  • Page 1 Installation Guide ® FibeAir IP-20V Part ID: BM-0296-0 | DOC-00042494 Rev A.04 December 2018 © Copyright 2018 by Ceragon Networks Ltd. All rights reserved.
  • Page 2 Installation Guide for FibeAir IP-20V Notice This document contains information that is proprietary to Ceragon Networks Ltd. No part of this publication may be reproduced, modified, or distributed without prior written authorization of Ceragon Networks Ltd. This document is provided as is, without warranty of any kind.

  • Page 3: Table Of Contents

    3.6.1 Fiber Optic Cables – Single Mode ....................27 3.6.2 Fiber Optic Cables – Multi Mode ....................28 3.6.3 DC Cable and Connector ......................29 3.6.4 Ethernet Cable and Specifications ..................... 29 Page 3 of 81 Ceragon Proprietary and Confidential...
  • Page 4 5.2.1 Procedure ........................... 70 Attaching the IP-20V to the Installation and Alignment Device ..........71 Performing Antenna Alignment ....................72 5.4.1 Adjusting the Antenna Azimuth ....................72 5.4.2 Adjusting the Antenna Elevation ....................78 Page 4 of 81 Ceragon Proprietary and Confidential...
  • Page 5 Figure 28: Removing the Azimuth Screws (Side View) ............76 Figure 29: Azimuth Screws in New Placement – Top View (Azimuth 45° to the Right) ..77 Figure 30: Repositioning the Azimuth Screws (Side View) ............77 Page 5 of 81 Ceragon Proprietary and Confidential...
  • Page 6 Table 18: CSFP Module Recommendations ................41 Table 19: SFP Module Recommendations for Third Party Equipment ........41 Table 20: Approved 10 GbE SFP+ Modules ................41 Table 21: Materials for Preparing Ethernet Data Cables ............50 Page 6 of 81 Ceragon Proprietary and Confidential...
  • Page 7 For the warranty to be honored, install the unit in accordance with the instructions in this manual. Target Audience This guide contains technical information about IP-20V installation, and is intended for use by qualified Ceragon technical personnel at all levels. Related Documents • FibeAir IP-20V Technical Description FibeAir IP-20C, IP-20S, and IP-20V User Guide •...

  • Page 8: Before You Start

    To avoid malfunctioning or personnel injuries, equipment or accessories/kits/plug-in unit installation, requires qualified and trained personnel. Changes or modifications not expressly approved by Ceragon Networks could void the user's authority to operate the equipment. Where special cables, shields, adapters and grounding kits are supplied or described in this manual, these items must be used, to comply with the FCC regulations.

  • Page 9: Précautions Générales Relatives À L'équipement

    électriques. Bruit de machine d’ordre - 3. GPSGV, le plus haut niveau de pression sonore s'élève à 70 dB (A) au maximum, dans le respect de la norme ISO EN 7779. Page 9 of 81 Ceragon Proprietary and Confidential...

  • Page 10: Allgemeine Vorsichtsmaßnahmen Für Die Anlage

    Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which • the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. • Page 10 of 81 Ceragon Proprietary and Confidential...

  • Page 11: Frequency Restrictions For Canada

    Installation Guide for FibeAir IP-20V Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Ceragon Networks Ltd.) could void the user’s authority to operate the equipment. This Class B digital apparatus complies with Canadian ICES-003.

  • Page 12: Inspection

    Check the packing lists and ensure that correct parts numbers quantities of goods have arrived. Inspect for any damage on the cases and equipment. Report any damage or discrepancy to a Ceragon representative, by e-mail or fax. Page 12 of 81...

  • Page 13: Product Hardware Description

    R&TTE Directive 1999/5/EC since 13 June 2017. Figure 1: IP-20V Rear View (Right) and Front View (Left) Figure 2: Cable Gland Construction Note: The Extension port is smaller than the other ports and requires a special gland. Page 13 of 81 Ceragon Proprietary and Confidential...

  • Page 14: Ip-20V Interfaces

    1GE or 10GE Eth traffic (user-configurable) Extension Port (Port 4): • ◦ Direct connection to CPU by technician (see User Guide for details) • Antenna Port – Ceragon proprietary flange (flange compliant with UG385/U) Page 14 of 81 Ceragon Proprietary and Confidential...

