ITEAD Iteaduino Plus Manual page 4

4
Memory
Power input
Interfaces
Dimension
Parameters of shield
Dimension
Indicator
Interface
Working voltage
Working voltage
at I/O port
Iteaduino PLUS with A10 Core Manual
CPU
GPU
Buttons
HDMI/SATA/MICROSD/USB-A*2/MICROUSB/MINIUS
B/RJ45/3.5MM sonic socket*2/2*36 2.54mm socket *2
ARM Cortex-A8 @ 1Ghz
Mali 400 MP
1GB @ DDR800
Uboot, Power
4.85~5.15VDC
4 groups of 2*30 1mm pitched female headers
break out all A10 I/O interfaces
62.72*56.39*1.61mm
109.22*76.2*1.2mm
3V3/5V
5~6.3VDC
3V3
iteadstudio.com
Tech Support: support@iteadstudio.com
st
21 August, 2013
