- Page 1 Dear users, the configuration for this camera is professional, so please read the user manual carefully before using the camera. IP Camera IP Camera (L series) (L series) User manual User manual 2013-01 V1.0...
- Page 2 Statement If the user manual can not help you to solve the problem, please call our technology center for solutions. We will update the content for the new functions without notice. Notice 1 、 Installation Environment Keep away from the places for high-temperature, heat source and direct sunlight; ...
-
Page 3: Table Of Contents
L SERIES IP CAMERA USER MANUAL Index PRODUCT INTRODUCTION..........................................4 RODUCT SUMMARY .................. ACKAGE FOR TYPICAL PRODUCTION INSTALLATION GUIDE.............................................. 5 CONNECTION LAN....................5 IRED CONNECTION TO WIFI LAN....................6 CONNECTING TO WAN......................7 ONNECTING TO OPERATION OF IE BROWSER....................9 .......................... -
Page 4: Product Introduction
1 Product introduction Product summary Thank you for choosing our company’s L series IP camera, the IP Camera combines a high quality digital video camera with network connectivity and a powerful web server to bring clear video to your desktop from anywhere on your local network or over the Internet. -
Page 5: Installation Guide
L SERIES IP CAMERA USER MANUAL √ √ √ √ Built-in Notice: Please check carefully if all listed items are included in the package, if anything missing, please contact vendor in time. guide Installation AP connection Power on the camera (Please check carefully output voltage of power adapter, don’t insert... -
Page 6: Wired Connection To Lan
L SERIES IP CAMERA USER MANUAL 2.2 Wired connection to LAN Power on the IP camera, connect IP camera to router by network cable, meanwhile, connect computer to the same router, example of figure 2. Figure Insert CD to computer driver, double click “LSearch_en.exe” in the CD, run the software, click “Search”, select the device searched, click “Browse”... -
Page 7: Wifi Connecting To Lan
L SERIES IP CAMERA USER MANUAL choose not to block. You can hold on reset button on the camera for 10 seconds to restore factory default if you forget user name and password, during the process, don’t disconnect the power, otherwise the camera maybe damaged. -
Page 8: Connecting To Wan
L SERIES IP CAMERA USER MANUAL Enter the Wireless LAN Setting, click the “Scan” button, it will show you all the wireless networks detected in the Wireless Network List column. Select one of them and tick “Using Wireless Lan”, then the relevant data of the selected wireless network will be shown in the following blanks. - Page 9 L SERIES IP CAMERA USER MANUAL Figure 7 Operation Steps: After login the interface of the router, choose “Port Forwarding” Choose “Add custom Service” Input IP camera http port Input IP address of IP camera, click “Apply” After finishing the port forwarding, you can use WAN IP address of router and http port of camera to visit the camera by remote computer as figure 6.
-
Page 10: Operation Of Ie Browser
L SERIES IP CAMERA USER MANUAL Operation of IE browser 3.1 View video After installing the plug-ins, click “Mode 1 to view” as Figure 3 to view the video (video as Figure 8). Figure 8 1 ） Audio, Talk, Record, Snapshot... -
Page 11: Device Information
L SERIES IP CAMERA USER MANUAL can set it in “Local Recording Path”, as figure 9. Figure 9 2 ） Multipicture change button If you add multi-devices in chapter 3.4.2 “multi-device setting”, it will connect other device to display pictures automatically when changing to 4, 9 split screen. In playing video area, you can select a picture to control audio, talk, record, snapshot and PTZ control etc. -
Page 12: Local Recording Path
L SERIES IP CAMERA USER MANUAL Figure 10 Remark ： Please carefully check the camera time, so it can be sure the alarm accuracy. 3.2.4 Local recording path The camera will be automatically create a file folder named “Record files” when the user don’t set “local recording path”... -
Page 13: Ap Settings
L SERIES IP CAMERA USER MANUAL Figure 12 Remark: The router connected to camera need to enable DHCP when the user uses “obtain IP from DHCP server”; the routers enable DHCP by default. 3.3.2 AP settings Example of chapter 2.1, the user can directly connect to the camera by mobile phone and laptop with WiFi. -
Page 14: Third Party Ddns Setting
L SERIES IP CAMERA USER MANUAL 3.3.5 Third party DDNS setting User can also use third party DDNS, such as www.dyndns.com, User must apply a free domain name from this website and fill the info into the below blanks (Figure 15) and save the settings. -
Page 15: Mail Service Setting
L SERIES IP CAMERA USER MANUAL After triggering the alarm, you can adopt several alarm mode in armed time, example of figure 17. Link to the Preset when alarming: need to set preset point of the camera; Send alarm info by email ( a email include a picture); every alarm trigger a email;... -
Page 16: Ftp Service Setting
L SERIES IP CAMERA USER MANUAL Figure 18 3.4.3 FTP Service Setting When alarming, the device will snap local picture and send them to FTP server, but need to set the FTP setting correctly. As figure 19, after the setting is finished, click “Test”... -
Page 17: User And Device Setting
L SERIES IP CAMERA USER MANUAL Figure 20 User and device setting 3.5.1 Multi-device Setting As Figure 21, User can add maximum 9 devices to view video simultaneously. Click “refresh” button to check the device in the LAN. When click a device, will popup setting dialogue and enter the device info, and click “Add”... -
Page 18: User Settings
L SERIES IP CAMERA USER MANUAL 3.5.2 User Settings Figure 22 3.5.3 PTZ settings Figure 23 Note: When you set cruise turns all the time, the camera will automatically stop after cruising one hour. 3.5.4 Maintain Figure 24 Click “Restore factory settings”, it will pop up a dialog to ask you if restore factory settings, the camera will restore factory settings and reboot after you confirmed. -
Page 19: Visiting Device By Other Software
L SERIES IP CAMERA USER MANUAL Visiting device by other software Other web browser Except IE browser, you can visit the camera by Firefox, Safari, Chrome, Opera browser etc., please select “Mode 2 to view”. Mobile phone software For more information, please see the user manual for mobile phone in attached CD, or download the latest software and user manual in our website. -
Page 20: Product Family For L Series
L SERIES IP CAMERA USER MANUAL Product family for L series 5.1 VGA Cube camera Figure 26 The camera adopts 300K pixels CMOS sensor, 3.6mm lens, built in MIC, 12 pieces IR LED, audio out socket. It uses 5V power adaptor. -
Page 21: Vga Ptz Camera
L SERIES IP CAMERA USER MANUAL 5.2 VGA PTZ camera (Model A ） Photoresistor IR LED RJ45 Antenna Reset DC Power Audio OUT Figure 27 camera adopts 300K pixels CMOS sensor, 3.6mm lens, built in PTZ and MIC, 11 pieces IR LED, audio out socket. It uses 5V power adaptor. - Page 22 L SERIES IP CAMERA USER MANUAL Appendix ： L series IP camera parameters comparison list...
- Page 23 L SERIES IP CAMERA USER MANUAL Product Function Video MJPEG compression Resolution VGA/QVGA/QQVGA Max. 30FPS Framerate Audio ADPCM compression Support HTTP, DHCP, IEEE 802.11b/g/n, NTP, FTP, SMTP, P2Pprotocol etc; Main software Support motion detection; function three level of user authority;...
- Page 24 L SERIES IP CAMERA USER MANUAL Statement ： If you have any questions of the manual, please contact our technical support. This manual will be updated periodically; the company reserves the right without prior notice.