  • Page 15: Figure 4: Rsl Interface

    The voltage at the RSL port is 1.XX where XX is the RSL level. For example: 1.45V means an RSL of -45 dBm. Note that the voltage measured at the RSL port is not accurate and should be used only as an aid. Page 15 of 81 Ceragon Proprietary and Confidential...

  • Page 16: Poe Injector

    PoE_Inj_AO – Includes one DC power port (DC Power Port #1), with a power • input range of ±(40-60)V. Note: An AC-power PoE Injector option is also available. Contact your Ceragon representative for details. Page 16 of 81 Ceragon Proprietary and Confidential...

  • Page 17: Poe Injector Interfaces

    PoE port. This adaptor is located inside of the gland. In such configurations, only one electrical GbE interface is available (MGT). Figure 8: Two-Wire to PoE Port Power Adaptor Page 17 of 81 Ceragon Proprietary and Confidential...

  • Page 18: System Components

    Figure 9: IP-20V Figure 10: PoE Injector Figure 11: Easy-Install Mounting and Alignment Kit Adaptors and Installation Kits Table 2: IP-20V Accessories Marketing Model Description IP-20E_V_Flat_Ant_Mounting_Kit IP-20E,IP20V Flat Ant. Mounting Kit Page 18 of 81 Ceragon Proprietary and Confidential...

  • Page 19: Table 3: Poe Injector

    PoE Injector 19” Rack Mount Kit PoE_Inj_ETSI_Rack_Mnt_kit PoE Injector ETSI Rack Mount Kit Table 4: Two-Wire to PoE Port Power Adaptor Marketing Model Description IP-20_Mini_Power_Adaptor RJ45 to TB Power Adaptor With Protection Page 19 of 81 Ceragon Proprietary and Confidential...

  • Page 20: Power Specifications

    2.6.4 PoE Injector Power Input Standard Input -48 or +24VDC (Optional) DC Input range ±(18 /40.5 to 60) VDC Optional. +18VDC extended range is supported as part of the nominal +24VDC support. Page 20 of 81 Ceragon Proprietary and Confidential...

  • Page 21: Important Notes

    Temperature range for exceptional temperatures; tested successfully, with limited margins: -45°C (-49°F) to +60°C (140°F) Humidity: 5%RH to 100%RH IEC529 IP66 Storage: ETSI EN 300 019-1-1 Class 1.2 Transportation: ETSI EN 300 019-1-2 Class 2.3 Page 21 of 81 Ceragon Proprietary and Confidential...

  • Page 22: Cable Installation And Grounding

    50m, using the kit CAT5E_gnd_kit. Figure 12: Cable Grounding Kit Table 7: Cable Grounding Kit Marketing P/N Description CAT5E_gnd_kit High speed GND KIT for CAT5e SF/UTP 5.9-7.1mm outdoor cable Page 22 of 81 Ceragon Proprietary and Confidential...
  • Page 23 Installation Guide for FibeAir IP-20V To connect the grounding kit: 1 Strip the cable jacket. 2 Place the cable in the middle of the grounding bracket. 3 Close the grounding bracket around the cable. Page 23 of 81 Ceragon Proprietary and Confidential...
  • Page 24 4 Tighten the two screws to secure the grounding bracket around the cable. 5 Install the grounding lug on the grounding bar, or directly to the tower. 6 Tighten the grounding lug. Page 24 of 81 Ceragon Proprietary and Confidential...

  • Page 25: Grounding The Ip-20V Unit

    A 2-pole circuit breaker, a branch circuit protector, suitably certified in accordance with applicable national code and regulations, rated maximum 20A, shall be installed for full power disconnection in a building installation. Page 25 of 81 Ceragon Proprietary and Confidential...

  • Page 26: Power Source

    In areas in which severe lighting conditions are likely to occur, it is strongly recommended to add additional protection by placing lightning protectors on all electrical Ethernet cables, near the connection points with the IP-20V unit. Page 26 of 81 Ceragon Proprietary and Confidential...

  • Page 27: Available Cable Options

    END,WITH M28 GLAND,ARMORED,OUTDOOR CABLE,FO,DUAL LC TO LC,120M,SM,55mm OPEN 20_FO_SM_LC2LC_ARM_120m 20_FO_SM_LC2LC_ARM_120m END,WITH M28 GLAND,ARMORED,OUTDOOR IP-20_FO_SM_LC2LC_ARM_10m IP-20_FO_SM_LC2LC_ARM_10m CABLE,FO,DUAL LC TO LC,10M,SM,55mm OPEN END,WITH M28 GLAND,ARMORED,OUTDOOR CABLE,FO,DUAL LC TO LC,100M,SM,55mm OPEN 20_FO_SM_LC2LC_ARM_100m 20_FO_SM_LC2LC_ARM_100m END,WITH M28 GLAND,ARMORED,OUTDOOR Page 27 of 81 Ceragon Proprietary and Confidential...

