard will blink 5 times.
