- Page 1 Release Version 2.0 4CHANNEL VIDEO INPUT DIGITAL SPLITTER SC-04MHD User's Manual...
- Page 2 Release Version 2.0 Precaution and Safety Guidelines The content of this guideline is to protect the safety of users and prevent property damage. Be sure to read this user’s manual thoroughly and use the device correctly. Warning (If you do not keep any of the below guidelines, you may get seriously injured or cause somebody’s death.) Be sure to install the product after unplugging power cord.
- Page 3 Release Version 2.0 Caution (If you do not keep any of the below guidelines, you may get injured or suffer property loss.) ■ Avoid installation in areas with strong magnetic fields or near wireless devices such as radio or TV. - Install the device in a place free from magnetic particles, radio waves or severe vibration.
- Page 4 1. Introduction 1-1. Overview SC-04MHD is a 4 channel multi-format video digital splitter, which provides high-resolution display in various split modes in real time. This item supports various input such as AHD, TVI, CVI, CVBS and has various output ports to be compatible with many different external devices.
-
Page 5: Product Parts And Peripheral Device Connection
Release Version 2.0 3. Product Parts and Peripheral Device Connection 3-1. Front Interface ① ② ③ ④ ⑤ ⑧ ⑥ ⑦ ⑨ ① POWER: To turn the power on/off. ② MENU: To set up this item and/or check the current settings. ③... - Page 6 Release Version 2.0 ④ AUTO: To enable auto sequence mode. Once you press this button in the split mode for a second, the green LED will be on, the video will be displayed from 1CH to 4CH in full screen successively. Once you press this button for a few seconds in the cropping mode of a vertically two-split mode, the LED will be flickering and a red circle will be shown in the relevant channel.
- Page 7 Release Version 2.0 1) Vertical 2 Split Press the AUTO KEY for a few seconds to make the AUTO KEY LED flickering and a red line displayed. Press the SINGLE DISPLAY 3 to shift the image on the right side and press SINGLE DISPLAY 1 to shift the image on the left side.
- Page 8 Release Version 2.0 3-2. Backside Interface ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ① VIDEO INPUT: HD Analog (AHD, TVI, CVI) and CVBS video input (up to four channels). ② CVBS: CVBS video output. ③ VGA OUT: RGB output. ④...
- Page 9 Release Version 2.0 ④-③ Alarm Operation Structure ⑤ POWER: DC 12V/200mA output. ⑥ RS-485: RS-485 communication by an external device for a remote control. ⑥-① Communication Settings - Data Length: 8 Bit, Start/Stop Bit: 1Bit, Parity Bit: None, Baud Rate: menu set point. - Control Communication Data Format Byte Value...
- Page 10 Release Version 2.0 ⑦ DC IN: Power input. ⑧ VIDEO OUTPUT: HD-Analog and CVBS video output. ※ When connecting it to the BNC port, 75Ω termination will be released as there is the auto termination switch inside. Therefore, if you do not connect it to an external device such as a DVR after connecting it to the BNC port, the displayed image may blur due to the termination problem.
-
Page 11: Menu Setup
• DEFAULT ALL 4-1. Start-up Screen of the Menu - Press the menu button on the front side of SC-04MHD to display the menu as shown above. - Move the sub-menus by using the △▽ buttons and press the DUAL(Select) button to select one of the sub-menus. -
Page 12: System Setup
4-2. SYSTEM Setup 4-2-1. SYSTEM ID Use the system ID when controlling SC-04MHD in a long or short distance by RS-485. You can insert from 1 to 255. SYSTEM SET> Press ▲▼ buttons to select SYSTEM ID> Press ◀▶ buttons to enter/change the values (1~255). -
Page 13: Buzzer Out
Release Version 2.0 4-2-5. BUZZER OUT Set the buzzer when a button is used, an alarm is generated and/or any video signal loss is detected. SYSTEM SET> Press the ▲▼ buttons to select the BUZZER OUT> Press the ◀▶ buttons to set the BUZZER OUT ON/OFF. - Page 14 Release Version 2.0 4-2-10. UTC CONTROL When controlling camera using UTC function of DVR as below picture, make sure to turn OFF the UTC CONTROL of the product because there is a risk of abnormal working of camera control or images appearing intermittently. In an environment installed as below picture, UTC CONTROL should be ON in order to control camera from DVR.
- Page 15 When output of MATRIX SWITCHER is connected to input of SC-04MHD, INPUT SET should be fixed to CVBS(NTSC) or CVBS(PAL) and LOSS OFF in SYSTEM setting.
-
Page 16: Display Set
Release Version 2.0 When a connected monitor’s resolution is not available in SC-04MHD, the video may not be displayed. If the video is not displayed, try to use other output port to set the compatible resolution with monitor. 4-4-1. HDMI/VGA Set the output resolution of HDMI and VGA. -
Page 17: Date And Time
Release Version 2.0 4-5-2. CH TITLE Set the channel title and cropping mode message. DISPLAY SET> Press the ▲▼ buttons to select the CH TITLE> Press the ◀▶ buttons to set as ON/OFF. When it is off, the channel name will not be displayed on the screen. 4-5-3. -
Page 18: Date/Time Set
Release Version 2.0 analog cameras and CVBS cameras to this splitter together, this mode should be set as 2D. However, in this case, there might be minute image shaking. SYSTEM SET> Press the ▲▼ buttons to select the DE-INTER MODE> Press the ◀▶ buttons to set the 2D/WEAVE. - Page 19 Release Version 2.0 DATE & TIME SET> Press the ▲▼ buttons to select the TIME SET> Press the ▲▼ and ◀▶ buttons to set the time. 4-7. CH TITLE SET Display the channel title(name) on the screen. CH TILTE SET> Press the ▲▼ buttons to select the CHANNEL> Press the DUAL(SELECT) button to set the channel title(name).
-
Page 20: Event List
Release Version 2.0 4-8. EVENT LIST Display the relevant channel and occurred time when an alarm or video loss occurs in a specific channel. (S_L: Signal Loss, ALM: Alarm) Connection Diagram ※ AHD, TVI, and CVI cameras do not have standardized signal format, so depending on the manufacturer, images may not be output properly, and UTC control may not work properly. -
Page 21: Checking Method
※ CVI signal is displayed irregularly randomly as the original image does not come out when SC-04MHD is turned on and off. In this case, please disconnect and reconnect the relevant BNC connector of the cable and then turn it on and off. -
Page 22: Specifications
Release Version 2.0 7. Specifications Model SC-04MHD Video Input AHD, TVI, CVI, CVBS HD-Analog 1920x1080p 25/30Hz, 1280x720p 25/30Hz Video Input Resolution CVBS NTSC, PAL LOOP OUT Same resolution as the input video signal CVBS 720x480i 59.94Hz(NTSC), 720x576i 50Hz(PAL) 1920x1080p 25/30/50/60Hz, 1920x1080i 50/60Hz,... -
Page 23: Warranty Certificate
Release Version 2.0 8. Warranty Certificate This product has passed thorough quality control and test, and if this gets broken during normal use, we provide the two-year warranty service. Model No. Serial No. Distributor Date you purchased Place you purchased Warranty Period Two (2) year from the date of purchase Name... - Page 24 Release Version 2.0 SeeEyes Co.,Ltd #503~509 Sunil Technopia, 555 Dunchon-daero, Jungwon-gu, Seongnam City, Gyeonggi Province, Korea (Zip Code: 13215) TEL: +82-(0)31-730-5833 FAX: +82-(0)31-777-3512 E-MAIL : overseas@sscctv.com http://www.sscctv.com/eng...
