- Page 1 IonPac ®...
- Page 2 TCC -ULP1 Column – Ultra Low Pressure, 5 x 23 mm (P/N 063783) TCC -XLP1 Column – Extremely Low Pressure, 6 x 16 mm (P/N 063889) ® Dionex Corporation, 2005 Document No. 034973 Revision 06 September 2005 Doc. No. 034973-06 ©2005 DIONEX September 2005...
-
Page 3: Table Of Contents
Poor Peak Shape............................16 APPENDIX A...................................17 A.1 Recommended Operating Pressures .........................17 A.2 Column Start-up ..............................17 A.3 Column Storage ..............................17 A.4 Column Cleanup of Polyvalent Cations and Acid-soluble Contaminants .............17 A.5 Column Cleanup Of Organic/Cationic Contaminants ..................17 Doc. No. 034973-06 ©2005 DIONEX September 2005... -
Page 4: September
Safety information can help prevent bodily harm. SAFETY Warning information can help prevent equipment harm. WARNING Caution information can help prevent problems. CAUTION Note information can help with tips for improved use. NOTE Doc. No. 034973-06 ©2005 DIONEX September 2005... -
Page 5: Introduction
10-32 and 1/4-28 threaded ThermoFlare ports, DIONEX recommends the use of Tefzel® liquid lines with a PEEK ferrule/bolt fitting on one end and a 1/4-28 ThermoFlare fitting on the other end. See, “DIONEX Liquid Line Fittings,” for detailed instructions on purchasing or making these lines. - Page 6 Typical Backpressure Standard Flow Rate Maximum Flow Rate Column MPa at 30 ºC mL/min mL/min TCC-LP1 < 70 (0.48) 0.50 4-mm TCC-ULP1 < 45 (0.31) 0.50 5-mm TCC-XLP1 < 30 (0.21) 0.50 6-mm Doc. No. 034973-06 ©2005 DIONEX September 2005...
-
Page 7: Installation
2. Column Body 6 x 16 mm (P/N 063561) 3. Bed Support (Frit) (P/N 063606) 4. Bed Support Assembly (P/N 063688) 5. 9-mm Column End Fitting (P/N 048298) FIGURE 2 TCC-XLP1 Column Components Doc. No. 034973-06 ©2005 DIONEX September 2005... -
Page 8: Operation
TCC-LP1. Alternately, you can use a separate positive displacement pump such as the Dionex DQP pump (P/N 035250). When using a pump, ensure that a high pressure damper is used. Pump flow rates of approximately 3 mL/min can be used while maintaining sample concentration efficiencies high enough to ensure good quantification. - Page 9 Figure 3 shows the configuration for sample loading using a Rheodyne valve. FIGURE 3 Configuration for Determining Trace Levels of Cations Figure 4 shows the configuration for sample loading using a slider valve. FIGURE 4 Loading the TCC-LP1, TCC-ULP1, or TCC-XLP1 Column Doc. No. 034973-06 ©2005 DIONEX September 2005...
-
Page 10: Reagent And Sample Handling
C. 1 µg/L working standard solutions may be prepared by diluting 1 mL of the 1 mg/L stock standard to 1,000 mL. These working standards are stored in polystyrene containers. They are stable up to 8 days, but Dionex recommends daily preparation since standard response is critical in the results of your analysis. -
Page 11: Concentrator Capacity
75% of this value. This will ensure that there is a safety margin built into the concentration process in case a sample in a series of concentration experiments has a slightly higher ionic concentration. FIGURE 5 Linearity of Lithium Concentrator Injection Doc. No. 034973-06 ©2005 DIONEX September 2005... - Page 12 F. Record the resulting chromatogram and calculate the breakthrough volume, as shown in Figure 7, “Typical Data Obtained in the Determination of the Breakthrough Volume.” G. For practical purposes, the volume concentrated should be below 75% of the breakthrough volume. Doc. No. 034973-06 ©2005 DIONEX September 2005...
- Page 13 Linearity Determinations for Concentrator Injection Time (min) that the simulated sample is pumped through the TCC-LP1, TCC-ULP1, or TCC-XLP1 after the single ion injection FIGURE 7 Typical Data Obtained in the Determination of the Breakthrough Volume Doc. No. 034973-06 ©2005 DIONEX September 2005...
-
Page 14: Example Applications
® AutoSuppression Recycle Mode ™ MMS Regenerant: 100 mN TBAOH (Use Dionex Cation Regenerant Solution P/N 039602) The following example demonstrates the advantages of sample concentration with low sensitivity detection versus direct injection with high sensitivity detection. Peaks µg/L (ppb) 1. -
Page 15: Concentration In The Manual Mode
Electrolytic Suppressor, CAES ® or MMS Suppressor Cation MicroMembrane Suppressor, CMMS MMS Regenerant: 100 mN TBAOH (Use Dionex Cation Regenerant Solution P/N 039602) Expected Background Conductivity: < 2 µS Expected System Operating Back Pressure: < 1,300 psi (8.96 MPa) Peaks µg/L (ppb) -
Page 16: Troubleshooting Guide
Troubleshooting Guide in the appropriate operator’s manual. If you cannot solve the problem on your own, call your nearest Dionex Regional Office (see, “Dionex Worldwide Offices” on the Dionex Reference Library CD-ROM). 5.1. High Backpressure from a Contaminated Inlet Bed Support If the TCC-LP1, TCC-ULP1, or TCC-XLP1 column displays high backpressure, the bed support in the column inlet may be contaminated. -
Page 17: High Background, Noise, Or Baseline Instability
Assistance is available for any problem during the shipment or operation of Dionex instrumentation, columns, and consumables through the Dionex North America Technical Call Center at 1-800-DIONEX-0 (1-800-346-6390) or through any of the Dionex Offices listed in “Dionex Worldwide Offices” on the Dionex Reference Library CD-ROM. Doc. No. 034973-06 ©2005 DIONEX... -
Page 18: Recommended Operating Pressures
F. Reconnect the cation guard, analytical column and the suppressor between the injection valve and the Conductivity Detector. Reconnect the Gradient Mixer or Cation Trap Column (CTC-1) between the gradient pump and the Injection Valve. Resume operation. Doc. No. 034973-06 ©2005 DIONEX September 2005...