  • Page 28: Fiber Optic Cables - Multi Mode

    END,WITH M28 GLAND,ARMORED,OUTDOOR IP-20_FO_MM_LC2LC_ARM_120m IP-20_FO_MM_LC2LC_ARM_120m CABLE,FO,DUAL LC TO LC,120M,MM,55mm OPEN END,WITH M28 GLAND,ARMORED,OUTDOOR IP-20_FO_MM_LC2LC_ARM_10m IP-20_FO_MM_LC2LC_ARM_10m CABLE,FO,DUAL LC TO LC,10M,MM,55mm OPEN END,WITH M28 GLAND,ARMORED,OUTDOOR IP-20_FO_MM_LC2LC_ARM_100m IP-20_FO_MM_LC2LC_ARM_100m CABLE,FO,DUAL LC TO LC,100M,MM,55mm OPEN END,WITH M28 GLAND,ARMORED,OUTDOOR Page 28 of 81 Ceragon Proprietary and Confidential...

  • Page 29: Dc Cable And Connector

    5E,FTP,4X2X24AWG,ARMORED,UV RESIST,305M This cable has the following specifications: Suitable for: • ◦ Fast Ethernet ◦ Gigabit Ethernet ◦ The numbers in the figure below refer to the items listed beneath the figure. Page 29 of 81 Ceragon Proprietary and Confidential...

  • Page 30: Figure 13: Cable Design

    • • [3]Screen: Alu/Pet foil. Alu outside • [4]Tinned copper braid • [5]Jacket Table 8: Ethernet Cable Color Code Pair Wire A Wire B WHITE-blue BLUE WHITE-orange ORANGE WHITE-green GREEN WHITE-brown BROWN Page 30 of 81 Ceragon Proprietary and Confidential...

  • Page 31: Outdoor Ethernet Cable Specifications

    6-7.1 mm (in order to be compatible with the grounding clamp, CAT5E_gnd_kit) Operating and Storage -40°C - 85°C temperature range Flammability rating According to UL-1581 VW1, IEC 60332-1 RoHS According to Directive/2002/95/EC Page 31 of 81 Ceragon Proprietary and Confidential...

  • Page 32: Outdoor Dc Cable Specifications

    Item Description SI-1229-0 Fiber_clamp_2cbl_4.0-7.0mm DUAL FEADER CLAMP FOR 4.0-7.0mm CABLE 2 WAY. SI-1230-0 Fiber_clamp_4cbl_4.0-7.0mm DUAL FEADER CLAMP FOR 4.0-7.0mm CABLE 4 WAY. SI-1231-0 Fiber_clamp_6cbl_4.0-7.0mm DUAL FEADER CLAMP FOR 4.0-7.0mm CABLE 6 WAY. Page 32 of 81 Ceragon Proprietary and Confidential...

  • Page 33: Special Instructions For Use Of Glands

    Cable protective caps kit 10 pcs, IP-20C/S/E In order to remove the plastic plugs for the unit, you can use the flange of supplied glands to disconnect them as shown in the figures below. Page 33 of 81 Ceragon Proprietary and Confidential...

  • Page 34: General Installation Procedure

    2 Expose 10 mm at the edge of each of the two wires. For all installations, perform the following steps: 1 Before inserting a cable, you must disassemble the gland cap and gland rubber from the gland body. Page 34 of 81 Ceragon Proprietary and Confidential...
  • Page 35 4 Slide the cable into the body of the gland. If you are using a gland cap (see Step 5), make sure to leave enough space for the gland cap to fit into the gland without disturbing the cable. Page 35 of 81 Ceragon Proprietary and Confidential...
  • Page 36 Before screwing the gland into the radio unit, you must remove the gland cap. Page 36 of 81 Ceragon Proprietary and Confidential...
  • Page 37 Important Note! Pay attention that the gland rubber is properly located and not damaged during the tightening of the gland cap. If the gland thread is damaged do not use it! Page 37 of 81 Ceragon Proprietary and Confidential...

