CDR PlusWire
User Guide
B1051067
Sirona Dental, Inc.
th
30-30 47
Avenue
Long Island City, NY 11101
USA
(718) 937-5765
(718) 937-5962 (fax)
Sirona Dental GmbH
Sirona Straße 1
5071 Wals bei Salzburg
Austria
PART NUMBER B1051067 REV. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Schick CDR PlusWire and is the answer not in the manual?

Questions and answers

Summary of Contents for Sirona Dental Schick CDR PlusWire

  • Page 1 CDR PlusWire User Guide B1051067 Sirona Dental, Inc. 30-30 47 Avenue Long Island City, NY 11101 (718) 937-5765 (718) 937-5962 (fax) Sirona Dental GmbH Sirona Straße 1 5071 Wals bei Salzburg Austria PART NUMBER B1051067 REV. A...
  • Page 2 Copyright © 2013 by Sirona Dental, Inc. All Rights Reserved CDR is a registered trademark of Sirona Dental, Inc. Sirona Dental, Inc. products are covered by one or more of the following US Patents. Wired CDR® Sensors US 5,434,418; US 6,069,935; US 6,134,298 Wired and Wireless CDR®...
  • Page 3: Table Of Contents

    Contents 1. Overview ..................1 1.1. Purpose ............................1 1.2. Indications for Use ........................1 1.3. System Description ........................1 1.4. PC Workstation Description ...................... 1 2. Installing the CDR PlusWire Sensor ........3 2.1. What You Will Need to Complete this Section ................ 3 2.2.
  • Page 4 List of Tables Table 1. Footpedal Actions ......................... 7 Table 2. Keyboard Shortcuts ......................7 Table 3. Compatible CDR Interfaces ....................9 Table 4. Specifications ........................18 Table 5. Guidance and Manufacturer's Declaration - Electromagnetic Emissions ......19 Table 6. Guidance and Manufacturer's Declaration - Electromagnetic Immunity ......19 Table 7.
  • Page 5 CDR PlusWire Sensor should have a smooth finish, with no evidence of chipping or damage. If detected, discontinue use of that sensor and contact your local distributor of Sirona Dental products for further instructions. The CDR PlusWire cable should be checked for any damage in the shielding, such as exposed or frayed shields or broken connections to solder points.
  • Page 6 Operate CDR PlusWire Sensors as Directed Always use CDR PlusWire Sensors in accordance with the directions and recommendations contained in this User Guide. Do not attempt to modify CDR PlusWire Sensors or use them in system configurations not specified in this document. Observe Proper Handling and Placement for CDR PlusWire Sensors As with any dental device or instrument placed intraorally, proper care must be taken when using CDR PlusWire Sensors to ensure...
  • Page 7 RF Interference Considerations Although the CDR PlusWire equipment is designed to provide a reasonable degree of protection from electromagnetic interference, according to IEC International regulations, it must be installed at an adequate distance from electricity transformer rooms, static continuity units, two-way amateur radios and cellular phones. To ensure proper operation, the latter (meaning, electricity transformer rooms, static continuity units, two-way amateur radios and cellular phones) can be used only at a minimum distance of 5 feet (1.5m)
  • Page 8 (for example Staticide 2005/2002) will also help eliminate static build-up in your office. Product Manuals from Sirona Dental The contents of this manual are subject to change without prior notice. For the latest version of this user guide and other product...
  • Page 9 Explanation of Symbols Sirona Dental products display a number of markings which indicate compliance with regulatory requirements or which provide information in accordance with applicable technical standards. The symbols and their descriptions are provided below. Symbol Description Conforms to European Union Medical Devices Directive (MDD)
  • Page 10 August 13, 2005. This directive, which seeks to reduce the waste of electrical and electronic equipment through re-use, recycling, and recovery, imposes several requirements on producers. Sirona Dental and its Dealers are committed to complying with the Directive. WEEE Marking...
  • Page 11 WEEE from Users other than Private Households According to the WEEE Directive, Sirona Dental or its Dealers will fulfill its obligations for the management of WEEE from users other than private households. Furthermore, as required by the WEEE Directive, in order to enable...
  • Page 12 CDR PlusWire CDR PlusWire Expanded View CDR PlusWire Completed Installation B1051067 Rev. A CDR PlusWire User Guide...
  • Page 13: Overview

    Imaging software applications such as CDR DICOM provide the capability to display, manipulate, store, and print images acquired from CDR Sensors. USB cables are available from Sirona Dental at the following lengths: 5 meter (B2250150), 2 meter (B2250151), and 0.5 meter (B2250152). CDR PlusWire User Guide...
  • Page 14 Getting the best results from your CDR system begins with having a computer system suitable for intraoral imaging. For optimum performance, we recommend the following: 1. Compatible operating system (Windows Vista/Windows XP) 2. Intel Pentium D or Intel Core 2 Duo processors 3.
  • Page 15: Installing The Cdr Pluswire Sensor

    2. Installing the CDR PlusWire Sensor 2.1. What You Will Need to Complete this Section To expedite installation, please have the CDR PlusWire Sensor (Starter) Kit available (Size 2 Sensor: P/N B1205000, or Size 1 Sensor: P/N B1105000), which includes the following items shown below: 1.
  • Page 16: Connecting The Cdr Pluswire Sensor

    2.2. Connecting the CDR PlusWire Sensor Perform the following steps to connect the Sensor to the appropriate CDR Interface. 1. Connect the USB cable from the CDR Remote, or CDR Remote HS, or SDX USB interface to the PC workstation. 2.
  • Page 17: Using The Cdr Pluswire Sensor With Cdr Dicom

