- Page 1 16 CHANNEL DIGITAL COLOR SPLITTER SC-16DS User's Manual SC-16DS...
- Page 2 Precaution and Safety Guidelines Please read this manual carefully and fully understand the portions of the installation and operation instructions prior to installing and using the product. Should you have any part of them not understandable or if you have any problem during your installation or in using it, please contact us.
- Page 3 1.1 Introduction With this splitter monitor can display various quads, sequence, etc. video signal from the 16 number of video inputs at SC-16DS. It displays the name of channel, date and time as well as event such as loss. 1.2 Functions ...
- Page 4 2. Components Open the package and place the main unit at the plain ground or installation site and then check the followings components; ① SC-16DS Main unit x 1 ② User manual x 1 ③ Power cord x 1 ④ 19” rack mount wing x 2...
- Page 5 3. SC-16DS Installation 3.1 Precaution & Important Notice Make sure not to supply the power to the main unit before install it. Avoid any heavy impact, which cause the malfunctions. Avoid the place where the magnetic material, radio wave such as radio, TV, etc.
-
Page 6: Rear Side
⑤ Serial Port: RS-232 / RS-485 Communication 3.2 Communication Way Remote control is available through RS-232/485 COM. Control Protocol is compatible with SDM-16, In the Menu -> Miscellaneous -> Remote Control. It is possible to select SDM-16 or RS-232 and RS-485. SC-16DS Remote Control Command... - Page 7 ASCII Function Remark 0x01 ~ 0x10 Ch 1 ~ 16 Full Display Rec Out Display Control 0x11 〃 0x12 4 Split mode Display 〃 0x13 7 Split mode Display 〃 0x14 9 Split mode Display 〃 0x15 10 Split mode Display 〃...
-
Page 8: Communication Setup
① SDM-16: when using instead of SDM-16 product - 1Byte Command (Control Code) transmission - SC-16DS is connected with external controller one on one, (only one on one control is possible) ② RS-232: when the external device support RS-232 communication. - Page 9 4.2 SETUP MENU Start SETUP MENU ▪ Above screen will appear when press “MENU” button at the front panel. Move the menu by click the ▲▼ direction keys and ◀▶ to change the setting. You can see the function of sub menu at the bottom, too. Press the Menu key to exit the previous menu.
- Page 10 ▪ FREEZE TIME To set the period of freeze time, use ◀,▶ direction keys. Freeze function is off when the setting time passed. ▪ BORDER LINE ON/OFF To set the border line on/off, use ◀,▶ direction keys. ▪ BORDER COLOR To set the border line color, use ◀,▶...
-
Page 11: Channel Select
▪ DATE DISPLAY Use ◀,▶ direction keys, set the date display on or off. ▪ TIME DISPLAY Use ◀,▶ direction keys, set the time display on or off. ▪ DATE SETTING Use ◀,▶ direction keys, adjust year, month and date. ▪... -
Page 12: Event Display
▪ TITLE Use ◀,▶ direction keys, set the camera title. Maximum character per camera is 8. ▪ SATURATION, BRIGHTNESS, CONTRAST, HUE Use ◀,▶ direction keys, change the channel color up to 64 steps. (SATURATION, BRIGHTNESS, CONTRAST, HUE) ▪ DEFAULT Press ◀,▶ direction keys , SATURATION, BRIGHTNESS, CONTRAST, HUE setting is changed from On to OFF about 0.5 sec. - Page 13 4.7. MISCELLANEOUS PIP LOCATION ▪ Positioning PIP location, four locations are available, right top, left top, right bottom and left bottom. TITLE ON/OFF ▪ Display the camera title on or off. ▪ LOSS ON/OFF Display Loss, Camera Off ICON on for off. ▪...
- Page 14 5. APPLICATION Monitor...
-
Page 15: Warranty Certificate
6. Warranty Certificate This product has passed thorough quality control and test, and if this gets broken during normal use, we provide 12 months warranty service. Model No. Serial No. Distributor Date you purchased Place you purchased Warranty Period One (1) year from the date of purchase Name Purchaser Address...