  • Page 38: Figure 14: Tightening The Front Portion Of The Gland

    If the main portion of the gland is rotated while the rear portion is seizing the cable, this may ruin the cable connector. Figure 14: Tightening the Front Portion of the Gland Figure 15: Tightening the Rear Portion of the Gland Page 38 of 81 Ceragon Proprietary and Confidential...
  • Page 39 Installation Guide for FibeAir IP-20V 12 Secure the cable to the lip of the gland using a tie wrap. Page 39 of 81 Ceragon Proprietary and Confidential...

  • Page 40: Connecting An Optical Fiber Cable And Sfp

    Table 17: SFP Module Recommendations Part Number Marketing Model Item Description AO-0098-0 SFP-GE-SX-EXT-TEMP XCVR,SFP,850nm,MM,1.0625 Gbit/s FC/ 1.25 GBE, INDUSTRIAL GRADE,SINGLE PACK KIT AO-0097-0 SFP-GE-LX-EXT-TEMP XCVR,SFP,1310nm,1.25Gb,SM,10km,W.DDM,INDUSTRIAL GRADE,SINGLE PACK KIT AO-0228-0 SFP-GE-COPER-EXT- XCVR,SFP,COOPER 1000BASE-T,RX_LOS TMP-LOS-DIS DISABLE,INDUSTRIAL TEMP Page 40 of 81 Ceragon Proprietary and Confidential...

  • Page 41: Table 18: Csfp Module Recommendations

    XCVR,SFP+,850nm,MM,10 Gbit/s, INDUSTRIAL GRADE AO-0264-0 SFP+10GBASE-LR10- SFP+ 10GE OPT 10GBASE- XCVR,SFP+,1310nm,SM,10 Gbit/s,10km,INDUSTRIAL EXT-TEMP LR,10km,EXT-TEMP GRADE,SINGLE P Note: Ceragon recommends the use of SFP and SFP+ modules certified by Ceragon, as listed above. Page 41 of 81 Ceragon Proprietary and Confidential...

  • Page 42: Connecting Optical Fiber To Sfps

    2 Split the connector into two separate LC connectors (one for each fiber). 3 Remove the gland cap and rubber from the gland body. 4 Slide the gland cap into the cable. 5 Slide the rubber into the cable. Page 42 of 81 Ceragon Proprietary and Confidential...
  • Page 43 Important Note: If you are raising the cable to a radio unit on a tower, this step is crucial to prevent the cable from slipping from the gland, which could damage the connector. Page 43 of 81 Ceragon Proprietary and Confidential...
  • Page 44 A new tie wrap must be used to secure the cable to the gland at the end of the procedure, as described in Step 13. 10 Connect the connector into the IP-20V connector. Page 44 of 81 Ceragon Proprietary and Confidential...
  • Page 45 If there is resistance, stop immediately, thread out the gland, and verify that the gland threads are not damaged. Then, tighten the gland again. If the gland thread is damaged do not use it! Page 45 of 81 Ceragon Proprietary and Confidential...
  • Page 46 Installation Guide for FibeAir IP-20V 13 Secure the cable to the gland using a tie wrap. Page 46 of 81 Ceragon Proprietary and Confidential...

  • Page 47: Connecting A Dc Power Cable

    4 Insert the power cable wires into the power connector. 5 Insert the power cable wires into the power connector. Match “+” to the 0V wire and “-“ to the -48V wire, and tighten the screws with a flat screwdriver. Page 47 of 81 Ceragon Proprietary and Confidential...
  • Page 48 If there is resistance, stop immediately and verify that the gland is not being inserted at an angle. Tightening the gland at an angle can ruin the thread on the gland and prevent proper sealing of the interface. Page 48 of 81 Ceragon Proprietary and Confidential...
  • Page 49 Installation Guide for FibeAir IP-20V 10 Tighten the gland cap. 11 Secure the cable to the gland with a tie wrap. Page 49 of 81 Ceragon Proprietary and Confidential...

  • Page 50: Connecting The Ethernet Cable

    1 Prepare the gland and insert the cable, as described in General Installation Procedure on page 34. 2 Strip off approximately 45 mm of the outer insulation jacket from the CAT5E cable. Page 50 of 81 Ceragon Proprietary and Confidential...
  • Page 51 Ethernet cable should extend into the plug by about 13 mm and held in place by the crimp. 9 Extend the cable jacket with the shield into the connector about 5 mm for strain relief and shielding connection. Page 51 of 81 Ceragon Proprietary and Confidential...

