MityCAM CMV50000 EVK User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MityCAM-C50000
CMV50000 EVK User's Manual
60-000034-1 RevA
1/11/2019
www.criticallink.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMV50000 EVK and is the answer not in the manual?

Questions and answers

Related Manuals for MityCAM CMV50000 EVK

Summary of Contents for MityCAM CMV50000 EVK

  • Page 1 MityCAM-C50000 CMV50000 EVK User’s Manual 60-000034-1 RevA 1/11/2019 www.criticallink.com...

  • Page 2: Table Of Contents

    CMV50000 EVK User’s Manual Contents 1 Introduction ..............................4 1.1 Additional Documentation ............................4 1.2 Organization ................................4 2 Interfaces ................................ 4 2.1 AIA USB 3 Vision ................................ 4 2.2 HDMI ..................................4 2.3 Power Interface ................................ 4 2.4 USB 2.0 RNDIS Debug ............................... 4 3 Frame Interval and Exposure Time ........................
  • Page 3 CMV50000 EVK User’s Manual Tables Table 1: Reference Documentation ..........................4 Table 2 GPIO Break Out Cable Pin Assignments ......................9 Table 3: GPIO Modes ..............................9 Page 3 of 20 60-000034-1 RevA 1/11/2019 www.criticallink.com...

  • Page 4: Introduction

    GenICAM HdmiOutputResolution register. The interface port must use an HDMI 1.4 compliant interface cable and suitable monitor. 2.3 Power Interface The MityCAM-C50000 kit requires a +12 V input voltage supply. A minimum of 2 Amps is required. See the datasheet for details on the connector. 2.4 USB 2.0 RNDIS Debug...

  • Page 5: Frame Interval And Exposure Time

    CMV50000 EVK User’s Manual The USB 2.0 port on the MityCAM-C50000 kit provides an RNDIS (ethernet) connection to an attached HOST PC. The port is configured to run a DHCP server and present an ethernet IP address of 10.45.45.1/8 for the camera and assign an address of 10.45.45.10/8 to the attached HOST PC.

  • Page 6: External Frame Rate And Internal Exposure

    CMV50000 EVK User’s Manual InternalExposureMode False The timing of the external exposure and frame rate must be consistent with the capabilities of the CMV50000 Sensor. 3.2 External Frame Rate and Internal Exposure This mode uses Control Mode 1 (Programmed External) mode of the CMV50000 as described by the CTRL_MODE register in the sensor datasheet.

  • Page 7: Continuous Operation

    The HDMI output is enabled and disabled using GenICam HdmiStart and HdmiStop commands. 4.3 Simultaneous Output The MityCAM-C50000 EVK supports both running both the USB output and the HDMI output at the same time. 5 Changing LVDS Clock Rate The camera supports operating the LVDS serializer rates of the CMV50000 at different frequencies up to the maximum 830 MHz.

  • Page 8: Configurable Region Of Interest

    Figure 2 CMV50000 Pixel Array The MityCAM-C50000 kit provides access to the top and bottom 22 buffer pixel rows and access to the left and right 68 OB column pixels by adjusting the request ROI of the camera. The camera presents the buffered pixel rows at the top and bottom positions in the ROI.

  • Page 9: Color Processing

    CMV50000 EVK User’s Manual pixels (192 total) at the right side of the ROI. The right most 192 pixels, starting at pixel X offset of 7920, will consist of the 68 optical black pixels on the left side of the array followed by 28 padded pixels followed by 68 optical black pixels on the right side of the array followed by 28 padded pixels.

  • Page 10: Input

    In output mode, the pin can be driven high or low. This can be used to toggle a light source or some other operation. 11 Firmware Upgrade Recent versions of the MityCAM-C50000 allow upgrading the firmware via the network interface. Details for acquiring the firmware and downloading the firmware to the camera are available on the Critical Link MityCAM Support Site.

  • Page 11: Device Control Group

    CMV50000 EVK User’s Manual 12.1 Device Control Group Feature Type SFNC? Description DeviceReset Command This command is used to reset the device and to put it in its power up state. DeviceVendorName StringReg Name of camera vendor DeviceModelName StringReg Name of the camera model...
  • Page 12 CMV50000 EVK User’s Manual Min Value:16 Increment:16 Height Integer Height of image, in pixels. Min Value:1 Increment:1 PixelFormat Enumeration Pixel format Allowed Values : Mono12p  Mono8   BayerBG8 BayerBG12P  TestPattern Enumeration This control allows the user to select between normal Sensor Data and the CMV50000 sensor channel test gradient test data as described in 7.8.5 of the CMV50000 datasheet.

  • Page 13: Acquisition Control Group

    CMV50000 EVK User’s Manual maximum frame rate achievable by the sensor. Min Value:200 Max Value:830 12.3 Acquisition Control Group Feature Type SFNC? Description AcquisitionMode Enumeration Acquisition mode Allowed Values : Continuous  SingleFrame  MultiFrame  AcquisitionStart Command Start acquisition.

  • Page 14: Sensor Peek/Poke Group

    CMV50000 EVK User’s Manual  TriggerActivation Enumeration TriggerActivation Allowed Values : RisingEdge  12.4 Sensor Peek/Poke Group Feature Type SFNC? Description RegAddress Integer Register address of the Peek/Poke Min Value:0 Max Value:255 Increment:1 RegValue Integer Value of the address peeked or to be written when poked...
  • Page 15 CMV50000 EVK User’s Manual Allowed Values : Gain_1x  Gain_2x   Gain_4x GDIG_RE_CE Integer Digital Gain for Even Rows, Even Columns. See section 7.7.2 of the CMV50000 datasheet. Min Value:0 Max Value:255 Increment:1 GDIG_RE_CO Integer Digital Gain for Even Rows, Odd Columns. See section 7.7.2 of the CMV50000 datasheet.

  • Page 16: Digital Io Control Group

    CMV50000 EVK User’s Manual 12.6 Digital IO Control Group Feature Type SFNC? Description LineSelector Enumeration Selects the physical line (or pin) of the external device connector or the virtual line of the Transport Layer to configure. When a Line is...
  • Page 17 CMV50000 EVK User’s Manual Feature Type SFNC? Description HdmiStart Command This command will cause the evalation kit to configure the Sensor to capture images, scale and output them to the HDMI port according to the settings in the HDMI Control group.
  • Page 18 CMV50000 EVK User’s Manual Res_4K  Page 18 of 20 60-000034-1 RevA 1/11/2019 www.criticallink.com...

  • Page 19: Transport Layer Control Group

    CMV50000 EVK User’s Manual HdmiGamma Float The evalation system will perform a gamma gain conversion of the HDMI output data using this parameter. 12.8 Transport Layer Control Group Feature Type SFNC? Description PayloadSize Integer Size of payload, in bytes Min Value:16...
  • Page 20 CMV50000 EVK User’s Manual Page 20 of 20 60-000034-1 RevA 1/11/2019 www.criticallink.com...
