Bircher EsGate 3 Original Instructions

EsGate 3
Safety switching device for sensors with 8,2 kOhm
Original instructions
General




1 Safety Instructions
• Read these operating instructions thoroughly before putting the device
into operation and keep them for future reference.
• The assembly, commissioning, modifications and extensions may only
be completed by an experienced electrician!
• Before commencing work, remove the power supply from the device/
installations!
• During the operation of electrical components
– e. g. in the case of a short circuit hot and ionised gases can be
– emitted
– protection covers must not to be removed!
• Pay attention to all local relevant electrical safety regulations!
• Disregard of the safety regulations can cause death, severe injuries or
extensive damage!
• It is the responsibility of the equipment manufacturer to carry out a
risk assessment and to install both the detector and the equipment in
compliance with applicable national and international regulations and
safety standards, as well as the Machinery Directive 2006/42/EC,
should this apply.
2 Common Applications


 LED
 LCD display
 "Mode" button

 "Data" button
 Terminals
 Label (with terminal
description)
Before commencing the installation or assembly complete the following
safety precautions:
• Check the voltage data on the label of the switching device.
• Ensure that the device/installations can not be switched on!
• Determine that the power supply is disconnected!
• Protect the device with a housing against contamination or aggressive
environments!
• Connect all operating and switching voltages to the same fuse.
• Connect the operating voltage to the same circuit as the industrial
door controller.
• Disconnect device from mains in the event of a fault.
• Protection max. 10 A
Limited protection against accidental contact!