  • Page 52: 3.11.2 Preparing The Ethernet Cable Already Assembled

    3.11.2 Preparing the Ethernet Cable Already Assembled To prepare the Ethernet cable already assembled: 1 Release the gland cap and the gland rubber slightly. Page 52 of 81 Ceragon Proprietary and Confidential...

  • Page 53: 3.11.3 Connection Of Ethernet Cable To Ip-20V

    To connect the Ethernet cable to the IP-20V: 1 Remove the relevant cap from the IP-20V radio. You can use the side of the gland to unscrew the cap. 2 Connect the CAT5E cable to the IP-20V. Page 53 of 81 Ceragon Proprietary and Confidential...
  • Page 54 Installation Guide for FibeAir IP-20V Page 54 of 81 Ceragon Proprietary and Confidential...
  • Page 55 Tightening the gland at an angle can ruin the thread on the gland and prevent proper sealing of the interface. 4 Tighten the gland cap. 5 Secure the cable to the gland using a tie wrap. Page 55 of 81 Ceragon Proprietary and Confidential...

  • Page 56: Poe Injector Installation And Connection

    10m (according to ANSI/TIA-568 standard). Note! For the warranty to be honored, the connection must be through the glands only. Do not open the PoE injector box cover. Page 56 of 81 Ceragon Proprietary and Confidential...

  • Page 57: Poe Injector Grounding

    Use Anchor Stainless Steel with flanged Hexagonal nut M6X70. 2 Drill two 6mm diameter holes with 100mm distance between the center of the holes. 3 Insert the anchors with the bolts. 4 Place the washers on the bolt. Page 57 of 81 Ceragon Proprietary and Confidential...
  • Page 58 Installation Guide for FibeAir IP-20V 5 Tighten the nuts. Page 58 of 81 Ceragon Proprietary and Confidential...

  • Page 59: Poe Injector Pole Mount Installation

    The Hose Clamp is not supplied with PoE injector kit. 3 Attach the PoE injector to the pole. 4 Connect the ends of the hose clamp. 5 Tighten the hose clamp using the captive screw. Page 59 of 81 Ceragon Proprietary and Confidential...

  • Page 60: Poe Injector 19" Rack Installation

    2 Mount the PoE Injector on the 19” adaptor through the wall mounting holes, using M6 screws and washers. 3 Mount the 19” rack adaptor to a 19” rack using four M6 screws and cage nuts. Page 60 of 81 Ceragon Proprietary and Confidential...

  • Page 61: Poe Injector Etsi Rack Installation

    1 Mount the PoE Injector to an ETSI rack using a 19” rack adaptor and ETSI adapting ears. 2 Connect the ETSI adapting ears to a 19” rack adaptor using four M6 screws. Page 61 of 81 Ceragon Proprietary and Confidential...
  • Page 62 4 Mount the 19” rack adaptor with the ETSI ears on the ETSI rack using four M6 screws and cage nuts. Note: For this type of installation, a 2RU space is required. Page 62 of 81 Ceragon Proprietary and Confidential...

  • Page 63: Installation Procedure And Antenna Alignment

    Page 63 of 81 Ceragon Proprietary and Confidential...

  • Page 64: Figure 17: Installation And Alignment Device - Azimuth Range

    Upon delivery, the installation and alignment device is aligned 45° downward (elevation) and straight ahead (azimuth). You can adjust the azimuth up to 45° in either direction by manually turning the azimuth base. Figure 17: Installation and Alignment Device – Azimuth Range Page 64 of 81 Ceragon Proprietary and Confidential...

  • Page 65: Figure 18: Installation And Alignment Device - Extended Azimuth Range

    Figure 19: Installation and Alignment Device – Delivery Elevation (45° Downward) Page 65 of 81 Ceragon Proprietary and Confidential...

  • Page 66: Figure 20: Installation And Alignment Device - Highest Elevation (45° Upward)

    Installation Guide for FibeAir IP-20V You can adjust the elevation upwards as far as 45° upward. Figure 20: Installation and Alignment Device – Highest Elevation (45° Upward) Page 66 of 81 Ceragon Proprietary and Confidential...

