Product Name: Metal Energy Absorber
Part #: 15206; 15207; 15208; 15209; 15210; 15211; 15212; 15213; 15214
Instruction Manual
Do not throw away these instructions!
Read and understand these instructions before using equipment!
1
1
1
2
2-4
5-6
6-9
9
9
10
10-11
11
Advertisement
Table of Contents
Related Manuals for Guardian 15206
Summary of Contents for Guardian 15206
-
Page 1: Table Of Contents
Product Name: Metal Energy Absorber Part #: 15206; 15207; 15208; 15209; 15210; 15211; 15212; 15213; 15214 Instruction Manual Do not throw away these instructions! Read and understand these instructions before using equipment! Introduction Applicable Safety Standards Worker Classifications Product Specific Applications... -
Page 2: Introduction
Introduction Thank you for purchasing a Guardian Fall Protection Metal Energy Absorber. This User Information manual must be read and understood in its entirety, and used as part of an employee training program as required by OSHA or any Date of First Use: applicable state agency. -
Page 3: Product Specific Applications
Product Specific Applications Use of equipment in unintended applications may result in serious WARNING injury or death. Maximum 1 attachment per connection point. Personal Fall Arrest: Metal Energy Absorber may be used as a component in a Horizontal Lifeline (HLL) system in Personal Fall Arrest (PFAS) applications. Maximum 2 users per Metal Energy Absorber HLL system when working in Fall Arrest. - Page 4 Compatibility: When making connections with Metal Energy Absorber, eliminate all possibility of roll-out. Roll-out occurs when interference between a hook and the attachment point causes the hook gate to unintentionally open and release. All connections must be selected and deemed compatible with Metal Energy Absorber by a Competent Person.
- Page 5 120’ 100’ 60’ Horizontal Lifeline SAFE ATTACHMENT ZONE DANGER ZONE: WORK IN THIS AREA NOT ALLOWED 120’ PLACE HLL 6’-10’ BACK FROM LEADING EDGE 60’ Horizontal Lifeline SAFE ATTACHMENT ZONE EXTENDS FOR ENTIRE BUILDING ROOF PERIMETER...
-
Page 6: Components And Specifications
Components made from some or all of the following: stainless steel, powder-coated steel, aluminum, and polyester. Part # Description 15206 Metal Energy Absorber, includes (2) shackles Metal Energy Absorber System for Applications Under 60'. Includes: (1) Energy Absorber, 15207 (2) Shackles, (2) Thimbles, (1) Turnbuckle, (6) Fist Grips, & (2) 2.5" O-rings Metal Energy Absorber System for Applications Over 60'. -
Page 7: Installation And Use
Metal Energy Absorber HLL System is fully installed and able to withstand forces of Fall Arrest as specified by this instruction manual. Always maintain 100% tie-off. Guardian recommends using 3/8” diameter cable. DO NOT use vinyl/plastic coated cable. MINIMUM 1 Metal Energy Absorber required for systems up to 60’. MINIMUM 2 Metal Energy Absorbers required for systems longer than 60’. - Page 8 3. Attach Metal Energy Absorber to anchor point using provided steel shackle as shown. If system is more than 60’, attach second Metal Energy Absorber to anchor point at other end of system. Tighten shackle until at least 1 full thread is visible. 4.
- Page 9 Appendix A: Fist Grip: compatible with cable diameters from 3/16” - 5/8”. Efficiency ratings for wire rope end terminations are based upon the catalog breaking strength of wire rope. The efficiency rating of a properly prepared loop or thimble-eye termination for clip sizes 1/8” through 7/8” is 80%, and for 1” through 3½” is 90%. WARNING Prepare wire rope end termination only as instructed.
-
Page 10: Maintenance, Cleaning, And Storage
If Metal Energy Absorber fails inspection in any way, immediately remove it from service, and contact Guardian to inquire about its return or repair. Cleaning after use is important for maintaining the safety and longevity of Metal Energy Absorber. Remove all dirt, corrosives, and contaminants from Metal Energy Absorber before and after each use. -
Page 11: Inspection Log
Inspection Log Date of First Use: __________________. Product lifetime is indefinite as long as it passes pre-use and Competent Person inspections. User must inspect prior to EACH use. Competent Person other than user must complete formal inspection at least every 12 months. Competent Person to inspect and initial. This inspection log must be specific to one Metal Energy Absorber. -
Page 12: Labels
Ultimate Strength: 5,000 lbs. THIS PRODUCT MUST BE USED WITH AN APPROVED HORIZONTAL LIFELINE OR INSTALLED AND DESIGNED UNDER THE SUPERVISION OF A QUALIFIED PERSON Part #: 15206 WITH A SAFETY FACTOR OF AT LEAST TWO. READ FULLY UNDERSTAND Date of Manufacture: MANUFACTURER’S INSTRUCTIONS SUPPLIED...
