Owner's
Manual
Plow Blade
2850
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
Before Operating this
Equipment.
2862
ATV ACCESSORIES
Universal Mount
2646
Sold as Separate Pieces!!!!
Fairllead Roller
8003
Hitch Mount
10260
Made In The
USA
REV 12-207
Advertisement
Related Manuals for Swisher 2850
Summary of Contents for Swisher 2850
- Page 1 Owner’s Manual Plow Blade 2850 ATV ACCESSORIES Sold as Separate Pieces!!!! IMPORTANT Read and follow all Safety Precautions and Instructions Before Operating this Equipment. Universal Mount 2646 Hitch Mount 10260 Made In The Fairllead Roller 8003 REV 12-207 2862...
- Page 2 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the product will be needed before any warranty claim can be processed.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. Failure to observe the following safety instructions could result in serious injury or death. - Page 4 REFER TO FIGURES 1 AND 2 WHILE ASSEMBLING THIS PORTION OF THE PLOW ATTACHMENT Unpack parts and make sure all are included. If they are not contact the dealer where the Swisher Plow was purchased. Locate the pivot weldment (2) and assemble to the blade (3) using two ½-13 X 2” bolts (14) two ½-13 nyloc nuts (8) and two bushing (32) as shown.
- Page 5 PLOW ATTACHMENT ASSEMBLY ITEM NO. QTY. PART NO. DESCRIPTION QTY PART NO. DESCRIPTION ITEM NO. 2588TK Mount - Plow NB212 Nut - HNC, 3/8-16 2323TK Pivot - Weldment NB272 Washer - SAE Flat 3/8 2139TK Blade - Rolled Weldment, 62" TR150W Washer - .531 X 1.5 2331TK Block - Tilt...
- Page 6 This is where you will attach your winch or manual lift pulley, sold separately. With your Swisher ATV Accessory Mount already installed, attach the plow using plow mount pin (6) and two 3/16 click pins (7).
-
Page 7: Adjustment And Operation
ADJUSTMENT AND OPERATION PUSH YOUR PLOW AROUND!! THE TENSION PLACED ON THE TILT SPRINGS DETERMINE THE AMOUNT OF PRESSURE THAT MUST BE APPLIED TO THE BLADE BEFORE IT FOLDS OVER IF SOMETHING IS HIT. ADJUST THE SPRINGS BY LOOSENING THE NUTS (12) ON THE EYEBOLTS (18) AND ADJUSTING UNTIL THE BLADE DOES NOT FOLD OVER DURING NORMAL OPERATION BUT WILL FOLD IF AN OBJECT IS STRUCK. - Page 8 Owner’s Manual ATV ACCESSORIES Plow Blade 2850 WHEN ORDERING PARTS, PLEASE HAVE THE FOLLOWING INORMATION AVAILABLE: * PRODUCT – ________________ * SERIAL NUMBER - _______________ * MODEL NUMBER - _______________ TYPE - _______________ * PART NUMBER WITH PAINT CODE * PART DESCRIPTION...