  • Page 67: Pole Mount Assembly And Installation

    • Open metric wrench set 5.1.1 Procedure 1. Open the outer bracket to slide the installation and alignment device onto the pole, then close the bracket as shown in the figure below. Page 67 of 81 Ceragon Proprietary and Confidential...
  • Page 68 Installation Guide for FibeAir IP-20V 2. To secure the installation and alignment device to the pole, tighten the four nuts on the outer bracket, two on each side as shown in the figure below. Page 68 of 81 Ceragon Proprietary and Confidential...

  • Page 69: Wall Mount Assembly And Installation

    Note: In wall mount assembly, the 4 M10 nuts, 2 M10 flat and spring washers, 2 M10x150 screws, and the rear bracket that are supplied with the mounting kit are not used. Page 69 of 81 Ceragon Proprietary and Confidential...

  • Page 70: Procedure

    3. Insert the anchor screws into the wall. 4. Place the mounting kit in front of the 4 anchor screws and tighten the 4 M8 screws, spring washers, and flat washers to secure the mounting device to the wall. Page 70 of 81 Ceragon Proprietary and Confidential...

  • Page 71: Attaching The Ip-20V To The Installation And Alignment Device

    Figure 21: Horizontal Polarization – Screws Figure 22: Vertical Polarization – Screws and Washers and Washers Figure 23: Horizontal Polarization – Radio and Figure 24: Horizontal Polarization – Antenna (Front) Installation and Alignment Kit Page 71 of 81 Ceragon Proprietary and Confidential...

  • Page 72: Performing Antenna Alignment

    Adjusting the Antenna Azimuth Note: For wall-mount installations, if it is necessary to adjust the azimuth by more than 45°, you must first adjust the position of the Azimuth Screws. See Extending the Azimuth Range. Page 72 of 81 Ceragon Proprietary and Confidential...
  • Page 73 To adjust the antenna azimuth: 1 Loosen the Azimuth Fixing Pin (Figure 16) by pulling it gently out of its groove and rotating it counter-clockwise. 2 Manually adjust the azimuth base to its required location. Page 73 of 81 Ceragon Proprietary and Confidential...
  • Page 74 There are notches within the device that enable you to adjust the azimuth in 15° increments. You can then perform fine azimuth adjustment as described below. You will hear a click when the pin slips into the groove. Page 74 of 81 Ceragon Proprietary and Confidential...
  • Page 75 Each ¼ turn is equal to an adjustment of 0.25°. 2 Tighten the two M8 Azimuth Screws connected to the azimuth base. h nut, either by key wrench. o M8 screws he azimuth base. Page 75 of 81 Ceragon Proprietary and Confidential...

  • Page 76: Figure 27: Azimuth Screws - Top View (Azimuth 45° To The Right)

    1 Manually rotate the azimuth base 45° in the direction you want to align the azimuth. 2 Remove the two Azimuth Screws. Figure 27: Azimuth Screws – Top View (Azimuth 45° to the Right) Figure 28: Removing the Azimuth Screws (Side View) Page 76 of 81 Ceragon Proprietary and Confidential...

  • Page 77: Figure 29: Azimuth Screws In New Placement - Top View (Azimuth 45° To The Right)

    45° to the left or 45° to the right. Figure 29: Azimuth Screws in New Placement – Top View (Azimuth 45° to the Right) Figure 30: Repositioning the Azimuth Screws (Side View) Page 77 of 81 Ceragon Proprietary and Confidential...

  • Page 78: Adjusting The Antenna Elevation

    To perform gross adjustment of the antenna elevation: 1 Loosen the Elevation Fixing Pin (Figure 16) by pulling it gently out of its groove and rotating it counter-clockwise. 2 Move the Elevation Adaptor to the required location. Page 78 of 81 Ceragon Proprietary and Confidential...
  • Page 79 15° increments. You can then perform fine elevation adjustment as described below. You will hear a click when the pin slips into the groove. Page 79 of 81 Ceragon Proprietary and Confidential...
  • Page 80 To perform fine elevation alignment: 1 Turn the Elevation Nut, either by hand or using a key wrench, for fine tuning of the elevation. Each ¼ turn is equal to an adjustment of 0.25°. Page 80 of 81 Ceragon Proprietary and Confidential...
  • Page 81 Installation Guide for FibeAir IP-20V 2 Tighten the two M8 Elevation Screws connected to the Elevation Adaptor. Page 81 of 81 Ceragon Proprietary and Confidential...
