EPYC ION 600 Manual page 3

DEFINITIONS FOR ILLUMINATED LED INDICATORS
Icon Name Alarm
Using AC OFF
Beep once every
30 seconds
Using Battery
Rapid beeping
every 0.5 second
Fault Constant Tone
TECHNICAL SPECIFICATIONS
Model 600VA
Capacity (VA/W) 600/360
Input
Nominal Voltage range
NominalFrequency range
Output
On Battery Output Voltage
On Battery Output Frequency
Overload Protection
Advanced function Suitable for APFC loads (up to 70% of nominal load)
Physical
Dimensions WxHxD (mm)
Weight 2.7kg
Battery
Sealed Maintenance Free
1x 12V/5Ah
Lead Acid Battery
Typical Recharge Time
Warning Diagnostics
Indicators
Audible Alarms
Environmental
Operating Temperature
Operating Relative Humidity
Management
Auto-Charger
Auto-Restart
USB COMM.Port
RJ45/11Communication
Protection Ports
Condition
Normal
Utility Failure – The UPS is providing power to
the outlets from its battery.
Utility Failure – The UPS is providing battery power. Rapid
beeping indicates the unit will run out of power shortly.
Battery Overload – Occurs when connected
Equipment exceeds the listed capacity of the UPS. Turn
the UPS off, unplug at least one piece of equipment from
the outlets, reset the circuit breaker and turn the unit on.
800VA
800/480
180-270VAC
50/60Hz
220-240VAC
50/60 Hz +/-1%
Breaker
90x190x235
3.5kg
1x 12V/7.5Ah
8 Hours
Power On
On Battery, Low Battery, Overload, Fault
0°C to 40°C
0 to 90%
Yes
Yes
Yes
Yes
TROUBLE SHOOTING
Problem Possible Cause
Batteries are not fully charged.
The UPS does not perform
expected runtime.
Battery is slightly worn out.
The on/off switch is designed to
prevent damage by rapidly
turning it off and on
The UPS will not turn on.
The unit is not connected to an
AC outlet.
The battery is worn out.
Mechanical problem.
The outlets stop providing
Circuit breaker has tripped due to
power to equipment.
an overload
Circuit breaker button is
projecting from the side
of the unit.
Batteries are discharged
The USB/serial cable is not
connected
Power Guide Management
Software is inactive
The UPS is not providing battery
power
MANAGEMENT SOFTWARE DOWNLOAD
The management software provides a user-friendly
interface for your power systems. The graphic interface
is intuitive and displays essential power informations at
a glance.
Installation procedure:
1. Download Power Guide software (for Windows or
Linux) or Power Master software (for MacOS) from
the website: www.justepyc.com
2. Double-click the file and follow the installation steps.
3. Power Guide: when your computer restarts, the
Power Guide software will appear as a blue icon
located in the system tray.
Power Master: to access Power Master enter http://localhost:3052 adress on your web browser.
MAINTENANCE
Before starting any cleaning operation, be sure that:
1. The AC Input Voltage for the UPS has been removed.
2. The UPS is OFF.
Use a cloth moisteened only with water to externally clean the UPS. Before restarting the UPS be sure it is completely
dry.
If the UPS works in an environmental unusually dusty or dirty, remove the dirty from the ventilation holes
If any liquid gets inside the UPS, do not start the unit and contact Technical Service immediately.
Solution
Recharge the battery by leaving the UPS plugged in.
Contact Technical Support for battery replacing.
Turn the UPS off.
Wait 10 seconds and then turn the UPS on
The unit must be connected to a 220-240V outlet.
Contact Technical Support for battery replacing.
Contact Technical Support.
Turn the UPS off and unplug at least one piece of equipment.
Reset the circuit breaker by depressing the button,
and then turn the UPS on.
Allow the unit to recharge for at least 4 hours.
Connect the USB/serial cable to the UPS unit and an open USB/serial port on
the back of the computer. You must use the cable that came with the unit.
Shutdown your computer and turn the UPS off. Wait 10 seconds and turn the
UPS back on. This should reset the unit
