Assembly

1
We recommend the use of a side-lift jack for
easier fitting of AL-KO Secure when used on a
tandem axle caravan. (Order No. AL-KO Jack
Set 1389235)
Align the wheel so that the receiver can be seen
in the centre of the rim opening.
Do not use the rim opening in which the tyre
valve is fitted.
2 Unscrew the plastic cap
and store in the tool kit box.
(When AL-KO Secure is not in use, always
screw the plastic cap in place.)
Insert the Locking Bolt
insert (8).
Insert the Locking bolt socket key
3
Line – up the locking bolts and assembly with
the receiver.
(12) from the receiver
(1) into the rim specific
(2)