    2.4. Using the CDR PlusWire Sensor with CDR DICOM NOTE: Refer to the CDR DICOM User Guide, P/N B1051047, for detailed information on the use and operation of CDR DICOM software. Start CDR DICOM from the Windows Start button or the CDR DICOM shortcut on your desktop.
  • Page 18 A. If your acquisition mode is set to AutoTake, the first empty view box in the exam is pre-selected and flashes green (default setting). Skip ahead to step 7. B. If your acquisition mode is set to manual, select an empty target frame that corresponds to the Sensor’s location in the patient’s mouth.
  • Page 19: Acquiring X-Ray Images With The Footpedal

    2.5. Acquiring X-ray Images with the Footpedal Optional serial footpedals (P/N B2501100) are available to navigate view boxes inside a patient exam and to control the capture of X-ray images. Refer to the following table for actions associated with footpedal operation. Table 1.
  • Page 20: Replacing The Cdr Pluswire Cable

    3. Replacing the CDR PlusWire Cable 3.1. What You Will Need to Complete this Section To expedite installation, please have a CDR PlusWire Cable Replacement Kit available. The kits are identified by cable length: B1205102 (3-ft cable), B1205101 (6-ft cable), B1205103 (9-ft cable).
  • Page 21: Before Replacing The Cdr Pluswire Cable

    Sensor interface during cable replacement steps to avoid potential damage to Sensor components. When performing cable replacement, always work outside the patient area, using the tools and materials supplied and /or recommended by Sirona Dental. IMPORTANT! Like other electronic devices, your PlusWire Sensor is susceptible to electrostatic discharge (ESD), particularly when the device is used in or around carpeted areas or low-humidity environments.
  • Page 22: Description Of The Cdr Pluswire Utility

    3.3. Description of the CDR PlusWire Utility The Sensor edge-card does more than just provide the means for the CDR Sensor to connect to USB Remotes or to the Sensor interface on the SDX system. It also includes specific information about the Sensor itself and uniquely identifies it for the purpose of Sensor calibration.
  • Page 23: Cdr Pluswire Cable Replacement

    3.5. CDR PlusWire Cable Replacement IMPORTANT!: Close CDR DICOM and any other imaging application (EagleSoft or Patterson Imaging) prior to starting the cable replacement procedure. Step Directions and Screenshots Connect the CDR Sensor with the original cable to the CDR Interface (CDR Remote, CDR Remote HS, or Sensor Interface on the SDX Intraoral X-ray...
  • Page 24 Step Directions and Screenshots Click Read. Sensor Size and Serial Number information are displayed Click Next. Disconnect Sensor with the original cable (to be replaced) from the CDR Interface. Connect the new replacement cable to the CDR Interface. You do not need to have the cable attached to the Sensor for this step.
  • Page 25 Step Directions and Screenshots The Data Transfer Successful screen is displayed. Click Finish and remove the CD. The new cable is ready to be attached to the Sensor. Carefully peel away the black label from the back of the Sensor. A.
  • Page 26 Step Directions and Screenshots IMPORTANT! The strip must be seated properly in its slot for the Sensor to function. Verify correct seating by applying a small amount of finger pressure to ensure the strip fits evenly in the slot. Align cable to Sensor as shown. Ensure that the keying feature in the Sensor mates with the corresponding keying feature in...
  • Page 27: Protective Measures

    If you are using the Rinn holder system, refer to their product documentation or their website for more information. Sirona Dental disposable tabs and holders are single–use only, as are the hygenic barriers (sheaths) that are used with them.
  • Page 28: Recommended Disinfectant

    1. Remove and discard all protective hygienic barriers and / or sheaths from the Sensor prior to removing disposable gloves. 2. Place the Sensor on a tray covered by a disposable liner, or in a receptacle that can be thoroughly disinfected. 3.
  • Page 29: Maintenance

    Sirona Dental products. In the United States, customers can contact the Patterson Technology Center at 877-498-6505. Outside the United States, please contact the authorized dealer for Sirona Dental products in your country or region. CDR PlusWire User Guide B1051067 Rev. A...
  • Page 30: Appendix A. Reference

    Appendix A. Reference A-1. Summary of Specifications CDR PlusWire is ETL-certified and complies with the following. Table 4. Specifications Item Value CAN/CSA C22.2 Medical Electrical Equipment Part 1: General Requirements for No.601.1-M90 Safety EC93/42/EEC Medical Device Directive Medical Electrical Equipment Part 1: General Requirements for IEC60601-1 Safety EMC/Safety...
  • Page 31: A-3. Emc Tables

    A-3. EMC Tables following tables provide PlusWire compliance information electromagnetic compatibility (EMC) electromagnetic immunity (EMI) standards. To ensure conformance, the customer or user must use the CDR PlusWire in environments that are consistent with these standards. USB cables used with CDR Interfaces must also comply with the same standards.
  • Page 32 IEC 60601 Test Compliance Immunity Test Guidance Level Level power supply or battery. IEC 61000-4-11 40% U 40% U is the AC mains voltage NOTE: U (60% dip in (60% dip in prior to application of the test level. cycles cycles for 5 for 5...
  • Page 33: Table 7. Recommended Separation Distance Between Portable And Mobile Rf Communications Equipment And Cdr Pluswire

    NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
  • Page 34 Index Acquiring X-ray Images, 5 Leakage Current Statement, 18 Acquiring X-ray Images with Footpedal, 7 Acquiring X-ray Images with Shortcuts, 7 After Replacing Cable, 10 Maintenance, 17 Be Sure to Disconnect the Sensor from the CDR Operate CDR PlusWire Sensors as Directed, iii Remote, or CDR Remote HS, or SDX Sensor Overview, 1 Interface before Performing Cleaning and...
  • Page 35 Visual Inspection, 17 Waste Electrical and Electronic Equipment (WEEE), viii Workstation, 1 CDR PlusWire User Guide B1051067 Rev. A...
